Bruksanvisning Panasonic SL-SV500 Discman

Bruksanvisning

2

Using the AC adaptor (not included)

Use only the recommended AC adaptor. Use of other

AC adaptors can damage the unit.

Connect the AC adaptor.

Conserving power

To save power when the unit is not to be used for a long

time, unplug the AC adaptor from the household AC

outlet.

Power Supply Preparations

Refer to the specifications (page 8) for information on operating times when using dry cell batteries.

CAUTION:

Use only car adaptor, Model: SH-CDC9 manufac-

tured by Matsushita Electric Industrial Co., Ltd.

Battery indicator

This indicator flashes when the batteries are almost out

of power. Power is cut off a short while later. Replace

batteries with new ones.

Note!

How long the unit continues to operate after the battery

indicator starts flashing depends on the type of batteries

and on whether you are using the unit to play CDs or

the radio.

Using the car adaptor (not included)

Use only the recommended car adaptor. Use of other

car adaptors can damage the unit.

Be sure to obtain the car adaptor (SH-CDC9) available

as an optional accessory.

DC IN4.5V

If the unit malfunctions or freezes during use,

disconnect the power source (the AC adaptor

or batteries).

Re-connect the power source and continue

operation.

DC IN jack (DC IN 4.5 V

K

)

Back panel of

the unit

Household

AC outlet

AC adaptor

Battery indicator

C

S

-

XBSAUTO

RANDOM

MEMORY

FM

AM

VOL

MONO

CITY

TUNED

SORRY

1

M

Important note about the memory

and the power supply

To preserve the contents of the memory, ensure

the unit has a constant supply of power.

≥Turn the unit off before changing the batteries and

before connecting or disconnecting the AC adaptor.

≥The unit can maintain the memory without power

for about one minute. Change batteries or recon-

nect the AC adaptor within this time.

≥As a precaution, insert batteries even when using

the AC adaptor or car adaptor.

For U.S.A.

To order the optional AC adaptor RP-AC46 contact

1-800-332-5368 or web site (http://www.panason-

ic.com).

For Canada

Be sure to obtain the optional AC adaptor RP-

AC46, available through your Panasonic dealer.

Using dry cell batteries

(not included)

Insert two “LR6, AA, UM-3” alkaline

batteries.

Note!

The dry cell batteries should be changed when the unit

is off.

Using rechargeable batteries

(not included)

≥If rechargeable batteries are to be used, rechargeable

batteries manufactured by Panasonic are recommend-

ed.

≥This unit cannot recharge batteries. The battery indi-

cator will not function correctly when using recharge-

able batteries.

Removing batteries

Push up on the battery

in the direction indicat-

ed by the arrow. Then

lift it out.

If the battery lid

comes loose

Slide the lid back into

place horizontally.

O

P

E

N

1

O

P

E

N

+

-

2

3

O

P

E

N

O

PE

N

Location of Controls

O

P

E

N

Ë

H

O

L

D

JKL

M

N

D

E

GF

H

I

B

A

C

O

DC IN4.5V

P

Q

Ë

OPEN

H

O

L

D

O

P

R

O

F

F

M

E

M

O

R

Y

/

R

E

C

A

L

L

T

U

N

IN

G

M

O

D

E

F

M

M

O

D

E

M

O

N

O

/

S

T

30 STATIO

N M

EM

O

RY

PO

R

TA

B

LE

C

D

PLA

YE

R

SL-SV500

V

O

L

V

O

L

S

-

X

B

S

R

AD

IO/

BAN

D

F

M

R

E

C

E

P

T

C

I

T

Y

/

N

O

R

M

O

D

E

A Stop/operation off button

(∫, OPR OFF)

B Tuning/skip/search buttons

(

9

/i,

:

/j)

C Memory/recall button

(MEMORY/RECALL)

D Tuning mode select button

(TUNING MODE)

E Display

F S-XBS button (S-XBS)

G Tuner on/band select button

(RADIO/BAND)

H Headphone volume control

buttons (VOLi, VOLj)

I Play/pause button (

1/

;

)

J Sensitivity control, play mode

button

(

FM RECEPT%CITY/NOR, MODE

)

K Open switch (OPEN1)

L Monaural/stereo button

(FM MODE MONO/ST)

M Headphone jack (Ë)

N Hold switch (HOLD)

O CD release button (PUSH)

P Hole for car mounting base

Q

DC IN jack

(DC IN 4.5 V K)

HOLD

Ë

O

P

E

N

H

O

L

D

O

P

R

O

F

F

M

E

M

O

R

Y/

R

E

C

A

LL

T

U

N

IN

G

M

O

D

E

F

M

M

O

D

E

M

O

N

O

/S

T

3

0

S

T

A

T

IO

N

M

E

M

O

R

Y

P

O

R

T

A

B

L

E

C

D

P

L

A

Y

E

R

S

L

-

S

V

5

0

0

V

O

L

V

O

L

S-XBS

RADIO/

BAND

F

M

R

E

C

E

P

T

C

I

T

Y

/N

O

R

M

O

D

E

HOLD mode

Before operating the buttons

Be sure to move [HOLD] to release

the unit from the HOLD mode.

This function causes the unit to ignore

short, accidental button presses. (The

disc lid can still be opened and closed.)

The HOLD function prevents the

following:

≥The unit is powered on accidentally

when not in use, causing the batteries

to run down.

≥A button is accidentally pressed during

play, interrupting the operation.

To use the HOLD function

Set [HOLD] to the HOLD position.

“(” indication

When the unit is in HOLD mode, press-

ing any button causes the indication

“(” to appear on the display.

When the unit is powered off:

The “(” indication appears only

when [

1/;

] or [RADIO/BAND] is

pressed.

HOLD Function

Back panel

of the unit
