2
PHONES
SPEAKERS(6
)
R
L
HAU
T-
P
ARLEURS
FM/AM ANT
AC IN
R
L
1
2
Use the numbers indicated in parentheses when asking for
replacement parts.
(As of December 2005)
In U.S.A. to order accessories, refer to “Accessory Purchases” on page 8.
1 Remote control
(N2QAGB000037)
(N2QAGB000038)
2 Batteries
1 FM/AM antenna
(N1DADYY00003)
1 AC power supply cord
(RJA0065-1D)
The included AC power supply cord is for use with this unit only. Do not
use it with other equipment.
Note
Batteries
• Insert so the poles (+ and –)
match those in the remote
control.
• Do not use rechargeable type
batteries.
Use
Remote control signal sensor
• Aim at the sensor, avoiding obstacles, at a
maximum range of 7 m directly in front of the
unit.
• Operation can be affected by strong light
sources, such as direct sunlight, and the glass
doors on cabinets.
To clean this unit, wipe with a soft, dry cloth.
• Never use alcohol, paint thinner or benzine to clean this unit.
• Before using chemically treated cloth, read the instructions that came with
the cloth carefully.
1 Speakers
Before connecting, twist off
the tip.
Red
Black
Black
Red
Copper (+)
Silver (–)
Silver (–)
Copper (+)
2 FM/AM antenna
Stand the antenna up on its base.
3 AC power supply cord
Connect the AC power
supply cord only after all
other connections have been
made.
Conserving power
The unit consumes 2.0 W even when it is turned
off with [POWER
8
]. To save power when the
unit is not to be used for a long time, unplug it
from the household AC outlet.
Remember to reset the radio stations and any
other memory items before using the unit again.
If the unit is left unplugged for longer than
approximately two weeks, all settings will revert
to the factory settings.
To household AC outlet
Portable audio equipment
(Cords and equipment not included.)
Portable audio player
Plug type:
3.5 mm (1/8″ )
stereo
Use
Start Playback from the
Portable audio source.
Note
• Adjust the volume and sound quality of this unit and
the other equipment.
• For details, refer to the instruction manual of the other
equipment.
Select
“MUSIC P”
Headphones
(Not included)
Reduce the volume before connection.
Plug type: 3.5 mm (1/8″ ) stereo
Avoid listening for prolonged periods of
time to prevent hearing damage.
Note
(R6, AA)
The socket outlet shall be installed near the equipment and easily accessible or the mains plug or an appliance coupler shall remain readily operable.
Care of the CD lens
• Clean the lens regularly to prevent malfunctions. Use a blower to remove
dust and a cotton swab if it is extremely dirty.
Recommended product: Lens cleaner kit (part no. SZZP1038C).
• Do not use the lens cleaner of the CD type.
Place this unit in an area with more than 240 mm (9
7/16″) of vertical space.
The CD lid may become damaged if it cannot open
completely.
Placement of speakers
Left and right speakers are exactly the same.
• Keep your speakers at least 10 mm (13/32″) away
from the system for proper ventilation.
• These speakers do not have magnetic shielding.
Do not place them near televisions, personal
computers or other devices easily infl uenced by
magnetism.
•
To avoid damage to the speakers, do not touch
the speaker cones if you have taken the nets off.
Caution
• Use the speakers only with the
recommended system. Failure
to do so may lead to damage to
the amplifi er and/or the speakers,
and may result in the risk of
fi re. Consult a qualifi ed service
person if damage has occurred
or if you experience a sudden
change in performance.
• Do not attach these speakers to
walls or ceilings.
Note
Note
Remote control
Unplug the antenna connector by
holding the taped part.
SC-EN27
SC-EN25/SC-EN26
Taped part
FM antenna
AM antenna
SC-EN252627PPC̲4.indd2SC-EN252627PPC̲4.indd2 2005-12-1218:05:432005-12-1218:05:43
