SIERRA DESIGNS 2011 Cherry Street, Unit 202 Louisville, CO 80027 Phone: 303-262-3050 Fax: 303-262-3051 Toll Free: 800-635-0461

Pole A:

Slightly Pre-bent Pole (2)

Pole B:

"V" Pole (2)

S I E R R A D E S I G N S

Figure 1: Tent Poles

BEDOUIN 6

Your Sierra Designs

BEDOUIN 6 tent is

very easy to pitch and

maintain. Follow these

instructions to pitch

your tent quickly, safely

and easily.

insert

incorrect

correct

BEDOUIN 6 TENT CONTENTS

Tent Body & Rainfly: 1 Pitching Instructions: 1

Tent Poles: 3 Stake Sack: 1

Tent Stakes: 9* Pole Sack: 1

Guy Cords: 4

* Sierra Designs tents include stakes for pitching the body and

fly under normal conditions. Additional stakes may be required

in severe conditions.

Figure 2: Correct Pole Assembly Figure 3: Tent Body (top view)

5

D

C

A

B

Q

P

S

R

G

H

E

F

First Pitch

In order to familiarize yourself with your new tent, we

suggest that you “test pitch” it before embarking on a

wilderness trip.

Select a Site

Pitch the tent on a level area that is protected from

wind and shaded from the sun, if possible. It also im

-

portant that the campsite drains well, in case of rain.

Clear the area of debris such as sharp stones and sticks

that might abrade or puncture the tent floor.

Assemble the Poles

The Bedouin 6 comes with 2 main poles and 2 brow

poles. All four poles are slightly pre-bent. The brow

poles are the shorter 2 poles. Carefully unfold the

shock corded sections and allow them to slide togeth

-

er. Do not snap the pole sections together, this will

damage the poles. Make certain that the insert of each

pole section is fully inserted into the next section (Fig-

ure 2). Failure to do so will cause your poles to crack.

Lay Out Tent Body

Unfold the royal blue and white tent body. Spread the

tent out, with the white canopy fabric facing up. Do

not step on the tent while setting it up. Spread the tent

floor out and locate all four of the stake loops. The two

royal blue stake loops are points B and C (Figure 3).

Locate the Pole Sleeves

There are two pole sleeves on this tent, running from

A to D and B to C. The pole sleeves start mid way be

-

tween the stake loops and the top of the tent.

Thread the Poles Through the Sleeves

The two main poles run A to D and B to C. Insert the

poles into the pole sleeves, with the ends of the poles

protruding equal distances on both ends of the pole

sleeves.

Erect the Tent

Once both pre-bent poles (Pole A) have been threaded

into the sleeves, arrange the tent body again so you can

see all four stake loops. Arrange the poles so they line

up with their corresponding stake loops. Working with

one pole at a time, insert one tip into its stake loop

grommet, and then push the pole from the opposite
