Bruksanvisning Miomare IAN 312113 Blandare

Bruksanvisning

5 GB

Basin mixer tap

Introduction

We congratulate you on the purchase of your new

product. You have chosen a high quality product.

Familiarise yourself with the product before using it

for the first time. In addition, please carefully refer

to the operating instructions and the safety advice

below. Only use the product as instructed and only

for the indicated field of application. Keep these in-

structions in a safe place. If you pass the product on

to anyone else, please ensure that you also pass on

all the documentation with it.

Proper use

This product is suitable for all pressure-tight hot water

systems such as central heating boilers, instantaneous

water heaters, pressurised boilers and the like. It is

not suitable for low-pressure water heaters such as

wood or coal burning bath geysers, oil or gas bath

geysers, open electrically heated water tanks. If in

doubt please seek the advice of a plumber or heating

engineer. Any use other than that described here or

modification to the product is not permitted and may

lead to damage to persons or property. There is

also the risk of injury and loss of life. The product is

intended for personal use only and not for medical or

commercial use. The manufacturer accepts no liability

for loss or damage arising from improper use.

Description of parts

1

1 Flexible hose cold water

2

1 Flexible hose hot water

3

1 Plastic washer

4

1 Metal washer

5

1 Metal rod

6

1 Plastic nut

7

1 Upper eccentric section

8

1 Upper Eccentric seals (foam)

9

1 Lower Eccentric seals (plastic)

10

1 Lower eccentric section

11

1 Eccentric nut

12

1 Knee joint bar

13

1 Eccentric joint

14

1 Pull-rod (Part 2)

15

1 Pull-rod (Part 1)

16

1 Control lever

17

1 Mixer nozzle

18

1 Locking screw

19

1 Hot / cold label

20

1 Cartridge end ring

21

1 Cartridge locking ring

22

1 Cartridge

23

1 Tap body

24

1 Setting ring

25

1 Hexagon key

Technical data

Connections: G⅜ (approx. 17 mm)

Water connection nut: approx. 19 mm

Safety advice

RISK OF LOSS

OF LIFE OR ACCIDENT TO IN-

FANTS AND CHILDREN! Never

leave children unsupervised with the packaging

materials. Danger of suffocation. Keep the product

away from children. The product is not a toy.

CAUTION - RISK OF ELECTRIC

SHOCK! Leaks or the escape of

water can lead to danger to life from

electric shock. Check all connections for leaks

carefully. In addition, ensure that all cables from

electrical devices are correctly and safely installed.

CAUTION! RISK OF INJURY! Please ensure

that no parts are damaged and that all parts are

correctly assembled. Incorrect assembly could

lead to injury. Please note that seals are wear

parts and therefore will require to be replaced

from time to time. Damaged parts could ad

versely

affect safety and proper function.

CAUTION! RISK OF DAMAGE TO

PROPERTY! Have the installation done by

experienced persons only. Leaks or escape of
