2
EUR7720X50 (NV-VP33 / NV-VP28)
EUR7720X70 (NV-VP23)
Dispose of batteries, packaging material and the unit according to
statutory regulations. They must not be thrown into the household refuse.
Inserting Batteries
The batteries last for about a year, depending on how often you use
the remote control unit.
!
Do not mix old with new batteries, or batteries of different types.
!
Only use batteries without any harmful substances (lead, cadmium, mercury).
!
Do not use rechargeable type batteries.
!
Remove the batteries if the remote control unit will remain unused
for longer periods of time.
!
Do not heat or short-circuit the batteries. Immediately remove
used-up batteries and replace with batteries of type AA, UM3 or R6.
!
Be sure to put in the batteries the right way round (+ and -).
Matsushita Electric Industrial Co., Ltd.
http://www.panasonic.co.jp/global/
Dear customer
Thank you for your trust and your decision to purchase this top-quality device. Panasonic is
one of the leading manufacturers of entertainment electronics devices. We are sure that you
will be completely satisfied with this device.
AC Mains Lead
RJA0043-1C
Batteries
AA, UM3 or R6
Operating Instructions
Guarantee Card
A
ccessories
Included
THIS UNIT IS INTENDED FOR USE IN MODERATE CLIMATES.
This product may receive radio interference caused by mobile telephones
during use. If such interference is apparent, please increase separation
between the product and the mobile telephone.
CAUTION!
!
DO NOT INSTALL OR PLACE THIS UNIT IN A BOOKCASE, BUILT-IN
CABINET OR IN ANOTHER CONFINED SPACE. ENSURE THE UNIT IS
WELL VENTILATED. TO PREVENT RISK OF ELECTRIC SHOCK OR FIRE
HAZARD DUE TO OVERHEATING, ENSURE THAT CURTAINS AND
ANY OTHER MATERIALS DO NOT OBSTRUCT THE VENTILATION VENTS.
!
DO NOT OBSTRUCT THE UNIT’S VENTILATION OPENINGS WITH
NEWSPAPERS, TABLECLOTHS, CURTAINS, AND SIMILAR ITEMS.
!
DO NOT PLACE SOURCES OF NAKED FLAMES, SUCH AS LIGHTED
CANDLES, ON THE UNIT.
!
DISPOSE OF BATTERIES IN AN ENVIRONMENTALLY FRIENDLY
MANNER.
The socket outlet shall be installed near the equipment and easily accessible or
the mains plug or an appliance coupler shall remain readily operable.
CAUTION!
THIS PRODUCT UTILIZES A LASER. USE OF CONTROLS OR
ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN
THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION
EXPOSURE. DO NOT OPEN COVERS AND DO NOT REPAIR YOURSELF.
REFER SERVICING TO QUALIFIED PERSONNEL.
WARNING:
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR PRODUCT DAMAGE,
DO NOT EXPOSE THIS APPARATUS TO RAIN, MOISTURE, DRIPPING OR
SPLASHING AND THAT NO OBJECTS FILLED WITH LIQUIDS, SUCH AS
VASES, SHALL BE PLACED ON THE APPARATUS.
Voltage: Only use power sources complying with the specifications for
this device.
AC mains lead protection: Ensure the AC mains lead is connected
correctly and not damaged. Poor connection and lead damage can
cause fire or electric shock.
Service: Never attempt to repair this unit by yourself. If a problem
occurs that is not described in these operating instructions,
disconnect the power supply and contact your dealer or an authorised
after sales service centre.
RF Coaxial cable
Audio/Video cable
K2KA6CA00001
Remote control
ENTER
1
2
3
4
5
6
7
8
9
0
-/--
CH
AV
VHS/DVD
TV
AUDIO
VOLUME
OPERATION
SELECT
CH
DVD
VHS
TRACKING/V-LOCK
ShowView
INPUT
REPEAT
CANCEL/RESET
INDEX/SKIP
SLOW/
SEARCH
REW
FF
PLAY
STOP
PAUSE
DIRECT NAVIGATOR
MENU
PLAYLIST
TOP MENU
FUNCTIONS
EXIT
RETURN
PROG/CHECK
I-TIMER
PLAY MODE
SETUP
TIMER
DVD-RAM
DUBBING
REC MODE
REC
EXT LINK
OFF TIMER
CINEMA MODE
VHS STATUS
DVD STATUS
QUICK OSD
QUICK REPLAY
MANUAL SKIP
Panasonic
VHS/DVD/TV
EUR7720X50
PROG
PLAY
JET REW
A B
SLOW
>
=
10
