Bruksanvisning

Instructions

LED Head Modes :

Rotate the side knob A to to turn on both

main and downcast leds.

Rotate the side knob A to

to turn on

downcast led only.

Rotate the side knob A to

to turn on main led only.

Rotate the side knob A to

for flashing.

To adjust brightness on the light

At any position, press the center blue button on the side knob B

to adjust brightness from 100%, 50%, 10% except on flashing mode.

Red led on battery pack

To activate the back RED led, press the switch one time.

For flashing, press the switch twice within 1 second.

To turn off from either mode, press the switch after 2 seconds.

Battery status indicator

3 blue leds : 75 to 100%

2 blue leds : 50 to 75%

1 blue led : 25 to 50%

1 blue led flashing : 25% or less

Notes: when 25% or less, light head

will flash 4 times per minute

Battery Replacement

1. Rotate the battery knob counter

clockwise to remove the battery

compartment.

2. Remove old batteries (dispose of properly) and

replace with four 1.5V alkaline batteries according

to the polarity label.

3. Reinsert the battery compartment into the housing

and rotate the battery knob clockwise to close.

Battery Safety Information

WARNING: HANDLE AND STORE BATTERIES PROPERLY TO

AVOID INJURY. DAMAGED BATTERIES CAN BE DANGEROUS!

Most battery issues arise from improper handling of batteries,

and particularly from the use of damaged or counterfeit batteries.

Please review the information below to avoid serious injury and/or

damage to your property.

Alkaline Batteries

1. For those lights with hazardous location safety approvals for

explosive environments please be advised that the safety

approval is only valid for the specified battery type manufacturer

and, where applicable, brand names that are displayed on the

flashlight and/or instructions sheets that are supplied with the

light. The use of other battery technologies may reduce the per-

formance of the flashlight and will invalidate the safety approval.

2. Always read the battery manufacturers recommendations for the

appropriate use of the battery technology/brand prior to using

the flashlight.

3. When replacing the batteries:

a. Replace all the batteries at the same time.

b. Do not mix battery brands and old and new batteries.

c. Always insert batteries correctly with regard to polarity

(+ and -) marked on the battery and equipment.

4. Do not change batteries in a hazardous location.

5. Remove batteries from equipment if it is not to be used for

an extended period of time.

23215 Early Ave. • Torrance, CA 90505 USA

Tel (310) 326-4700 • FAX (310) 326-3311 • www.pelican.com

10221-184th Street • Edmonton, Alberta T5S 2J4 Canada

Tel (780) 481-6076 • FAX (780) 481-9586

www.pelican.ca

002785-0311-000 5-16104 Rev A NO/15 © PELICAN PRODUCTS 2015

All trademarks are registered and/or unregistered trademarks

of Pelican Products, Inc., its subsidiaries and/or afliates.

CON LA GARANTÍA LIMITADA DE EXCELENCIA

DE POR VIDA DE PELICAN

Pelican Products, Inc., ofrece una garantía de por vida en sus linter-

nas contra roturas o defectos de fabricación. Esta garantía no cubre

la lámpara ni las pilas. Las reclamaciones de garantía de cualquier

clase se considerarán nulas en caso de que el producto haya sufrido

alteraciones, daños o modicaciones físicas de cualquier tipo, se

haya hecho un uso incorrecto, abusivo o negligente o haya sufrido

accidentes. Para obtener toda la información relativa a la garantía,

véase http://www.pelican.com/warranty.

GARANTIE D’EXCELLENCE À VIE LIMITÉE DE PELICAN

Pelican Products, Inc. garantit à vie ses torches contre la casse et les

défauts de fabrication. Cette garantie ne couvre pas l’ampoule ou les

piles. Toute demande de prise en charge sous garantie, de quelque

nature que ce soit, sera refusée si le produit a été transformé, endom-

magé ou physiquement modié d’une façon ou d’une autre, ou encore

sujet à un traitement abusif, une mauvaise utilisation, une négligence

ou un accident. Pour une version complète et détaillée de la garantie,

voir http://www.pelican.com/warranty.

PELICAN LIMITED LIFETIME GUARANTEE OF EXCELLENCE

Pelican Products, Inc. guarantees its lights for a lifetime against breakage

or defects in workmanship. This guarantee does not cover the lamp or

batteries. All warranty claims of any nature are barred if the product has

been altered, damaged or in any way physically changed, or subjected to

abuse, misuse, negligence or accident. For complete warranty details, see

http://www.pelican.com/warranty.

In Australia: The benets provided to you under this warranty are in

addition to your rights and remedies as a consumer under the Competition

and Consumer Act 2010 (Cth). Nothing in this warranty limits the rights or

obligations of a party under provisions of the Competition and Consumer

Act 2010 (Cth) in relation to the supply to consumers of goods which

cannot be limited, modied or excluded. If applicable, our goods come with

guarantees that cannot be excluded under the Australian Consumer Law.

You are entitled to a replacement or refund for a major failure and compen-

sation for any other reasonably foreseeable loss or damage. You are also

entitled to have the goods repaired or replaced if the goods fail to be of

acceptable quality and the failure does not amount to a major failure. If you

are not a consumer under the Competition and Consumer Act 2010 (Cth),

then your rights may be limited. To make a warranty claim, the purchaser

must contact Pelican Products Australia, Suite 2.33, West Wing, Platinum

Bldg., Erina NSW 2250, Tel: +612 4367 7022. Any warranty claims shall

be made by the purchaser as soon as practicable. The purchaser must

obtain a return authorization number from Pelican Customer Service prior

to returning any product, and is responsible for paying for all warranty

freight costs. If Pelican determines that any returned product is not

defective, within the terms of this warranty, the purchaser shall pay Pelican

all costs of handling, return freight and repairs at Pelican’s prevailing rates.

In the event that Pelican determines that any returned product is

defective, within the terms of this warranty, Pelican shall pay the purchaser

all reasonable costs of the purchaser in making claim under this warranty.

Lifetime Guarantee does not cover Roto Molded cases, AALG

products or fabric portion of backpacks. Refer to

www.pelican.com/warranty for full details.

A

B

PELICAN PRODUCTS ULC

Red LED

Switch

Battery

Status

Indicator

Battery Knob Door

Red LED

2785 LED

Coding: Class I, Division 1, Groups A, B, C, D, T4

IECEx ITS 15.0057X Ex ia op is IIC T4 Ga

Intrinsically Safe

Approved for use with four size “AA” alkaline cells

(Energizer E91, Panasonic LR6, Philips LR6)

Codicación: clase I, división 1, grupos A, B, C, D, T4

IECEx ITS 15.0057X Ex ia op is IIC T4 Ga

Intrínsecamente seguro

Aprobado para su uso, con cuatro pilas alcalinas tamaño “AA”

(Energizer E91, Panasonic LR6, Philips LR6)

Codage: Classe I, Division 1, Groupes A, B, C, D, T4

IECEx ITS 15.0057X Ex ia op is IIC T4 Ga

Intrinsèquement sûr

Approuvé pour une utilisation avec quatre piles alcalines de taille

«AA» (Energizer E91, Panasonic LR6, Philips LR6)

002785-0311-000 Rev A.indd 1 1/26/16 7:29 AM
