Bruksanvisning Panasonic TH-42PX60B Viera Plasma TV

Bruksanvisning

4 5

Safety Precautions

4 : 3

12

AC 220-240 V

50 / 60 Hz

Do not display a still picture for a long time

This causes the image to remain on the plasma

screen ("after-image").

This is not considered a malfunction and is

not covered by the warranty.

To prevent after-image, the screen saver is

automatically activated after a few minutes if no signals

are sent or no operations are performed. (p. 44)

Electronic equipment

In particular, do not place video equipment near the unit

(electromagnetic interference may distort images / sound).

Equipment with an infrared sensor

This TV also emits infrared rays (this may affect

operation of other equipment).

Keep the unit away from these equipment

Warning & Caution

Typical still images

Channel number and other logos

Image displayed in 4:3 mode

Video game

Computer image

Notes

IMPORTANT: THE MOULDED MAINS PLUG

FOR YOUR SAFETY, PLEASE READ THE FOLLOWING TEXT CAREFULLY.

The wire which is coloured GREEN-AND-YELLOW must be connected to the terminal in the mains plug which is

marked with the letter E or by the Earth symbol

or coloured GREEN or GREEN-AND-YELLOW.

The wire which is coloured BLUE must be connected to the terminal in the mains plug

which is marked with the letter N or coloured BLACK.

The wire which is coloured BROWN must be connected to the terminal in the mains plug

which is marked with the letter L or coloured RED.

How to replace the fuse.

Open the fuse compartment with a screwdriver and replace the fuse.

As the colours of the wire in the mains lead of this appliance may not correspond with the coloured markings

identifying the terminals in your mains plug, proceed as follows.

WARNING: – THIS APPARATUS MUST BE EARTHED.

IMPORTANT: – The wires in this mains lead are coloured in accordance with the following code: –

Green-and-Yellow: Earth

Blue: Neutral

Brown: Live

If a new mains plug is to be fi tted, please observe the wiring code as shown below.

If in any doubt, please consult a qualifi ed electrician.

If the fi tted moulded mains plug is unsuitable for the socket outlet in your home, then the fuse shall be

removed and the mains plug cut off and disposed of safety. There is a danger of severe electrical shock

if the cut off mains plug is inserted into any 13 amp socket.

If the mains plug contains a removable fuse cover, you must ensure that it is refi tted when the fuse is replaced.

If you lose the fuse cover the mains plug must not be used until a replacement cover is obtained.

A replacement fuse cover may be purchased from your local Panasonic Dealer.

This appliance is supplied with a moulded three pin mains plug for your safety and convenience. A 5 amp fuse is

fi tted in this mains plug. Shall the fuse need to be replaced, please ensure that the replacement fuse has a rating

of 5 amps and that it is approved by ASTA or BSI to BS1362.

Check for the ASTA mark

ASA

or the BSI mark on the body of the fuse.

Handling the mains plug

Ensure that the mains plug is easily accessible at all

times. The On/Off switch on this model does not fully

disconnect the TV from the mains supply. Remove the

mains plug from the wall socket when the TV set is not

used for a prolonged period of time.

Ensure the grounding pin on the mains plug is securely

connected to prevent electrical shock.

An apparatus with CLASS I construction shall be connected

to a mains socket outlet with a protective earthing connection.

Note

If the set is not switched off when the TV station stops

transmitting, it will automatically go to standby mode after 30

minutes. This function will operate only in Analogue TV mode.

Do not expose to

direct sunlight and

other sources of heat

Avoid exposing the TV set to direct

sunlight and other sources of heat. To

prevent fi re never place any type of

candle or naked fl ame on top or near

the TV set.

Power source

This TV set is designed to operate on 220-240V,

50 / 60 Hz AC.

Do not remove the cover

Do not remove the rear cover as live parts are

accessible when it is removed. There are no

user serviceable parts inside.

Do not expose to rain or

excessive moisture

To prevent damage which might result in electric

shock or fi re, do not expose this TV set to rain

or excessive moisture.

This TV must not be exposed to dripping or

splashing water and objects fi lled with liquid,

such as vases, must not be placed on top of or

above the TV.

Do not block the rear

ventilation openings

Ventilation should not be impeded by covering

the ventilation openings with items such as

newspapers, tablecloths and curtains.

Cabinet and display panel care

Remove the mains plug from the wall socket.

The cabinet and display panel can be cleaned

with a soft cloth moistened with mild detergent

and water. Do not use solutions containing

benzol or petroleum.

TV sets can produce static electricity, care must

be taken whenever touching the TV screen.

Use only the dedicated

stands / mounting equipment

Using an unauthorized stand or other fi xtures may

make the unit shaky, risking injury. Be sure to ask

your local Panasonic dealer to perform setup.

Use optional stands / mounts (p. 6).

Do not place the TV on

sloped or unstable surfaces

The TV may fall off or tip over.

Display panel

Cabinet

Mains plug

Daily care:

Gently wipe the surface clean of dirt by using a soft cloth.

Major contamination: Wipe the surface clean using a soft

cloth dampened with clean water or water containing a

small amount of neutral detergent. Then, using a soft dry

cloth, evenly wipe the surface clean until it is dry.

Daily care: Wipe the surface clean using a soft dry cloth.

Major contamination: Dampen a soft cloth with clean water

or water containing a small amount of neutral detergent.

Then, wring the cloth and wipe the surface clean with it.

Finally, wipe the surface clean with a dry cloth.

Wipe the mains plug with a dry cloth at regular intervals.

(Moisture and dust may lead to fi re or electrical shock.)

First, remove the mains plug from the socket outlet.

Caution

•

The surface of the display panel has been specially

treated and may be easily damaged.

Do not tap or scratch the surface with your fi ngernail or

other hard object.

•

Use care not to subject the surface to insect repellent,

solvent, thinner, or other volatile substances

(this may degrade surface quality).

Caution

•

Use care not to subject the TV unit's surfaces to detergent.

(A liquid inside the TV unit could lead to product failure.)

•

Use care not to subject surfaces to insect repellent,

solvent, thinner, or other volatile substances

(this may deteriorate the surface by peeling the paint).

•

Do not allow the cabinet to make contact with a rubber

or PVC substance for a long time.

Maintenance

Allow suffi cient space around

the unit for radiated heat

10

10

6

10

7

(cm)
