Sparking visible through the housing air vents

A small amount of sparking may be visible through the housing vents.

This is normal and does not indicate a problem.

Excessive sparking visible through the housing air vents

and/or the drill failing to operate

May indicate the carbon brushes have worn out and need to be

replaced. Carbon brushes should only be replaced by a qualied

electrician or power tool repairer.

MAINTENANCE

DESCRIPTION OF SYMBOLS

CARING FOR THE ENVIRONMENT

TROUBLESHOOTING

Power tools that are no longer usable should not be disposed of

with household waste but in an environmentally friendly way. Please

recycle where facilities exist. Check with your local council authority

for recycling advice.

Recycling packaging reduces the need for landll and raw materials.

Reuse of recycled material decreases pollution in the environment.

Please recycle packaging where facilities exist. Check with your

local council authority for recycling advice.

V Hz

~ W

/bpm

ø

/min

n

o

Volts

Alternating current

Revolutions or

reciprocation per minute

Impact rate

Double insulated

Warning

Hertz

Watts

No load speed

Diameter

Regulator compliance mark

• Keep the vents on the drill clean at all times, if possible, prevent foreign matter

from entering the vents.

• After each use, blow air through the drill housing to ensure it is free from all

dust particles which may build up. Build up of dust particles may cause the

drill to overheat and fail.

• If the enclosure of the drill requires cleaning, do not use solvents. Use a moist,

soft cloth only. Never let any liquid get inside the drill; never immerse any part

of the drill into a liquid.

Carbon Brushes

When the carbon brushes wear out, the drill will

spark and/or stop. Discontinue use as soon as this

happens. Carbon brushes should be replaced prior

to recommencing use of the drill. They are a wearing

component of the drill and therefore not covered

under warranty. Continuing to use the drill when

carbon brushes need to be replaced may cause

permanent damage to the drill. Carbon brushes

will wear out after many uses. When the carbon brushes need to be replaced,

take the drill to an electrician or a power tool repairer for a quick and low cost

replacement. Always replace both carbon brushes at the same time.

Note: Ozito Industries will not be responsible for any damage or injuries

caused by the repair of the drill by an unauthorised person or by mishandling

of the drill.

Spare parts can be ordered from the Special Orders Desk

at your local Bunnings Warehouse.

For further information, or any parts not listed here, visit

www.ozito.com.au or contact Ozito Customer Service:

Australia 1800 069 486

New Zealand 0508 069 486

E-mail: [email protected]

SPARE PARTS

Keyless Chuck SPHDR3000-02

Brush Holder SPHDR3000-18

Carbon Brushes SPHDR3000-19

Handle Assembly SPHDR3000-30

Switch SPHDR3000-34

OPERATION (cont.)

Helpful Tips

When drilling hard, smooth surfaces, use a centre punch to mark the desired

hole location. This measure will prevent the drill bit from slipping off centre as

you start the hole. However, the variable speed feature allows you to start holes

without centre punching. To accomplish this, operate the drill at a low speed

until you start the hole.

When drilling metals, use light oil on the drill bit to keep it from overheating. The

oil will prolong the life of the bit and increase drilling action.

If the bit jams in the work piece or if the drill stalls, stop the tool immediately.

Remove the bit from the work piece and determine the reason for jamming.
