For Your Safety

- 2 -

Earthing Instructions

WARNING: THIS APPLIANCE MUST BE EARTHED.

IMPORTANT: The wires in this mains lead are

coloured in accordance with the following code:

Green-and-yellow: Earth

Blue: Neutral

Brown: Live

As the colours of the wire in the mains lead of this

appliance may not correspond with the coloured

markings identifying the terminals, proceed as

follows:

The wire which is coloured GREEN-AND-YELLOW

must be connected to the terminal which is marked

with the letter E or by the Earth symbol or

coloured GREEN or GREEN-AND-

YELLOW.

The wire which is coloured BLUE must be connected

to the terminal which is marked with the letter N or

coloured BLACK.

The wire which is coloured BROWN must be

connected to the terminal which is marked with the

letter L or coloured RED.

Voltage & Power

The voltage used must be the same as specified on

this microwave oven. Using a higher voltage than that

which is specified is dangerous and may result in a

fire or other type of accident causing damage.

Do not immerse cord, plug or oven in water. Keep

cord away from heated surfaces. Do not let cord hang

over the edge of table or worktop. Do not plug your

oven in via an extension cable as this can be

dangerous. It is important to plug the oven directly

into a wall socket.

The back of the appliance heats up during use. Do

not allow the cord to be in contact with the back of the

appliance or cabinet surface.

CAUTION:

The rear panel of model NE-3280 can become hot

- take care when handling.

Unpacking Your Oven

1. Examine Your Oven

Unpack the oven, remove all packing material, and

examine the oven for any damage such as dents,

broken door latches or cracks in the door. Notify

dealer immediately if the unit is damaged. DO

NOT install it if the unit is damaged.

2. Guarantee Card

Fill out and post the pre-addressed guarantee

card.

3. Cord

If the supply cord of this appliance is damaged, it

must be replaced by the manufacturer or its

service agent or a similarly qualified person in

order to avoid a hazard.

4. Door Seal

The appliance should be inspected for damage to

the door seals and door seal areas and if these

areas are damaged the appliance should not be

operated until it has been repaired by service

technician trained by the manufacturer.

5. Removal of protective film

A protective film is used to prevent scratching of

the outer case during transportation. Peel this film

off before installation or use.

6. Attach caution label

Before using this appliance, please attach the

caution label to top of appliance.

WARNING: (NE-3280/NE-2180/NE-1880)

This appliance must be connected to an outlet

having a rated current greater than 13 amps.

A 13 amp, B.S. 1363 plug is, therefore, not

suitable. It is recommended that this unit should be

installed by a professional contractor, as the

installation wiring should be in accordance with

current IEE regulation and connected to the circuit

with all poles having a disconnection of at least 3 mm.

When the mains lead is connected to supply

terminals , please observe the wiring code as

shown below. If in doubt, please consult a qualified

electrician.

For model NE-1540

This appliance is supplied with a moulded three

pin mains plug for your safety and convenience. A

13 amp fuse is fitted in this plug. Should the fuse

need to be replaced, please ensure that the

replacement fuse has a rating of 13 amps and that

it is approved by ASTA or BSI to BS1362. Check

for the ASTA mark

or the BSI mark on the body of the fuse.

If the plug contains a removable fuse cover, you

must ensure that it is refitted when the fuse is

replaced. If you lose the fuse cover, the plug must

not be used until a replacement cover is obtained.

A replacement fuse cover can be purchased from

your local Panasonic Dealer.

HOW TO REPLACE THE FUSE

Open the fuse compartment with a

screwdriver and replace the fuse.

IF THE FITTED MOULDED PLUG IS

UNSUITABLE FOR THE SOCKET OUTLET

THEN THE FUSE SHOULD BE REMOVED AND

THE PLUG CUT OFF AND DISPOSED OF

SAFELY AND AN APPROPRIATE ONE FITTED.

THERE IS A DANGER OF SEVERE

ELECTRICAL SHOCK IF THE CUT OFF PLUG IS

INSERTED INTO ANY 13 AMP SOCKET.

If a new plug is to be fitted, please observe the

wiring code as shown below. If in any doubt,

please consult a qualified electrician.
