Bruksanvisning Pergo Long Plank Laminatgolv

Bruksanvisning

1. FLOATING FLOOR — Pergo flooring is designed to be

installed as a floating floor — thus it is not nailed or glued

to the subfloor. Instead, planks are fastened together uti-

lizing unique tongues and grooves to create a durable,

easy-to-maintain floor surface. Because Pergo flooring

expands and contracts with temperature/humidity

changes—it is essential that a

3

⁄8" expansion space be

left around the floor’s perimeter. Depending on the type

of Pergo flooring you purchased and your home’s sub-

floor type, you may also be required to install a sound

underlayment and/or 6-mil. (.15mm) non-recycled (100%

virgin) resin polyethylene film as a moisture barrier

beneath your Pergo floor. Please refer to the detailed

installation instructions by subfloor type that follow. The

illustrated example below shows Pergo being installed

over a concrete subfloor.

2. WHAT YOU NEED TO KNOW — Pergo flooring consists

of planks made from a durable laminate surface, a

wood based core and a balancing backing. The planks

are clicked together to form a long lasting, easy-to-

maintain surface. Like almost all materials in the home,

Pergo flooring expands and contracts due to changes

in temperature and humidity. You must allow unopened

cartons of Pergo flooring to lay flat in the room where

they will be installed to acclimate for 48-96 hours,

depending upon climate, before beginning installation.

A

3

⁄8" expansion space must be left around the perimeter

of the floor to allow for movement. Failure to meet these

requirements can result in the flooring buckling.

Pergo flooring is a complete flooring system that includes

a wide range of coordinating moldings and transition

strips designed to cover the

3

⁄8" expansion space at the

walls, doorways and transitions to other flooring.

Specialized tools, required to properly install Pergo

flooring, are available where Pergo products are sold.

3. BEFORE STARTING —Before beginning a Pergo

installation project, it is critical that you 1) fully acquaint

yourself with the detailed installation instructions for your

specific flooring and subfloor type and 2) conduct a

complete job site evaluation (see section 6, Job Site

Evaluation).

a. For appropriate installation information, review this

guide and the assembly instructions printed on or

provided within each carton for the Pergo flooring

type you purchased. If you prefer to speak to a

person regarding installation, call 1-800-33-PERGO

(1-800-337-3746).

b. Make a complete job site evaluation (see section 6,

Job Site Evaluation) to assure that environmental

conditions are acceptable for installing Pergo flooring.

c. Determine the quantity of Pergo planks, flooring

transitions and wall trim needed for your installation.

Depending on the type of Pergo flooring purchased,

the type of room and the type of subfloor you are

working with, you may also need glue, sealant,

a 6 mil (.15mm) non-recycled (100% virgin) resin

polyethylene film as a moisture barrier and/or

sound underlayment designed for laminate floors

(see detailed installation instructions). Add 10%

to your square footage for standard installations.

For diagonal installations, add 15%.

d. Make sure you have the appropriate installation

tools, an Installation Kit, additional spacers (used to

maintain expansion space).

e. Acclimation — Allow unopened cartons of Pergo

planks to lay flat in the room where they will be

installed for 48-96 hours, depending upon climate,

before beginning installation. During this time, the

planks adjust to the specific temperature and

humidity conditions of the room.

4. A BASIC OVERV IEW

a. Remove any existing quarter round molding. The

existing quarter round can be repainted and installed

after the Pergo installation or you can select a new,

finished, color-coordinated Pergo quarter round

available at your retailer.

b. Always remove carpet, pad and tack strips.

c. Remove wood flooring if it is installed over a concrete

subfloor.

d. Be sure the surface of the subfloor is flat, clean, dry

and sound before starting. (Refer to Subfloor

Requirements Sections 7, 8, 9, 10 & 11.)

e. On concrete subfloors, use a non-recycled 6-mil. (.15mm)

non-recycled (100% virgin) resin polyethylene film as

a vapor barrier, overlapping edges 8", or follow the

directions for installation of an equivialent vapor barrier.

f. Use Pergo SilentStep

TM

or Soundbloc

TM

Foam or equiva-

lent foam underlayment to absorb sound and to make

the floor more comfortable to walk and stand on

when the Pergo product that you are using does not

have an attached underlayment foam. Do not install

Pergo over multiple layers of acoustic underlayment.

g. Inspect every plank for any shipping damage when

removing from the carton.

5. INSTALLATION REQUIREMENTS

a. Pergo is intended only for indoor use.

b. Acclimation— Allow the Pergo planks to lay flat in

unopened cartons, at least two feet from walls where

they will be installed, for 48-96 hours before starting

the installation. In very dry or very humid climates,

allow at least 96 hours (4 days). For acclimation, the

relative humidity should be 30-90%. The temperature

should be at least 65°F for product acclimation and

at least 65°F two days after installation.

Pergo SilentStep

™

Foam or Soundbloc

™

Foam to be used with flooring that

doesn't have attached underlayment.

Vapor barrier over

concrete –

Moisturbloc

™

●

●
