•Keeptheventsofthesprayguncleanatalltimes.Ifpossible,preventforeign

matterfromenteringthevents.

•Ifthebodyofthespraygunrequirescleaning,donotusesolventsbutamoist

softclothonly.Neverletanyliquidgetinsidethegunbody;neverimmerseany

partofthespraygunintoaliquid.

Note: Ozito Industries will not be responsible for any damage or injuries

caused by the repair of the sander by an unauthorised person or by mishandling

of the spray gun.

MAINTENANCE

DESCRIPTION OF SYMBOLS

CARING FOR THE ENVIRONMENT

TROUBLE SHOOTING

Powertoolsthatarenolongerusableshouldnotbedisposedof

with household waste but in an environmentally friendly way. Please

recycle where facilities exist. Check with your local council authority

forrecyclingadvice.

Recyclingpackagingreducestheneedforlandllandrawmaterials.

Reuse of recycled material decreases pollution in the environment.

Pleaserecyclepackagingwherefacilitiesexist.Checkwithyour

localcouncilauthorityforrecyclingadvice.

Filter (pack 2) SPSPG300-03

ValveSpringAssy.    SPSPG300-08

Nozzle Kit SPSPG300-17K

Suction Tube Assy. SPSPG300-24

Pot SPSPG300-25

Spare parts can be ordered from the Special Orders Desk

at your local Bunnings Warehouse.

For further information, or any parts not listed here, visit

www.ozito.com.au or contact Ozito Customer Service:

Australia 1800 069 486

New Zealand 0508 069 486

E-mail: [email protected]

SPARE PARTS

Problem Cause Remedy

Little or no material

ow

Nozzle/Suctiontubeclogged

Sprayregulatordialtolow

Suction tube loose

No pressure build up in paint pot

Airlterclogged

Clean

Increaseregulatordial

Insert

Tightenpaintpot

Clean or replace

Materialleaking Nozzle loose

Nozzle worn

Material build up on air cap and nozzle

Tighten

Replace

Clean

Atomization is too

coarse

Viscosityofmaterialtoohigh

Materialvolumetoolarge

Nozzleclogged

Airlterclogged

Too little pressure build up in container

Thin material

Decreasesprayregulator

dial

Clean

Clean or replace

Tightenpaintpot

Spray jet pulsates Materialinpaintpotrunningout

Airlterclogged

Rell

Clean or replace

Patternrunsorsags Applyingtomuchmaterial Decreasesprayregulator

dial or increase movement

speed

Too much overspray Gun too far from spray object

Too much material applied

Reduce distance

Decreasesprayregulator

dial

Patternisverylight

and splotchy

Movingthesprayguntofast Decreasesprayregulator

dial or decrease movement

speed

V Volts Hz Hertz

~ Alternating current W Watts

BAR Pressure rating

Read Instruction manual

Warning

Double insulated

Wear eye, breathing,

ear protection

Do not use in raining

/min Revolutions or r

Regulatory Compliance

Mark (RCM)

eciprocation per minute

ºC Degrees Celsius

WARNING! ENSURE THE TOOL IS DISCONNECTED FROM THE

POWER SUPPLY BEFORE PERFORMING ANY OF THE FOLLOWING

OPERATIONS.

1 Unscrew the paint pot and return

remainingmaterialintoacontainer.

1 Unscrew the air cap nut to remove

the air cap.

3 Remove and dismantle the suction

tubebyturningclockwise.

5 Takenoteofthe3holesonthesuctiontube,ifblockedcleanusingthe

providedcleaningneedle.

3 Clean the paint pot and suction

tube with a brush and then screw

thepotbackintothegun.

5 Remove the paint pot and empty

anyremainingsolvent.

Aftereachuseitisessentialthatthesprayguniscleanedthoroughly.Thiswill

preventanyblockagesoccurringandprovidereliableperformancewhenyounext

come to use it.

2 Fill the paint pot with solvent or

water. Note: Only use solvents with

a ash point over 21°C

2 Turn both quick release knobs to

remove the paint head.

4 Dipaclothinsolventorwaterandcleantheaircap,nozzle,gunhousing,rear

of the paint head and suction tube.

6 Priortostoringthespraygun,ensureitiscompletelydry.

4 Plugthegunbackinandspraythe

solvent into a container. Repeat

until clear solvent comes out.

Cleaning
