Bruksanvisning Panasonic SL-SX276J Discman

Bruksanvisning

Power Supply Preparations

Refer to the specifications (page 8) for information on operating times when using rechargeable batteries or dry-cell batteries.

Using the AC adaptor

Connect the AC adaptor supplied.

Using rechargeable batteries

(not included)

Obtain the optional rechargeable batteries. (page 8)

Make sure to recharge the batteries before using them.

The unit cannot be used to charge rechargeable batter-

ies other than those specially designed for it.

≥Optional batteries (P-3GAVA/2B)

Recharging procedure

1 Insert the special rechargeable bat-

teries into the unit.

2 Connect the AC adaptor.

(Refer to “Using the AC adaptor” for connection

instructions.)

Recharging starts and the “H

” charging indicator

flashes on and off on the unit’s display. When the

rechargeable batteries fully recharge the charging

indicator disappears.

3 When recharging is complete, un-

plug the AC adaptor from the

household AC outlet and the DC IN

jack.

Note!

≥Rechargeable batteries have a service life of approxi-

mately 300 charge-discharge cycles. If the operating

time on one full charge becomes noticeably shorter

than it used to be, the battery has reached the end of

its service life and should be replaced.

≥Recharging may only be performed when the unit is

powered off. (It is not possible to recharge the batter-

ies while playing a CD.)

≥The AC adaptor and rechargeable batteries may be-

come warm while recharging is in progress. This is not

a malfunction.

Using the car adaptor

(not included)

Be sure to obtain the car adaptor (SH-CDC9) available

as an optional accessory.

The car adaptor can be used to recharge the unit’s bat-

teries while in the car.

Using dry-cell batteries

(not included)

After disconnecting the AC adaptor, insert two “AA”

(LR6) alkaline batteries.

The procedure for inserting and removing dry-cell

batteries is identical to that for rechargeable bat-

teries.

Battery indicator

This indicator flashes on and off when the batteries are

almost out of power. Power is cut off completely a short

while later.

Rechargeable batteries: Recharge batteries.

Dry-cell batteries: Replace batteries with new ones.

Note!

≥The length of time the unit will continue to operate be-

tween when the battery indicator starts flashing and

when the power is cut off differs depending on the

type of batteries used.

≥The battery indicator may not flash if rechargeable

batteries other than those designated by Panasonic

are used.

Removing batteries

Push up on the battery

in the direction indicat-

ed by the arrow. Then

lift it out.

If the battery lid

comes loose

Slide the lid back into

place horizontally.

If the unit malfunctions or freezes during use,

then disconnect the power sources (the AC

adaptor or batteries).

Re-connect the power source and continue op-

eration.

1

+

-

2

3

CAUTION:

Use only car adaptor, Model: SH-CDC9 manufac-

tured by Matsushita Electric Industrial Co.,Ltd.

2

DC IN jack (DC IN 4.5 V K)

Back panel of the unit

Household

AC outlet

AC adaptor

A.SHOCK

S

-

XBS

Battery indicator

Location of Controls

Portable CD Player A

A Stop/operation off button

(∫,OPR OFF)

B Skip/search buttons

(:, 96, 5)

C Display

D Anti-shock button (A.SHOCK)

E Play/pause button (1;)

F Play mode selector

(NOR, RANDOM, RESUME)

G Hold switch (HOLD)

H Headphone jack (Ë)

I Headphone volume control

(VOLUME)

J EQ button (EQ)

K Memory/recall button

(MEMORY/RECALL)

L Repeat button (`)

M Open switch (OPEN)

N CD release button (PUSH)

O Hole for car mounting base

P DC IN jack

(DC IN 4.5 V K)

Wired remote control B

A Skip/search buttons (i,j)

B Hold switch (HOLD)

C Play/stop/off button

D Plug

E Volume control (VOL)

F Hold indicator

F

A BCD B E

GHI J K L M

PO

A

B

N

D

A

B

C

E

F

Back panel of

the unit

Conserving power

The AC adaptor consumes 2.0 W when the unit is

turned off with [∫,OPR OFF]. To save power when the

unit is not to be used for a long time, unplug the AC

adaptor from the household AC outlet. Reprogram

tracks if necessary before use.
