R6/LR6, AA
Aim at the sensor, avoiding obstacles, at a
maximum range of 7 m directly in front of
the unit.
Operation can be affected by strong light
sources, such as direct sunlight, and the
glass doors on cabinets.
•
•
Keep your speakers at least 10 mm away from the
system for proper ventilation.
These speakers do not have magnetic shielding. Do
not place them near televisions, personal computers
or other devices easily influenced by magnetism.
You cannot take the front net off the speakers.
•
•
•
Note
Left and right speakers are different.
Insert so the poles (+ and – ) match those
in the remote control.
Do not use rechargeable type batteries.
•
•
Standby/on switch [8]
Press to switch the unit from on to
standby mode or vice versa.
In standby mode, the unit is still
consuming a small amount of power.
[SLEEP]
SLEEP timer operation ON/OFF or SLEEP time setting
CD/MP3 Program, Tuner Preset (Manual) [PGM, -AUTO PRESET]
[Long press] Tuner Preset (Auto)
CD/MP3/USB: Delete all programs [CLEAR]
[PLAY MODE] Play mode button
[CD q/h] Selector switch to CD.
Direct CD Play/CD Pause
[TUNER/BAND]
Selector switch to Tuner
for FM and AM.
Turn the volume up/down [VOL-], [+VOL]
[z PLAY] Timer PLAY ON/OFF
Clock and Timer setting [CLOCK/TIMER]
[1-9, 0,
≧
10] Numbered buttons
To select a 2-digit number
e.g. 16: [
≧
10] [1] [6]
To select a 3-digit number
e.g. 226: [
≧
10] [
≧
10] [2] [2] [6]
[MUSIC PORT] Selector switch to MUSIC PORT
[g] Stop button
[2/u, 1\i] CD: Skip/Search
MP3/USB: Track Skip
TUNER: Tune up/down, [Long press] Auto tuning
[REPEAT] Repeat ON/OFF
[SURROUND] SURROUND mode ON/OFF
Delete last programmed track [DEL]
[DISPLAY]
CD: CD Display (Elapsed play time/Remaining play time)
MP3: MP3 Display (Elapsed time/Album name/Track name/
ID3 [Album]/ID3 [Track]/ID3 [Artist])
USB: USB Display (Elapsed time/Remaining time/Album
name/Track name/ID3 [Album]/ID3 [Track]/ID3 [Artist])
RDS: RDS Display (Station Name/Program Type/Frequency)
Preset EQ mode selector [PRESET EQ]
Remote control signal sensor
■ Use
■ Batteries
The remote control
Control guide
Display
Standby/on switch
[^]
Remote control signal sensor
Placement of speakers
Caution
Use the speakers only with the
recommended system. Failure to do so
may lead to damage to the amplifier and/or
speakers, and may result in the risk of
fire. Consult a qualified service person if
damage has occurred or if you experience
a sudden change in performance.
Do not attach these speakers to walls or
ceilings.
•
•
Music port jack
[- VOLUME +] To adjust the volume
[2/u, 1\i] CD: Skip/Search
MP3/USB: Track Skip
TUNER: Tune up/down, [Long press] Auto tuning
[g] Stop button
[CD q/h] Selector switch to CD. Direct CD Play/CD Pause
[MUSIC PORT] Selector switch to MUSIC PORT
[; OPEN/CLOSE] Open and Close CD lid
FM/AM/MUSIC PORT select button [FM/AM/MUSIC P.]
FM/AM select button [TUNER/BAND]
2 3
SC-EN35
SC-EN33
[;, OPEN/CLOSE] Open and Close CD lid
SC-EN35
SC-EN33
Previous/Next Album [ , ALBUM]
Confirm track selection during MP3/USB Program Mode [ENTER]
0
(Minimum)
50
(Maximum)
Use the numbers indicated in parentheses when asking for replacement
parts.
Supplied accessories
(As of January 2007)
1 Remote control [
➡
page 2]
1 FM/AM antenna [
➡
page 3]
2 Batteries [➡ page 2]
1 AC mains lead [
➡
page 3]
(N2QAYB000107)
(N2QAYB000108)
SC-EN35
SC-EN33
AC mains lead
Right Speaker
Left Speaker
DC in cord to connect to main set
For other areas
For Australia and N.Z.
Selector switch to Tuner for
FM and AM.
[FM/AM]
Selector switch to USB. Direct USB Play/USB Pause [USB
q/h]
SC-EN35
SC-EN33
USB port
The included AC mains lead is for use with this unit only. Do not use it with other
equipment.
Do not use an AC mains lead from other equipment.
•
•
[USB q/h] Selector switch to USB. Direct USB Play/USB Pause
SC-EN35
SC-EN35 E,GN,GCS PP.indd 2 22/03/2007 17:17:21
