CONTROL PANEL AND FEATURES

Not all features and cycles are available on all models.

POWER

Touch to turn the dryer on and off. Touch to stop/cancel

a cycle at any time.

CYCLE CONTROL KNOB

Use your dryer’s cycle control knob to select available cycles

on your dryer. Turn the knob to select a cycle for your laundry

load. See “Cycle Guide” for detailed descriptions of cycles.

START/PAUSE

Touch and hold to start a cycle, or touch once while a cycle

is in process to pause it.

TIMED DRY ADJUST

Use “+” and “–” with Timed Cycles to increase or

decrease the length of a Timed Dry or Rapid Dry cycle.

LED DISPLAY AND SETTINGS

When you select a cycle, its default settings will light up and

the Estimated Time Remaining (for Sensor Cycles) or actual

time remaining (for Timed Cycles) will be displayed.

Touch the setting names next to the display to adjust settings.

See “Cycle Guide” for available settings on each cycle. Not all

settings are available with all cycles.

Temperature

When using Timed Cycles, you may select a dry

temperature based on the type of load you are drying.

Use the warmest setting safe for the garments in the load.

Follow garment label instructions.

NOTE: Sensor Cycles allow temperature adjustment. At

most, 3 of available temperatures (not including Air Only)

are allowed.

Dry Level

You may adjust the Dry Level on Sensor Cycles (except

for the Sanitize cycle), if desired.

NOTE: Dryness level is for use with Sensor Cycles only.

Wrinkle Prevent

If you will be unable to remove a load immediately, touch

Wrinkle Prevent to add up to 150 minutes of periodic

tumbling to help reduce wrinkling. On some cycles, you

may select the “With Steam” setting to add a short steam

cycle after 60 minutes to help smooth out wrinkles.

1

2

3

OPTIONS

Use to select available options for your dryer. Not all cycles

and options are available on all models.

Static Reduce (on some models)

Touch to add the Static Reduce option to selected Sensor

cycles (see “Cycle Guide”). The dryer will automatically

tumble, pause, and introduce a small amount of moisture

into the load to help reduce static. This option adds

approximately 8 minutes to the total cycle time.

Damp Dry Signal

Touch to select the Damp Dry Signal to Low, High, or Off.

When selected, a series of beeps will sound when the

load is damp, but not completely dry. This will allow you

to take clothes out of the load that do not need to

dry completely. This option is not available on Sanitize,

Steam Refresh, and the Timed Dry cycles.

Audio Level

Touch AUDIO LEVEL to change end beep and button

sounds simultaneously to Low, High, or Off.

CYCLE STATUS LIGHTS

The indicator bar on the right side of the control will let you

know what stage of the drying cycle is in process. For more

information on each stage, see “Cycle Status Indicators.”

Sensing

The Sensing indicator will light during Sensor Cycles

to indicate that the moisture sensor on the dryer is

operating. This indicator will not light during Timed

Cycles or options such as Wrinkle Prevent.

Steam

This indicator will light when a steam function is

active.

NOTE: Steam is not available on all models or

on all cycles.

Done

This will indicate that the selected cycle has ended

and the load may be removed from the dryer. If

Wrinkle Prevent has been selected, the dryer may

continue to tumble the load, even if the Done

indicator is lit.

Check Lint Screen

The Check Lint Screen indicator light will flash as a

reminder to clean the lint screen. It will flash until the

door is opened or a cycle is started. It will turn off

when the dryer is turned off.

4

NOTE: The control panel features a sensitive surface that responds to a light touch of your finger. To ensure your selections are registered,

touch the control panel with your finger tip, not your fingernail. When selecting a setting or option, simply touch its name.

3

2

1

5

5

6 7

4

5

6

7
