Main unit

Remote control

A

Location of controls/Connection to other equipment

Turn off this unit and the other equipment before connection.

Battery

compartment

Hold switch

Headphone jack

Open switch

Tuning/Skip/Search

Play/Pause

Stop /

Operation off

Volume control

To DC IN jack

Play/Stop/

Operation off

Skip/Search

Monaural/Stereo

Sensitivity control/

Play mode selection

Memory/

Recall

Audio system

Adjust the volume level

on the audio system.

AC adaptor (RP-AC46) (not included)

Household AC

outlet

Car power adaptor (SH-CDC9) (not included)

Car audio

Hold switch

Playing MP3

This unit can play MP3 files you have recorded to discs.

MPEG Layer-3 audio decoding technology licenced from

Fraunhofer IIS and Thomson multimedia.

HOLD

This function causes the unit to ignore accidental button

presses.

Set to HOLD so the unit doesn’t power on accidentally or

play is interrupted.

∫The unit and remote control each have independent HOLD

switches.

Note on CD-R and CD-RW

This unit can play CD-R and CD-RW recorded with CD-DA or

MP3. Use an audio recording disc for CD-DA and finalize

§

it

when you finish recording. The unit may not be able to play

some discs due to the condition of the recording.

§A process performed after recording that enables CD-

R/CD-RW players to play audio CD-R and CD-RW.

Resume function

The unit stores the track where you stopped play. Replacing

the disc cancels the function.

Auto power off function

If the unit is left in stop mode for approximately 10 minutes,

the unit powers itself off automatically.

To CD or AUX terminals

Audio cable (not included)

Car stereo cassette adaptor (SH-CDM10A)

(

not included

)

Set the unit’s volume to 10.

Tone

selection

≥Set the unit’s volume to 10.

≥Use the main unit to avoid beep

sounds heard when operating the

remote control buttons.

Some cannot be

connected.

2

CD SECTION

∫CD-DA

No. of channels:

2 (left and right, stereo)

Frequency response:

20 to 20,000 Hz

(j10 dB to 0 dB)

DA converter: 1 bit, MASH

Headphone output level:

RMS max. 8 mWi8 mW/

16 ≠ (adjustable)

∫MP3

Supported bit-rates:

32 kbps to 320 kbps

(128 kbps is recommended)

Supported sampling frequency

48 kHz/44.1 kHz/32 kHz

Maximum number of items

(sum of albums and tracks): 999

Maximum album levels: 100

∫Pickup

Light source:

Semiconductor laser

Wavelength: 780 nm

RADIO SECTION

∫Frequency

Radio frequency:

FM; 87.90–107.90 MHz

(0.2 MHz steps)

87.50–108.00 MHz

(0.1 MHz/0.05 MHz steps)

AM; 520–1710 kHz

(10 kHz steps)

522–1629 kHz

(9 kHz steps)

GENERAL

Power supply:

DC input (via optional AC adaptor):

DC 4.5 V

Operational temperature range:

0 eC–40 eC (32 eF–104 eF)

Play time:

[Approximate operating time in hours

(playing MP3 at the recommended

bitrate of 128 kbps, with HOLD on

and S-XBS canceled, at 25 eC (77 eF)

on a flat, stable surface)]

≥The play time may be less

depending on the operating

conditions.

≥Play time will be considerably

reduced when playing CD-RW.

Dimensions (WaHaD):

135a25.8a135 mm

(5

5

/16za1

1

/32za5

5

/16z)

Mass: 223 g (7.9 oz.)

(with batteries)

177 g (6.2 oz.)

(without batteries)

Note:

Specifications are subject to

change without notice.

Mass and dimensions are

approximate.

Specifications

Lens

Supplied Accessories

For U.S.A.

≥1 Pair of stereo headphones:

L0BAD0000162

For Canada

≥1 Pair of stereo earphones:

L0BAB0000123

≥1 Wired remote control:

N2QCBD000011

≥1 Pair of stereo headphones:

L0BAD0000163

≥1 Jogger soft case:

RFC0060-K

SL-SV553JSL-SV550

Check the packing carton for these accessories.

Use numbers indicated when ordering replacements or optional accessories

from your Panasonic dealer.

In U.S.A. contact 1-800-332-5368 or web site (http://www.panasonic.com).

Tuner on/off/

Band select

Volume control

Tuning mode selection

Tuner on/Band select

For Canada

SL-SV553J

Through to Headphone jack

SL-SV553J

Directly to headphone jack

SL-SV550

Connect remote control to main unit first.

SL-SV550

For U.S.A.

SL-SV553J

Actual headphones may be different

from those shown in the illustration.

SL-SV553J

Display panel

Batteries

used

2 optional

alkaline batteries

MP3

disc

35

CD-DA

disc

23

RADIO

(FM BAND)

75
