1995 Nikon Corporation

English

Thank you for purchasing a Nikon product. The AF Nikkor 85 mm f/1.4D IF lens features a rounded

diaphragm for natural bokeh, Close-Range Correction (CRC) for sharp images at close range, and

an inner focus mechanism for quick focus. Used with Nikon autofocus cameras (F3AF excluded), it

supports autofocus and can supply subject distance information to compatible cameras. Manual

focus is also supported. Before using this product, please carefully read both these instructions

and the camera manual so you can get the most out of your lens now and for years to come.

■

Parts of the Lens

q Aperture ring

w Meter coupling guide

e CPU contacts

r Aperture-direct-readout scale

t Aperture scale

y Aperture indexing post

u Aperture index mark

i Focus distance indicator window

o A-M mode ring release button

!0 Infrared compensation index (white)

!1 Focus distance indicator

!2 Focus distance mark

!3 Depth-of- eld indicators

!4 A-M mode index

!5 Minimum aperture lock lever

!6 Focus ring

!7 A-M mode ring

■

For Your Safety

CAUTIONS

• Do not disassemble. Touching the internal parts of the camera or lens could result in injury. In the event of

malfunction, the product should be repaired only by a qualiﬁ ed technician. Should the product break

open as the result of a fall or other accident, remove the camera battery and/or disconnect the AC adapter

and then take the product to a Nikon-authorized service center for inspection.

• Turn the camera o immediately in the event of malfunction. Should you notice smoke or an unusual smell com-

ing from the equipment, immediately unplug the AC adapter and remove the camera battery, taking care

to avoid burns. Continued operation could result in ﬁ re or injury. After removing or disconnecting the

power source, take the equipment to a Nikon-authorized service center for inspection.

• Do not use in the presence of  ammable gas. Operating electronic equipment in the presence of ﬂ ammable gas

could result in explosion or ﬁ re.

• Do not look at the sun through the lens or the camera view nder. Viewing the sun or other bright light source

through the lens or viewﬁ nder could cause permanent visual impairment.

• Keep out of reach of children. Particular care should be taken to prevent infants from putting the batteries or

other small parts into their mouths.

• Observe the following precautions when handling the lens and camera:

- Keep the lens and camera dry. Failure to observe this precaution could result in ﬁ re or electric shock.

- Do not handle the lens or camera with wet hands. Failure to observe this precaution could result in

electric shock.

- Keep the sun well out of the frame when shooting backlit subjects. Sunlight focused into the camera

when the sun is in or close to the frame could cause a ﬁ re.

- If the lens will not be used for an extended period, attach the front and rear lens caps and store the lens

out of direct sunlight. If left in direct sunlight, the lens could focus the sun’s rays onto ﬂ ammable objects,

causing ﬁ re.

■

Notices

• Keep the CPU lens contacts clean and be careful not damage the CPU contacts.

• Do not attach the following accessories directly to the lens: PK-1 or PK-11 auto extension rings or BR-4 or

BR-2 auto ring (the PK-11A and BR-6 can be used in place of the PK-11 and BR-4, respectively). Failure to

observe this precaution will result in damage to the CPU contacts or other parts of the lens. Other lens

accessories may not be compatible with the camera; be sure to consult the camera manual before use.

• The lens can not be used with the DX-1 viewﬁ nder for Nikon F3AF cameras.

■

Focusing Screens

The cameras in the “Focusing Screens” table support a variety of focusing screens for use with

di erent lenses or in di erent situations. The screens listed in the table are suited for use with this

lens.

When using B2/B3, E2/E3, or K2/K3 screens with cameras not listed in this table, refer respectively

to columns B, E, or K.

Screen

Camera

EC-B

A/L

 

F5+ DP-30

  

F5+ DA-30

   



(+0.5)

F4+ DP-20/F4+ DA-20



  

Screen

Camera

K/P



F5+ DP-30



F5+ DA-30



F4+ DP-20/F4+ DA-20



 



: Recommended.

: Vignetting visible in viewﬁ nder (photographs are not aﬀ ected).

: Split-screen display does not improve focus accuracy.

( ): Figures in parentheses give the exposure compensation for center-weighted metering. Select

“Other screen” for Custom Setting b6 (“Screen comp.”) when adjusting exposure compensation

for the F6; note that with screens other than B or E, “Other screen” must be selected even when the

value for exposure compensation is 0. Users of the F5 and F4 can adjust exposure compensation

using Custom Setting 18 or the focusing screen exposure compensation dial, respectively; see the

camera manual for details.

Empty cell: Not suited to use with this lens. Note that type M screens can however be used for photomicrog-

raphy and macro photography at magniﬁ cations of 1 : 1 or higher.

■

Focus

This lens supports A-M mode selection. To choose the A-M mode, rotate the A-M mode ring while

pressing the A-M mode ring release button. Select A for autofocus and M for manual focus. There

is no need to use the camera focus mode selector.

■

The Minimum Aperture Lock Lever (Figure A)

Lock aperture at f/16 when shooting in programmed auto or shutter-priority auto mode.

Rotate the aperture ring to the minimum aperture setting (f/16).

Slide the lock lever toward the aperture ring so that the white dot on the lock lever aligns

with the orange dot.

To release the lock, slide the lever in the opposite direction.

■

Lens Care

• Use a blower to remove dust and lint from the lens surfaces. To remove smudges and  nger-

prints, apply a small amount of ethanol or lens cleaner to a soft, clean cotton cloth or lens-

cleaning tissue and clean from the center outwards using a circular motion, taking care not to

leave smears or touch the glass with your  ngers.

• A lens hood or NC  lter can be used to protect the front lens element.

• Attach the front and rear caps when the lens is not in use.

• Keep the lens dry. Rusting of the internal mechanism can cause irreparable damage.

• If the lens will not be used for an extended period, store it in a cool, dry location to prevent mold

and rust. Do not store in direct sunlight or with naphtha or camphor moth balls.

• Leaving the lens in extremely hot locations could damage or warp parts made from reinforced

plastic.

■

Compatible Accessories

• 77 mm screw-on  lters

• Flexible Lens Pouch CL-0915

■

Speciﬁ cations

Focal length

Focal length 85 mm

Maximum aperture

Maximum aperture f/1.4

Lens construction

Lens construction 9 elements in 8 groups

Angle of view

Angle of view 28° 30’

Focus distance indicator

Focus distance indicator Graduated in meters and feet from 0.85 m (3 ft) to inﬁ nity (∞)

Distance information

Distance information Output to camera

Aperture scale

Aperture scale f/1.4 to f/16 on both standard and aperture-direct-readout scales

Minimum aperture lock

Minimum aperture lock Provided

Diaphragm

Diaphragm Fully automatic

Metering

Metering • CPU/AI cameras: Full aperture

• Other cameras: Minimum aperture

Mount

Mount Nikon bayonet mount

Filter-attachment size

Filter-attachment size 77 mm (P=0.75 mm)

Dimensions

Dimensions Approx. 80 mm maximum diameter × 72.5 mm (distance from camera lens

mount  ange); overall length is approx. 82 mm

Weight

Weight Approx. 550 g (19.4 oz)

Nikon reserves the right to change the speciﬁ cations of the hardware described in this manual at any time and

without prior notice.

Figure A Minimum aperture lock lever

■

Depth of Field (Metric)

(m)

Focus

distance

Depth of  eld

Reproduction

ratio

f/1.4

f/2

f/2.8

f/4

f/5.6

f/8

f/11

f/16

0.85

0.85 0.854 – 0.846 0.855 – 0.845 0.857 – 0.843 0.864 – 0.840 0.864– 0.836 0.871 – 0.830 0.879 – 0.823 0.893 – 0.812

1/8.77

1.0

1.0 1.01 – 0.995 1.01 – 0.993 1.01 – 0.990 1.01 – 0.986 1.02 – 0.980 1.03 – 0.972 1.04 – 0.962 1.06 – 0.945

1/10.6

1.2

1.2 1.21 – 1.19 1.21 – 1.19 1.22 – 1.18 1.22 – 1.18 1.23 – 1.17 1.25 – 1.16 1.26 – 1.14 1.30 – 1.12

1/13.0

1.5

1.5 1.51 – 1.49 1.52 – 1.48 1.53 – 1.48 1.54 – 1.47 1.55 – 1.45 1.58 – 1.43 1.61 – 1.41 1.66 – 1.37

1/16.5

2 2.02 – 1.98 2.03 – 1.97 2.05 – 1.95 2.07 – 1.94 2.10 – 1.91 2.14 – 1.88 2.20 – 1.83 2.31 – 1.77

1/22.5

3 30.6 – 2.95 3.08 – 2.92 3.11 – 2.90 3.16 – 2.85 3.23 – 2.80 3.35 – 2.72 3.50 – 2.63 3.79 – 2.49

1/34.3

5 5.16 – 4.85 5.23 – 4.79 5.33 – 4.71 5.49 – 4.59 5.71 – 4.45 6.08 – 4.25 6.63 – 4.03 7.79 – 3.70

1/57.8

10 10.7 – 9.41 11.0 – 9.17 11.5 – 8.88 12.2 – 8.47 13.4 – 7.98 15.7 – 7.35 20.0 – 6.69 37.2 – 5.83

1/116.7

∞

∞ 155 – ∞ 109 – ∞ 78 – ∞ 54 – ∞ 39 – ∞ 27 – ∞ 20 – ∞ 14 – ∞

1/∞

■

Close-up Photography (Metric)

(cm)

Accessory

Close-up photography

Close-up photography (lens reversed)

Reproduction ratio

Subject  eld

Focus distance

Reproduction ratio

Subject  eld

Focus distance

PK-Ring

1/10.6 – 1/1.4 25.5 × 38.3 – 3.25 × 4.87 105 – 31.2 –––

PN ring

PN ring 1/1.6 – 1/1.3 3.89 × 5.83 – 0.98 × 1.47 32.9 – 30.96 –––

PB-4 or PB-5 bellows attachment

PB-4 or PB-5 bellows attachment 1/2.0 – 2.2 4.74 × 7.12 – 1.1 × 1.65 35.0 – 35.5 –––

PB-6 bellows attachment

PB-6 bellows attachment 1/1.8 – 2.4 4.25 × 6.38 – 0.98 × 1.47 33.7 – 37.24 –––

PB-6E extension bellows

1/1.8 – 5.20 4.25 × 6.38 – 0.47 × 0.70 33.7 – 56.99 –––

1. Can not be used when lens is reversed.

2. First ﬁ gure is for PK-11A when used alone, remaining ﬁ gures for rings PK-11A through PK-13, PK-11 through PK-13, or PK-1 through PK-3 used together. Note the

PK-11 and PK-1 can not be attached directly to the lens.

■

Depth of Field (Imperial)

(ft)

Focus

distance

Depth of  eld

Reproduction

ratio

f/1.4

f/2

f/2.8

f/4

f/5.6

f/8

f/11

f/16

3 ft ⁄ in. –

2 ft 11 ⁄ in.

3 ft ⁄ in. –

2 ft 11 ⁄ in.

3 ft ⁄ in. –

2 ft 11 ⁄ in.

3 ft ⁄ in. –

2 ft 11 ⁄ in.

3 ft ⁄ in. –

2 ft 11 ⁄ in.

3 ft ⁄ in. –

2 ft 11 ⁄ in.

3 ft 1 ⁄ in. –

2 ft 10 ⁄ in.

3 ft 2 ⁄ in. –

2 ft 10 ⁄ in.

1/9.5

4 ft ⁄ in. –

3 ft 11 ⁄ in.

4 ft ⁄ in. –

3 ft 11 ⁄ in.

4 ft ⁄ in. –

3 ft 11 ⁄ in.

4 ft ⁄ in. –

3 ft 11 ⁄ in.

4 ft 1 ⁄ in. –

3 ft 11 ⁄ in.

4 ft 1 ⁄ in. –

3 ft 10 ⁄ in.

4 ft 2 ⁄ in. –

3 ft 9 ⁄ in.

4 ft 3 ⁄ in. –

3 ft 8 ⁄ in.

1/13.2

5 ft ⁄ in. –

4 ft 11 ⁄ in.

5 ft ⁄ in. –

4 ft 11 ⁄ in.

5 ft 1 ⁄ in. –

4 ft 10 ⁄ in.

5 ft 1 ⁄ in. –

4 ft 10 ⁄ in.

5 ft 2 ⁄ in. –

4 ft 10 in.

5 ft 3 ⁄ in. –

4 ft 9 ⁄ in.

5 ft 4 ⁄ in. –

4 ft 8 ⁄ in.

5 ft 6 ⁄ in. –

4 ft 6 ⁄ in.

1/16.8

7 ft 1 ⁄ in. –

6 ft 10 ⁄ in.

7 ft 1 ⁄ in. –

6 ft 10 ⁄ in.

7 ft 2 ⁄ in. –

6 ft 9 ⁄ in.

7 ft 3 ⁄ in. –

6 ft 9 ⁄ in.

7 ft 4 ⁄ in. –

6 ft 8 in.

7 ft 6 ⁄ in. –

6 ft 6 ⁄ in.

7 ft 9 ⁄ in. –

6 ft 4 ⁄ in.

8 ft 2 ⁄ in. –

6 ft 1 ⁄ in.

1/24.0

10 ft 2 in. –

9 ft 9 ⁄ in.

10 ft 3 in. –

9 ft 8 ⁄ in.

10 ft 4 in. –

9 ft 6 in.

10 ft 6 in. –

9 ft 6 ⁄ in.

10 ft 9 in. –

9 ft 3 ⁄ in.

11 ft 2 in. –

9 ft ⁄ in.

11 ft 8 in. –

8 ft 8 ⁄ in.

12 ft 8 in. –

8 ft 3 ⁄ in.

1/34.8

15 ft 5 in. –

14 ft 7 in.

15 ft 7 in. –

14 ft 5 in.

15 ft 10 in. –

14 ft 2 in.

16 ft 3 in. –

13 ft 10 in.

16 ft 11 in. –

13 ft 5 in.

17 ft 10 in. –

12 ft 11 in.

29 ft 3 in. –

12 ft 3 in.

22 ft 3 in. –

11 ft 4 in.

1/52.8

31 ft 10 in. –

28 ft 4 in.

32 ft 8 in. –

27 ft 8 in.

33 ft 11 in. –

26 ft 10 in.

35 ft 11 in. –

25 ft 9 in.

39 ft –

24 ft 4 in.

44 ft 10 in. –

22 ft 6 in.

55 ft 3 in. –

20 ft 8 in.

90 ft 1 in. –

18 ft 1 in.

1/106.6

∞

∞ 508 ft – ∞ 356 ft – ∞ 254 ft – ∞ 178 ft – ∞ 127 ft – ∞ 89 ft – ∞ 65 ft – ∞ 44 ft – ∞

1/∞

■

Close-up Photography (Imperial)

(in.)

Accessory

Close-up photography

Close-up photography (lens reversed)

Reproduction ratio

Subject  eld

Focus distance

Reproduction ratio

Subject  eld

Focus distance

PK-Ring

1/10.6 – 1/1.4 10.04 × 15.08 – 1.28 × 1.92 41.34 – 12.28 –––

PN ring

PN ring 1/1.6 – 1/1.3 1.53 × 2.30 – 0.39 × 0.58 12.95 – 12.19 –––

PB-4 or PB-5 bellows attachment

PB-4 or PB-5 bellows attachment 1/2.0 – 2.2 1.87 × 2.28 – 0.43 × 0.58 13.78 – 13.98 –––

PB-6 bellows attachment

PB-6 bellows attachment 1/1.8 – 2.4 1.67 × 2.51 – 0.39 × 0.58 13.27 – 14.66 –––

PB-6E extension bellows

1/1.8 – 5.20 1.67 × 2.51 – 0.19 × 0.28 13.27 – 22.44 –––

1. Can not be used when lens is reversed.

2. First ﬁ gure is for PK-11A when used alone, remaining ﬁ gures for rings PK-11A through PK-13, PK-11 through PK-13, or PK-1 through PK-3 used together. Note the

PK-11 and PK-1 can not be attached directly to the lens.

Ladda ner bruksanvisning i Engelska (PDF, 0.48 MB)

(Tänk på miljön och skriv endast ut denna bruksanvisning om det verkligen är nödvändigt)

Betyg

Berätta vad du tycker om Nikon Nikkor AF 85mm f/1.4D IF Objektiv genom att betygsätta den. Vill du dela med dig av dina åsikter om denna produkt eller ställa en fråga? Lämna en kommentar nederst på sidan.

Är du nöjd med Nikon Nikkor AF 85mm f/1.4D IF Objektiv?
Ja Nej

Bli den första personen som betygsätter denna produkt

0 röster

Delta i konversationen om denna produkt

Här kan du dela vad du tycker om Nikon Nikkor AF 85mm f/1.4D IF Objektiv. Om du har en fråga, läs först noggrant igenom manualen. Att begära en manual kan göras genom att använda vårt kontaktformulär.

Mer om denna bruksanvisning

Vi förstår att det är trevligt att ha en pappersbruksanvisning för din Nikon Nikkor AF 85mm f/1.4D IF Objektiv. Du kan alltid ladda ner bruksanvisningen från vår hemsida och skriva ut den själv. Om du vill ha en originalbruksanvisning rekommenderar vi att du kontaktar Nikon. De kanske kan tillhandahålla en originalbruksanvisning. Letar du efter bruksanvisningen för din Nikon Nikkor AF 85mm f/1.4D IF Objektiv på ett annat språk? Välj ditt föredragna språk på vår hemsida och sök efter modellnumret för att se om vi har det tillgängligt.

Specifikationer

Märke	Nikon
Modell	Nikkor AF 85mm f/1.4D IF
Kategori	Objektiven
Filtyp	PDF
Filstorlek	0.48 MB

Alla bruksanvisningar för Nikon Objektiven
Fler bruksanvisningar för Objektiven

Vanliga frågor om Nikon Nikkor AF 85mm f/1.4D IF Objektiv

Vårt supportteam söker efter användbar produktinformation och svar på vanliga frågor. Om du hittar en felaktighet bland våra vanliga frågor uppskattar vi om du meddelar oss detta via vårt kontaktformulär.

Vad står ”f” för på kameraobjektivet? Verifierad

F-värdet används för att säga hur stor ett objektivs bländare är i förhållande till brännvidden. Bländaren är ett hål i kamerans objektiv. Genom att bestämma storleken på hålet påverkar du hur mycket ljus som når sensorn. Ju större bländare, desto mer ljus.

Detta hjälpte (30) Läs mer
