Bruksanvisning Rosières BRBF 172 DT Kyl-frys

Bruksanvisning

EN 3

Fig. 1

Remove all wrapping/packaging present inside the appliance and clean

with water and baking soda or neutral soap.

After the installation, wait 2 - 3 hours to allow time for the refrigerator/

freezer to stabilize at normal working temperature, before placing fresh

or frozen foods inside.

If the power cord becomes disconnected, wait at least five minutes

before restarting the refrigerator/ freezer. At this point, the appliance is

ready for use.

Press the button for setting the temperature until you reach the level you

want where level 1 is the warmest and level 4 is the coldest. Under

normal operating conditions, we recommend using an intermediate

setting (level 2)

If you do not press the button (2) for more than 5 seconds, the settings

will be saved.

The temperature levels in advanced settings are set from warmest to

coldest e.g. 2/2.1/2.3/2.4 which means there are 4 sub-levels for every

main level.

Door open alarm

If the door is left open for longer than 90 seconds, an alarm is sounded. To

1 2 3 4

Press button (2) for less than 2 seconds to change the temperature level.

1 2 3 4

Advanced settings menu:

Use this menu to set an intermediate level.

1 2 3 4

Press button (2) for more than 2 seconds. When you release it, LED

2 will flash

1 2 3 4

The next time you press button (2) for less than 2 seconds, the

intermediate level will be set. This operation works in cycles every time

you press the button.

1 2 3 4

1 2 3 4

By placing the mark on this product, we are confirming compliance to

all relevant European safety, health and environmental requirements which

are applicable in legislation for this product.

Scrapping old appliance

Conformity

Appliance start-up

Turning On/Off with internal User Interface

Setting the temperature

OPERATION

Control panel

1. Temperature indicator LED

2. Temperature control

3. ON/OFF button

4. E- Contact button

Turning the appliance ON:

Plug the appliance in, if all the temperature indicators LEDs are off, press

ON/OFF (3) for 1 second. When you release the ON/OFF button (

3) a

temperature light will come on and the appliance will beep.

Turning the appliance OFF:

Press the ON/OFF button (3) for 1 second, when you release it, the

temperature light will go out and the appliance will beep. In the event of a

power failure, when the power comes back on, the appliance will run

using the last saved setting.

23

1

WARNINGS:

• Do not install the appliance in a damp or wet location as this could

compromise the insulation and result in leakage.

Furthermore, on the exterior of the same, condensate could accumulate

• Do not place the appliance in locations outside or near sources of heat

or exposed to direct sunlight.

The appliance operates properly within the range of environmental

temperatures indicated:

+10 +32’C for the climatic class SN

+16 +32’C for the climatic class N

+16 +38’C for the climatic class ST

+16 +43’C for the climatic class T

(See the nameplate of the product)

• Do not place containers with liquids on top of the appliance.

• Wait at least 3 hours after final placement before placing the appliance

in operation.

After shipping, place the appliance vertically and wait at least 2 - 3 hours

before connecting it to the electrical system. Before inserting the plug

into the electrical socket, make sure that:

• The socket is earthed and in compliance with the law.

• The socket can withstand the maximum power load of the appliance, as

indicated on the nameplate of the refrigerator.

• The power supply voltage is within the amounts indicated on the

nameplate of the refrigerator.

• The cord must not be folded or compressed.

• The cord must be checked regularly and replaced solely by authorized

technicians.

• The manufacturer declines any liability whenever these safety

measures are not respected.

Electrical connection

INSTALLATION

This appliance is marked according to the European directive

2012/19/EU on Waste Electrical and Electronic Equipment (WEEE).

WEEE contains both polluting substances (which can cause negative

consequences for the environment) and basic components (which

can be re-used). It is important to have WEEE subjected to specific

treatments, in order to remove and dispose properly all pollutants,

and recover and recycle all materials.

Individuals can play an important role in ensuring that WEEE does

not become an environmental issue; it is essential to follow some

basic rules:

- WEEE should not be treated as household waste;

- WEEE should be handed over to the relevant collection points

managed by the municipality or by registered companies. In

many countries, for large WEEE, home collection could be

present.

In many countries, when you buy a new appliance, the old one may

be returned to the retailer who has to collect it free of charge on a

one-to-one basis, as long as the equipment is of equivalent type and

has the same functions as the supplied equipment.

4
