Thank you for choosing Silva Jogger headlamp. This compact headlamp is

designed for the leisure training runner and walker who require a comforta-

ble flood light for evening training on paths, tracks and un-lit roads.

PRODUCT OVERVIEW

The Jogger headlamp consists of the following parts:

• Headlampunitwithbatterycompartment

• Headband

• 3pcsAAAbatteries

• Quickguide

BEFORE USE

INSERT BATTERIES

1. Twisttheheadlampbodysoitpoints90degreesupward

2. Pulloutthelightunitfromtheheadlampbody

3. Insertthe3pcsAAAbatteriesasperthesketch

2

4. Assemblebyputtingbackthelightunitintotheheadlampbody

5. Ready!

ADJUST THE HEADBAND

The elastic headband is designed to give a comfortable fit when running or

walking. Adjust the headband by moving the sliding buckle to fit it onto your

head.

3

DURING USE

SWITCH ON YOUR HEADLAMP

On the side of the headlamp body there is a push button which controls all

light modes.

Each press on the button gives you the following light:

4

1. TurnstheheadlampONwiththeLEDinmaximumpower

2. Putstheheadlampinminmode

3. Startsoverfrom1

To turn OFF the headlamp; press and hold the button for 1 second.

5



6

The flash function, which is used to attract attention, is started from OFF

mode by pressing and holding the button for 1 second. To turn OFF; press and

hold the button for 1 second.

AFTER USE

MAINTENANCE

To make sure you get maximum performance from your Jogger headlamp,

clean it regularly with a damp cloth.

Headband cleaning – wash in washing machine at 40C.

If stored for a long period the batteries should be removed.

TECHNICAL SPECIFICATIONS

Weight (including batteries): 82g

Battery type: 3 pcs AAA Alkaline

Light distance (Max/Min): 32m/19m

Lumen: 45

Burn time (Max/Min/Blink): 20h/50h/100h

Water resistance: IPX3

Operative temperature range: -20 - +60 ºC

PROTECT THE ENVIRONMENT

Headlamp and batteries should be recycled and must not be thrown in the

regular trash. Dispose these items in accordance with applicable local

regulations.

WARRANTY

Silva warrants that, for a period of two (2) years, your Silva Product will be

substantially free of defects in materials and workmanship under normal

use. Silva’s liability under this warranty is limited to repairing or replacing

the product. This limited warranty extends only to the original purchaser.

IftheProductprovesdefectiveduringtheWarrantyPeriodpleasecontact

theoriginalplaceofpurchase.Makesuretohaveyourproofofpurchase

onhandwhenreturningtheproduct.Returnscannotbeprocessedwithout

theoriginalproofofpurchase.ThiswarrantydoesnotapplyiftheProduct

hasbeenaltered,notbeeninstalled,operated,repaired,ormaintainedin

accordancewithinstructionssuppliedbySilva,orhasbeensubjectedto

abnormalphysicalorelectricalstress,misuse,negligenceoraccident.Nei-

therdoesthewarrantycovernormalwearandtear.Silvaisnotresponsible

foranyconsequences,directorindirect,ordamageresultantfromuseof

thisproduct.InnoeventwillSilva’sliabilityexceedtheamountpaidbyyou

fortheproduct.Somejurisdictionsdonotallowtheexclusionorlimitation

ofincidentalorconsequentialdamages,sotheabovelimitationorexclusion

maynotapplytoyou.ThisWarrantyisvalidandmaybeprocessedonlyinthe

countryofpurchase.

For more information please visit www.silva.se

FULL VERSION MANUAL

jogger

Art.no 37312-1 (Turquoise)

Art.no 37312-2 (White)

Visit: www.silva/enviroment

for more information about the

Waste Electrical and Electronic

Equipment (WEEE) Directive.
