Bruksanvisning Philips HQ132 Rakapparat

Bruksanvisning

2 Place two batteries in the battery

compartment (Fig. 3).

Note: Make sure the + and - indications on

the batteries match the indications in the

battery compartment.

Note: The shaver does not work if the

batteries have been placed incorrectly.

3 Put the lid of the battery

compartment back onto the appliance.

First insert the top part of the lid

(1) and then press down the bottom

part (2) until you hear a click (Fig. 4).

How to avoid damage due to

battery leakage

- Do not expose the appliance to

temperatures higher than 35°C.

- Remove the batteries if you are not

going to use the appliance for a month

or more.

- Do not leave empty batteries in the

appliance.

Shaving time

Two new batteries offer a shaving time of

60 minutes.

Using the appliance

Shaving

Your skin may need 2 or 3 weeks to get

accustomed to the Philips shaving system.

Shaving on a dry face gives the best results.

1 Push the on/off slide upwards to

switch on the shaver (Fig. 5).

2 Move the shaving heads over your

skin. Make both straight and circular

movements (Fig. 6).

3 Push the on/off slide downwards to

switch off the shaver.

4 Push the protection cap onto the

shaver after use to prevent damage to

the shaving heads (‘click’) (Fig. 7).

Cleaning and maintenance

Never use scouring pads, abrasive cleaning

agents or aggressive liquids such as petrol

or acetone to clean the appliance.

Regular cleaning guarantees better shaving

performance.

For easy and optimal cleaning, Philips

Shaving Head Cleaning Spray (type no.

HQ110) is available. Ask your Philips dealer

for information.

Note: Philips Shaving Head Cleaning

Spray may not be available in all countries.

Contact the Consumer Care Centre in your

country about the availability in your country.

You can also clean the shaver in the

following way:

Every week: shaving unit and hair

chamber

1 Switch off the shaver.

2 Clean the top of the appliance with

the cleaning brush (Fig. 8).

3 Press the release button (1) and

remove the shaving unit (2) (Fig. 9).

4 Clean the inside of the hair

chamber with the cleaning

brush (Fig. 10).

5 Clean the inside of the shaving unit

with the cleaning brush (Fig. 11).

6

Put the shaving unit back onto the shaver.

Every two months: shaving heads

1 Switch off the shaver.

2 Press the release button (1) and

remove the shaving unit (2) (Fig. 9).

3 To remove the retaining frame, push the

sides of the central spring towards each

other (1). Then lift the retaining frame

out of the shaving unit (2) (Fig. 12).

4 Slide the shaving heads out of the

retaining frame (Fig. 13).

Do not mix up the cutters and the guards.

Cutters and guards are matching sets.

Each cutter has been ground with

its corresponding guard for optimal

performance. If you accidentally mix up the

sets, it may take several weeks before

optimal shaving performance is restored.

5 Clean the cutter with the short-

bristled side of the cleaning

brush (Fig. 14).

Brush carefully in the direction of the arrow.

6 Clean the guard with the cleaning

brush (Fig. 15).

HQ139, HQ136, HQ132, HQ130

Register your product and get support at

www.philips.com/welcome

4222.002.5009.6

1 2 3

4

5 6

7

8 9

10

11 12

13

14 15

16

2

yrs

17 18

19

ENGLISH

Introduction

Congratulations on your purchase and

welcome to Philips! To fully benet from

the support that Philips offers, register your

product at www.philips.com/welcome.

Important

Read this user manual carefully before you

use the appliance and save it for future

reference.

Danger

- Keep the appliance dry.

Warning

- This symbol means: Forbidden to clean

under a running tap (Fig. 1).

- This appliance is not intended for use

by persons (including children) with

reduced physical, sensory or mental

capabilities, or lack of experience and

knowledge, unless they have been given

supervision or instruction concerning

use of the appliance by a person

responsible for their safety.

- Children should be supervised to ensure

that they do not play with the appliance.

Caution

- Use and store the appliance at a

temperature between 15°C and 35°C.

- Remove the batteries from the

appliance if you are not going to use it

for a month or more.

Electromagnetic elds (EMF)

This shaver complies with all standards

regarding electromagnetic elds (EMF).

If handled properly and according to the

instructions in this user manual, the shaver

is safe to use based on scientic evidence

available today.

Preparing for use

Inserting batteries

This shaver runs on two R6 AA 1.5-volt

batteries. Preferably use Philips alkaline

batteries.

Make sure that your hands are dry when

you insert the batteries.

1 Remove the lid of the battery

compartment (Fig. 2)
