Safety Precautions

AC 220-240 V

50 / 60 Hz

Electronic equipment

In particular, do not place video equipment near the TV

(electromagnetic interference may distort images / sound).

Equipment with an infrared sensor

This TV also emits infrared rays (this may affect

operation of other equipment).

Keep the TV away from these equipment

Warning & Caution

Notes

Example 1

Example 2

IMPORTANT: THE MOULDED MAINS PLUG

FOR YOUR SAFETY, PLEASE READ THE FOLLOWING TEXT CAREFULLY.

The wire which is coloured BLUE must be connected to the terminal in the mains plug

which is marked with the letter N or coloured BLACK.

The wire which is coloured BROWN must be connected to the terminal in the mains plug which is

marked with the letter L or coloured RED.

Under no circumstances should either of these wires be connected to the Earth terminal of the

three pin mains plug, marked with the letter E or the earth symbol .

How to replace the fuse.

For plug type shown in example 1:

Lift out the removable fuse compartment with a screwdriver and replace the fuse, then refit

securely into the mains plug (see example 1).

For plug type shown in example 2:

Lift open the fuse compartment, in the mains plug, with a screwdriver, and replace the fuse, then

press the fuse cover down securely (see example 2).

As the colours of the wire in the mains lead of this appliance may not correspond with the coloured

markings identifying the terminals in your mains plug, proceed as follows.

IMPORTANT: – The wires in this mains lead are coloured in accordance with the following code: –

Blue: Neutral

Brown: Live

If a new mains plug is to be fitted, please observe the wiring code as shown below.

If in any doubt, please consult a qualified electrician.

If the fitted moulded mains plug is unsuitable for the socket outlet in your home, then the fuse shall be

removed and the mains plug cut off and disposed of safety. There is a danger of severe electrical shock

if the cut off mains plug is inserted into any 13 amp socket.

If the mains plug contains a removable fuse cover, you must ensure that it is refitted when the fuse is replaced.

If you lose the fuse cover the mains plug must not be used until a replacement cover is obtained.

A replacement fuse cover may be purchased from your local Panasonic Dealer.

This appliance is supplied with a moulded three pin mains plug for your safety and convenience. A 5 amp fuse is

fitted in this mains plug. Shall the fuse need to be replaced, please ensure that the replacement fuse has a rating

of 5 amps and that it is approved by ASTA or BSI to BS1362.

Check for the ASTA mark

ASA

or the BSI mark on the body of the fuse.

Handling the mains plug

Ensure that the mains plug is easily

accessible at all times. The On / Off switch

on this model does not fully disconnect the

TV from the mains supply. Remove the

mains plug from the wall socket when the

TV is not used for a prolonged period of

time.

Do not expose to

direct sunlight and

other sources of heat

Avoid exposing the TV to direct sunlight

and other sources of heat. To prevent fire

never place any type of candle or naked

flame on top or near the TV.

Power source

This TV is designed to operate on 220-240V, 50 / 60 Hz AC.

Display panel

Cabinet

Mains plug

Regular care: Gently wipe the surface clean of dirt by using a

soft cloth.

Major contamination: Wipe the surface clean using a soft cloth

dampened with clean water or diluted neutral detergent by

100 times of water. Then, using a soft dry cloth, evenly wipe

the surface clean until it is dry.

Regular care: Wipe the surface clean using a soft dry cloth.

Major contamination: Dampen a soft cloth with clean water or

water containing a small amount of neutral detergent. Then,

wring the cloth and wipe the surface clean with it. Finally, wipe

the surface clean with a dry cloth.

Wipe the mains plug with a dry cloth at regular intervals.

(Moisture and dust may lead to fire or electrical shock.)

First, remove the mains plug from the socket outlet.

Caution

•

The surface of the display panel has been specially treated

and may be easily damaged.

Do not tap or scratch the surface with your fingernail or

other hard object.

•

Use care not to subject the surface to insect repellent,

solvent, thinner, or other volatile substances

(this may degrade surface quality).

Caution

•

Use care not to subject the TV’s surfaces to detergent.

(A liquid inside the TV could lead to product failure.)

•

Use care not to subject surfaces to insect repellent, solvent,

thinner, or other volatile substances

(this may deteriorate the surface by peeling the paint).

•

Do not allow the cabinet to make contact with a rubber or

PVC substance for a long time.

Maintenance

Do not remove the cover

Do not remove the rear cover as live parts are accessible

when it is removed. There are no user serviceable parts inside.

Do not block the rear

ventilation openings

Ventilation should not be impeded by

covering the ventilation openings with

items such as newspapers, tablecloths and

curtains.

Use only the dedicated

stands / mounting

equipment

Using an unauthorized stand or other

fixtures may make the TV shaky, risking

injury. Be sure to ask your local Panasonic

dealer to perform setup.

Use optional stands / mounts (p. 6).

Do not place the TV

on sloped or unstable

surfaces

The TV may fall off or tip over.

Do not expose to rain or

excessive moisture

To prevent damage which might result in

electric shock or fire, do not expose this TV

to rain or excessive moisture.

This TV must not be exposed to dripping or

splashing water and objects filled with liquid,

such as vases, must not be placed on top of

or above the TV.

Do not allow children to

handle SD card

As with a small object, SD card can be

swallowed by young children. Please

remove SD card immediately after use.

Adjust the LCD panel to your desired angle

15° 15°

(View from the top)

If no signal is received and no operation is performed in TV mode

for 30 minutes, the TV will automatically go to standby mode.

Auto power standby function

Transport only in upright position

Allow sufficient space

around the TV for radiated

heat

10

10

10

10

(cm)

TV Stand

Minimum distance
