Bruksanvisning

2 VQT2A30 3VQT2A30

Before use

Remove the connector cover.

How to replace the fuse

The location of the fuse differ according to the type of AC mains plug (figures A

and B).

Confirm the AC mains plug fitted and follow the instructions below.

Illustrations may differ from actual AC mains plug.

1) Open the fuse cover with a

screwdriver.

2) Replace the fuse and close or

attach the fuse cover.

Figure A Figure B

Fuse cover

Figure A Figure B

Fuse

(5 ampere)

Fuse

(5 ampere)

EMC Electric and magnetic compatibility

This symbol (CE) is located on the rating plate. (EB/EP only)

IF THE POWER CORD OF THIS EQUIPMENT IS DAMAGED, IT MUST BE

REPLACED WITH AN ELECTRICALLY APPROVED POWER CORD.

Use only the recommended accessories.

Do not use any other AV cables and USB connection cables except the

supplied one.

When you use the cable which are sold separately, please make sure to use

the one whose length is less than 3 m.

Keep the Memory Card out of reach of children to prevent swallowing.

How to replace the Fuse(Only for Hong Kong Special

Administrative Region of China and Saudi Arabia)

The location of the fuse differ according to the type of AC mains plug

(figures A and B).Confirm the AC mains plug fitted and follow the

instructions below.Illustrations may differ from actual AC mains plug.

1) Open the fuse cover with a

screwdriver.

2) Replace the fuse and close or

attach the fuse cover.

Figure A Figure B

Fuse cover

Figure A Figure B

Fuse

(5 ampere)

Fuse

(5 ampere)

●

●

●

Dear Customer,

We would like to take this opportunity to thank you for purchasing this

Panasonic SD Video Camera. Please read these Operating Instructions

carefully and keep them handy for future reference. Please note that the actual

controls and components, menu items, etc. of your SD Video Camera may look

somewhat different from those shown in the illustrations in these Operating

Instructions.

Caution for AC mains lead (For United Kingdom)

For your safety, please read the following text carefully.

This appliance is supplied with a moulded three pin mains plug for your safety

and convenience.

A 5-ampere fuse is fitted in this plug. Should the fuse need to be replaced

please ensure that the replacement fuse has a rating of 5-ampere and that it is

approved by ASTA or BSI to BS1362.

Check for the ASTA mark

or the BSI mark on the body of the fuse.

If the plug contains a removable fuse cover you must ensure that it is refitted

when the fuse is replaced.

If you lose the fuse cover the plug must not be used until a replacement cover

is obtained.

A replacement fuse cover can be purchased from your local dealer.

CAUTION!

IF THE FITTED MOULDED PLUG IS UNSUITABLE FOR THE SOCKET

OUTLET IN YOUR HOME THEN THE FUSE SHOULD BE REMOVED AND

THE PLUG CUT OFF AND DISPOSED OF SAFELY.

THERE IS A DANGER OF SEVERE ELECTRICAL SHOCK IF THE CUT

OFF PLUG IS INSERTED INTO ANY 13-AMPERE SOCKET.

If a new plug is to be fitted please observe the wiring code as stated below.

If in any doubt please consult a qualified electrician.

IMPORTANT

The wires in this mains lead are coloured in accordance with the following code:

Blue: Neutral, Brown: Live.

As these colours may not correspond with the coloured markings identifying the

terminals in your plug, proceed as follows:

The wire which is coloured Blue must be connected to the terminal which is

marked with the letter N or coloured Black or Blue.

The wire which is coloured Brown must be connected to the terminal which is

marked with the letter L or coloured Brown or Red.

WARNING: DO NOT CONNECT EITHER WIRE TO THE EARTH TERMINAL

WHICH IS MARKED WITH THE LETTER E, BY THE EARTH SYMBOL

OR

COLOURED GREEN OR GREEN/YELLOW.

THIS PLUG IS NOT WATERPROOF—KEEP DRY.
