ENGLISH

4 5

Using the rechargeable battery (supplied)

The supplied rechargeable battery must be charged before using this unit.

Nickel-metal hydride rechargeable battery

Use the supplied battery or a dedicated replacement battery

RP-BP6000 (optional).

Commercially available rechargeable batteries

You cannot charge commercially available rechargeable

batteries.

Power supply preparations: Headphones

1

2

3

Insert the rib c on the battery compartment

lid into the hole on the left housing and then

close the battery compartment lid.

Push the battery compartment lid until it locks.

Insert the supplied nickel-metal hydride

rechargeable battery.

● Align the poles + and - correctly when inserting.

● Push down on the

-

pole spring when inserting

Remove the +

poles first when removing.

Press the [BATT] knob on the left housing

a to open the battery compartment lid b

and then take it off.

4

Charging

Put the headphones on the transmitter (not

included) making sure that the charging

terminals f are in contact with each other.

g Left housing

The battery can be charged with the headphones

placed vertically or horizontally.

● The OPR/CHARGE lamp

h on the transmitter

glows red.

● The OPR/CHARGE lamp

h goes out when the

battery is fully charged.

● When putting the headphones on the

transmitter, hold the left and right housings in

each hand and put the headphones straight

down onto the transmitter.

● The transmitter will automatically stop emitting radio waves if headphones are left on the transmitter. Be sure to

take the headphones off the transmitter when using other headphones at the same time.

● The headphones can be used even if the battery is not fully charged.

● Charge the battery in an environment with an ambient temperature between 0 °C and 40 °C or it may not be fully

charged.

Note

The headphones are recharged if they are put back

onto the transmitter after being fully charged.

Do not keep recharging the battery if you do not use it

between recharges.

The battery will be overcharged causing overheating

and electrolyte leakage.

Placing the

headphones vertically

Placing the headphones

horizontally

For your reference

Charging and operating times

*

1

At 1 kHz, 1 mW+1 mW output.

*

2

Time required to fully charge from empty.

*

3

Operating times may differ depending on the temperature of the surrounding environment and operating

conditions.

Charging time Operating time *

1

Approx. 3 hours *

2

Approx. 8 hours *

3

If the OPR/CHARGE lamp does not glow red

Check that the left and right sides of the headphones are correctly placed on the left and right sides of the

transmitter.

Check that the charging terminals on the headphones and transmitter are touching each other. Adjust them if

they are not touching.

● When there is dirt on the charging terminals of the headphones or the transmitter, remove it gently with a

cotton bud, etc.

To charge the battery after using the headphones

Put the headphones back on the transmitter. The OPR/CHARGE lamp glows red and charging begins.

To check the remaining battery power

Pull the free-adjusting band i and check if the OPR lamp j on the right housing

k is dim or off. This means that the battery has run down and should be charged

or replaced.

If the sound is distorted, intermittent or there is excessive background noise while

using the headphones, the battery should be charged or replaced.

The service life for the supplied rechargeable battery

The supplied nickel-metal hydride rechargeable battery can be recharged

approximately 300 times. If the operation time of the battery becomes extremely

short after charging, the battery’s service life has reached the end. Be sure to

replace it with the dedicated rechargeable battery RP-BP6000 (optional).

The power turns off automatically when you remove

the headphones.

(Auto power on/off function)

Do not pull up the free-adjusting band i when not using the headphones. This may

cause the auto power on/off function to switch the headphones back on and battery

power to run down

Using alkaline dry cell batteries (not included)

Use “LR6, AA” alkaline dry cell batteries. Put the 2 alkaline dry cell batteries into the headphones in the same way

as described in [Using the rechargeable battery (supplied)] ( page 4)

You cannot charge dry cell batteries even if you put the headphones on the transmitter.

Operating time for the dry cell battery

*

1

At 1 kHz, 1 mW + 1 mW output.

*

2

Operating times may differ depending on the temperature of the surrounding environment and operating

conditions.

Battery type Operating time *

1

Panasonic Alkaline batteries Approx. 6 hours *

2
