Bruksanvisning Panasonic SB-TP10GN Högtalare

Bruksanvisning

RQT6901

2

Safety precautions

Placement

Set the unit up on an even surface away from direct sunlight, high

temperatures, high humidity, and excessive vibration. These conditions

can damage the cabinet and other components, thereby shortening

the unit’s service life.

Voltage

Do not use high voltage power sources. This can overload the unit

and cause a fire.

Do not use a DC power source. Check the source carefully when

setting the unit up on a ship or other place where DC is used.

AC mains lead protection

Ensure the AC mains lead is connected correctly and not damaged.

Poor connection and lead damage can cause fire or electric shock.

Do not pull, bend, or place heavy items on the lead.

Grasp the plug firmly when unplugging the lead. Pulling the AC

mains lead can cause electric shock.

Do not handle the plug with wet hands. This can cause electric

shock.

Foreign matter

Do not let metal objects fall inside the unit. This can cause electric

shock or malfunction.

Do not let liquids get into the unit. This can cause electric shock or

malfunction. If this occurs, immediately disconnect the unit from the

power supply and contact your dealer.

Do not spray insecticides onto or into the unit. They contain

flammable gases which can ignite if sprayed into the unit.

Service

Do not attempt to repair this unit by yourself. If sound is interrupted,

indicators fail to light, smoke appears, or any other problem that is not

covered in these operating instructions occurs, disconnect the AC

mains lead and contact your dealer or an authorized service center.

Electric shock or damage to the unit can occur if the unit is repaired,

disassembled or reconstructed by unqualified persons.

Extend operating life by disconnecting the unit from the power

source if it is not to be used for a long time.

Insertion of connector

Even when the connector is per-

fectly inserted, depending on the

type of inlet used, the front part of

the connector may jut out as shown

in the drawing.

However there is no problem using

the unit.

Connector

Approx. 6 mm

Appliance inlet

Caution for AC mains lead

(For the United Kingdom)

(“EB” area code model only)

For your safety, please read the following text carefully.

This appliance is supplied with a moulded three pin mains plug for

your safety and convenience.

A 5-ampere fuse is fitted in this plug.

Should the fuse need to be replaced please ensure that the re-

placement fuse has a rating of 5-ampere and that it is approved by

ASTA or BSI to BS1362.

Check for the ASTA mark m or the BSI mark o on the body of the fuse.

If the plug contains a removable fuse cover you must ensure that it

is refitted when the fuse is replaced.

If you lose the fuse cover the plug must not be used until a replace-

ment cover is obtained.

A replacement fuse cover can be purchased from your local dealer.

If a new plug is to be fitted please observe the wiring code as stated

below.

If in any doubt please consult a qualified electrician.

IMPORTANT

The wires in this mains lead are coloured in accordance with the

following code:

Blue: Neutral, Brown: Live.

As these colours may not correspond with the coloured markings

identifying the terminals in your plug, proceed as follows:

The wire which is coloured Blue must be connected to the terminal

which is marked with the letter N or coloured Black or Blue.

The wire which is coloured Brown must be connected to the terminal

which is marked with the letter L or coloured Brown or Red.

WARNING: DO NOT CONNECT EITHER WIRE TO THE

EARTH TERMINAL WHICH IS MARKED WITH THE LET-

TER E, BY THE EARTH SYMBOL

nn

nn

n OR COLOURED

GREEN OR GREEN/YELLOW.

THIS PLUG IS NOT WATERPROOF—KEEP DRY.

Before use

Remove the connector cover.

How to replace the fuse

The location of the fuse differ according to the type of AC mains

plug (figures A and B). Confirm the AC mains plug fitted and follow

the instructions below.

Illustrations may differ from actual AC mains plug.

1. Open the fuse cover with a screwdriver.

2. Replace the fuse and close or attach the fuse cover.

Fuse cover

Figure A

Figure B

Fuse

(5 ampere)

Fuse

(5 ampere)

Figure A

Figure B

CAUTION!

IF THE FITTED MOULDED PLUG IS UNSUITABLE FOR THE

SOCKET OUTLET IN YOUR HOME THEN THE FUSE

SHOULD BE REMOVED AND THE PLUG CUT OFF AND

DISPOSED OF SAFELY.

THERE IS A DANGER OF SEVERE ELECTRICAL SHOCK IF

THE CUT OFF PLUG IS INSERTED INTO ANY 13-AMPERE

SOCKET.
