2
Caution
Audio (CD-DA)
No. of channels:
2 (left and right, stereo)
Frequency response:
20 to 20,000 Hz
(i0.5 dB to j10 dB)
DA converter: 1 bit, MASH
Headphone output level:
RMS max. 8 mWi8 mW/
16 ≠ (adjustable)
Pickup
Light source:. Semiconductor laser
Wavelength: 780 nm
(NORSK)
Bølgelengde 780 nm
Laserstyrke
Ingen farlig stråling sendes ut
(med sikkerhets-beskyttelse)
WMA(SL-MP80)/MP3
Supported bit-rates:
WMA: 32 kbps to 192 kbps
(96 kbps is recommended)
MP3: 32 kbps to 320 kbps
(128 kbps is recommended)
Supported sampling frequencies:
48 kHz/44.1 kHz/32 kHz
Maximum number of items
(sum of albums and tracks): 999
Maximum album levels: 100
General
Power supply:
DC input: DC 4.5 V
(
SL-MP80/SL-MP70)
AC adaptor input:
The United Kingdom:
AC 230 –240 V 50/60 Hz
Continental Europe :
AC 220 –230 V 50/60 Hz
China : AC 220 V 50 Hz
Other areas: AC 110 –127 V/
220 –240 V 50/60 Hz
(SL-MP80/SL-MP70)
Power consumption:
Using AC adaptor
(WMA
[SL-MP80]
/MP3/CD-DA):
3.6 W/3.6 W/3.4 W
Recharging: 5.9 W
≥Do not expose the unit to direct sunlight or heat, such as from heating
appliances, as these can damage the unit.
≥Discontinue use if you experience discomfort with the earphones or any
other parts that directly contact your skin. Continued use may cause
rashes or other allergic reactions.
∫Batteries
≥Do not peel off the covering on batteries and do not use if the covering
has been peeled off.
≥Align the poles + and - correctly when inserting the batteries.
≥Do not mix different types of batteries or old and new batteries.
≥Remove the batteries if you do not intend to use the unit for a long time.
≥Do not throw into fire, short-circuit, disassemble, or subject to excessive
heat.
≥Do not attempt to recharge dry cell batteries.
≥When carrying batteries in a pocket or bag, ensure no metal objects
such as necklaces are placed together with them. Contact with metal
may cause short-circuiting which can cause a fire.
∫Listening
≥Do not play your headphones or earphones at a high volume. Hearing
experts advise against continuous extended play.
≥If you experience a ringing in your ears, reduce volume or discontinue
use.
≥Do not use while operating a motorized vehicle. It may create a traffic
hazard and is illegal in many areas.
≥You should use extreme caution or temporarily discontinue use in
potentially hazardous situations.
≥Even if your headphones or earphones are the open-air type designed to
let you hear outside sounds, don’t turn up the volume so high that you
can’t hear what’s around you.
∫CDs
≥Do not use irregularly shaped CDs.
≥Do not use non-specification discs.
≥Do not use CDs printed with label printers available on the market.
≥Do not use CDs with labels and stickers that are coming off or with
adhesive exuding from under labels and stickers.
Specifications
Maintenance
If the surfaces are dirty wipe with a soft, dry cloth.
≥Never use alcohol, paint thinner or benzine to clean this unit.
≥Before using chemically treated cloth, read the instructions that came
with the cloth carefully.
Play time:
Approximate operating time in
hours, playing WMA/MP3 at the
recommended bitrate (WMA: 96
kbps, MP3: 128 kbps), with HOLD
on and EQ canceled, at 25 oC on a
flat, stable surface.
Recharging time: 5 to 6 hours
≥The play time may be less
depending on the operating
conditions.
≥Play time will be considerably
reduced when playing CD-RW.
Operational temperature range:
0 eC–40 eC
Rechargeable temperature range:
5 eC–40 eC
Dimensions (WaHaD):
135a28a135 mm
Mass: 230 g (with batteries)
184 g (without batteries)
Note:
Specifications are subject to
change without notice.
Mass and dimensions are
approximate.
Batteries
used
2 optional
alkaline batteries
2 optional
rechargeable
batteries
WMA
disc
(SL-MP80)
45
20
MP3
disc
48
23
CD-DA
disc
37
15
Display
HOLD
The HOLD function is on (
➪
page 4).
NO DISC
≥You haven’t inserted a disc or it isn’t inserted correctly.
≥You have inserted a disc this unit cannot play.
OPEN
The disc lid is open.
F
Full: The program already contains 20 tracks.
READING
Reading disc. “>” also appears when reading WMA/MP3 files.
CHARGE
The batteries are recharging. Recharging is complete when this
disappears.
References to WMA apply only to SL-MP80.
References to WMA apply only to SL-MP80.
Notice about the rechargeable battery
The battery is designated recyclable.
Please follow your local recycling regulations.
Norsk
Merknad vedrørende det oppladbare batteriet
Batteriet er resirkulerbart.
Vennligst følg det lokale regelverket for resirkulering.
Suomi
Huomautus ladattavasta paristosta
Paristo määritellään kierrätykseen sopivaksi.
Ole hyvä ja noudata asuinpaikkasi kierrätyssääntöjä.
For the United Kingdom and Continental Europe:
