7

ENGLISH

NOTE :

Symptom Check

Heating/Cooling operation is not working

efciently.

• Set the temperature correctly.

• Close all doors and windows.

• Clean or replace the lters.

• Clear any obstruction at the air inlet and air outlet vents.

Noisy during operation. • Check if the unit has been installed at an incline.

• Close the front panel properly.

Remote control does not work.

(Display is dim or transmission signal is weak.)

• Insert the batteries correctly.

• Replace weak batteries.

The unit does not work. • Check if the circuit breaker is tripped.

• Check if timers have been set.

The unit does not receive the signal from the

remote control.

• Make sure the receiver not obstructed.

• Certain uorescent lights may interfere with signal transmitter. Please

consult your nearest dealer.

Symptom Cause

Mist emerges from indoor unit. • Condensation effect due to cooling process.

Water owing sound during operation. • Refrigerant ow inside the unit.

The room has a peculiar odour. • This may due to damp smell emitted by the wall, carpet, furniture or

clothing.

Indoor fan stops occasionally during automatic

fan speed setting.

• This helps to remove the surrounding odours.

Operation is delayed a few minutes after

restart.

• The delay is a protection to the unit’s compressor.

Outdoor unit emits water/steam. • Condensation or evaporation occurs on pipes.

The unit operates automatically when power is

resumed after a power failure.

• It is the Auto Restart function of the unit. Operation will be restarted

automatically under the previous operation mode and airow direction

when power is resumed as the operation is not stopped by remote control.

• To cancel the Auto Restart Control, please contact with authorized

distributor.

Power indicator blinks during operation and

the indoor fan is stopped.

• The unit is in defrost mode, and the melted frost is drained from the

outdoor unit.

Indoor fan stops occasionally during heating

operation.

• To avoid unintended cooling effect.

Power indicator blinks before the unit is

switched on.

• This is a preliminary step in preparation for the operation when the ON

timer has been set.

Cracking sound during operation. • Changes of temperature cause the expansion/contraction of the unit.

The following symptoms do not indicate malfunction.

Check the following before calling for servicing.

The unit stops and the timer indicator blinks.

SELECTSELECT

CHECKCHECK ERRORERRORRESETRESET RESETRESET

SET/CANCELSET/CANCEL

POWERFUL / QUIETPOWERFUL / QUIET

1

Press for 5

seconds.

3

Press for 5 seconds

to quit checking.

2

Press until you hear

beep sound, then jot

down the error code.

• Turn the unit off and reveal the error code to your nearest dealer.

TROUBLESHOOTING TROUBLESHOOTING

• The unit may be operable

(with 4 beeps) on a limited

basis, depending on the

error.

FOR SEASONAL INSPECTION AFTER EXTENDED

NON-USE

• Checking of remote control batteries.

• No obstruction at air inlet and air outlet vents.

• After 15 minutes of operation, it is normal to have the

following temperature difference between air inlet and air

outlet vents:

Cooling: ≥ 8°C Heating: ≥ 14°C

NON SERVICEABLE CRITERIAS

TURN OFF POWER SUPPLY AND UNPLUG then CALL

Authorized Distributor under the following conditions:

• Abnormal noise during operation.

• Water/foreign particles have entered the remote control.

• Water leaks from Indoor unit.

• Circuit breaker switches off frequently.

• Power cord becomes unnaturally warm.

• Switches or buttons are not functioning properly.

• The timer indicator blinks and the unit can not be operated.

FOR EXTENDED NON-USE

• Activate heat mode for 2~3 hours to thoroughly dry the unit.

• Turn off the power supply and unplug.

• Remove the remote control batteries.

F565951-EN1.indd 7 2008-3-24 11:27:57
