Bruksanvisning Prime3 ABT02OR Up! Högtalare

Bruksanvisning

Owner's manual

Model: PRIME3 UP! (ABT02), Bluetooth speaker

· Use in accordance with the instruction manual.

· Do not install the device near any heat sources such as radiators,

heat registers, stoves or other apparatus (including amplifiers) that

generate heat.

· Clean only with a dry cloth.

· Do not cover or obstruct ventilation holes on speakers' grill.

· Do not expose the device to dripping or splashing.

· Use only original accessories specified by manufacturer.

· This product is not a toy, can be used by children only under

supervision of adults.

· Do not expose the device to excessive heat such as sunshine, fire

or the like.

· Do not use during lighting storms.

· Do not expose the device to electromagnetic radiation.

· In order to prevent hearing loss, do not listen to music for

prolonged periods of time.

· Remember to do not use electronic devices in distance smaller

than 10cm from pacemaker.

Hereby, 2N-Everpol Sp. z o.o., declares that this equipment is in compliance with the essential requirement and

other relevant provisions of Directive 2014/53/EU. Declaration of conformity can be obtained from the

product page at www.prime3.eu. Responsible party: 2N-Everpol Sp.z o.o., Puławska 403A, 02-801 Warsaw,

Poland, Phone: +48 22 331 99 59, E-mail: inf[email protected]

Your products is designed a

manufactured with high quality

materials and components, which can

be recycled and reused.

When this crossed-out wheeled bin symbol is attached to a product it means that the product is covered by the European

Directive 2012/19/EU. Please inform yourself about the local separate collection system for electrical and electronic

products. Used appliance should be delivered to the dedicated collecting points due to hazardous components, which may

affect the environment. Do not dispose this appliance In the common waste bin.

Many thanks for buying our product. This model includes

below main features.

1. Bluetooth function for audio streaming playback.

2. Aux in.

3. Built-in rechargeable battery power.

List of controls：

1. Power buton

2. MicroUSB DC 5V power jack

3. Charging LED indicator.

4. AUX IN jack.

Battery charging

This unit had built-in rechargeable lithium battery inside. Before

start the playing, please follow up below step for charging.

1. Using the supplied USB to microUSB type charging cable

connects the speaker with your USB charger (USB adaptor or USB

output port like on PC, USB rating output: 5V/500mA, other USB

charger with current equal or above 500mA). The microUSB

connector should connect with the DC 5V power jack on the rear

panel of speaker, and another terminal connect with USB charger.

Then plug your USB charger into the household AC power.

2. The charging LED will light on in red colour during charging, and

the red colour LED will off when the battery is fully charged.

3. The speaker will off automatically when the battery power

exhausted, please arrange recharge for playing.

Important: We recommend connect the USB charger with rating

output spec at DC 5V/500mA, or equal or above 500mA output

current USB power. The general USB output on PC (personal

computer) is 5V/500mA (please reference your PC spec for

checking). There may have some charging noise or abnormal

function from speaker if the charging current is too low. If it

happened, please remove the charging power and put the speaker

in a while, then the speaker will reset the function in normal. Please

kindly note this is not malfunction.

Notes:

Your battery lifetime will last longer if you follow up below simple

guidelines for charging and storing.

a. For charging first time, charge it at least 10 hours.

b. Recharge and store the unit within the temperature range of

5°C~35°C (40°F~95°F).

c. Do not charge longer than 24 hours. Excessive charging or

discharging may shorten the battery's life.

d. Battery life naturally shortens slowly over time.

e. Please turn off the speaker if long time not to use.

f. he speaker can play music during charging.

g. Due to prolong charging and discharging, the unit battery life

will be affected and playback time will also be shortened. We

cannot guarantee the same playback consistently throughout and

this is not include in our warranty and service.

Bluetooth operation

The speaker includes Bluetooth function which allows you to

wireless playback the audio with other Bluetooth device like smart

phone etc. Please follow up below for the operation.

Your product contains batteries covered by the European Directive

2006/66/EG, which cannot be disposed with normal household

waste. Please inform yourself about the local rules on separate

collection of batteries because correct disposal helps to prevent

negative consequences for the environmental and human health.

Recording and playback of material might require consent. See Copyright Act 1956 and The Performer's

Protection Acts 1958 to 1972.

The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of

such marks by us is under license. Other trademarks and trade names are those of their respective owners.

12 4

3
