Bruksanvisning Maytag CWE5800ACB Ugn

Bruksanvisning

4

OVEN USE

Odors and smoke are normal when the oven is used the first few

times, or when it is heavily soiled.

IMPORTANT: The health of some birds is extremely sensitive to the

fumes given off. Exposure to the fumes may result in death to

certain birds. Always move birds to another closed and well-

ventilated room.

Electronic Oven Controls

Control Display

The display will flash when powered up or after a power loss. Press

CANCEL to clear. When oven is not in use, the time of day is

displayed. Indicator lights show functions that are in use.

To nes

Tones are audible signals, indicating the following:

Basic Functions

One tone

■ Valid pad press

■ Oven is preheated (long tone)

■ Function has been entered

■ Reminder (on some models), repeating each minute after the

end-of-cycle tones

Three tones

■ Invalid pad press

Four tones

■ End of cycle

Reminder Tones: The audible tones at the end of the Kitchen

Timer may be set to beep once (“b1”) or continue to beep (“b”).

Press and hold KITCHEN TIMER for 5 seconds to enter Options

mode. “Opt” will appear on the display. Use TEMP/TIME to cycle

through the options until “b” or “b1” is shown in the display.

Choose on or off using the KITCHEN TIMER keypad. Press

CANCEL to exit the mode.

Fahrenheit and Celsius

The temperature is preset at Fahrenheit, but can be changed to

Celsius.

To change: Press and hold BROIL for 5 seconds. A tone will

sound, and “°C” or “°F” will appear on the display. Repeat to

change back.

To exit mode, press CANCEL.

Oven Control Lockout

Only the Clock and Kitchen Timer keypads will function with the

controls locked.

To lock controls: Press and hold START for 3 seconds. The

display will show “Loc.”

To unlock controls: Press and hold START for 3 seconds. The

display will show “Time of Day.”

12-Hour Shutoff

The oven control is set to automatically shut off the oven 12 hours

after the oven turns on. This will not interfere with any timed or

delayed cook function.

Oven Temperature Control

IMPORTANT: Do not use a thermometer to measure oven

temperature because opening the oven door may cause element

cycling to give incorrect readings.

The oven provides accurate temperatures; however, it may cook

faster or slower than your previous oven, so the temperature

calibration can be adjusted. It can be changed in Fahrenheit or

Celsius.

To Adjust Oven Temperature Calibration:

1. Press and hold BAKE for 5 seconds until the oven display

shows the current calibration, for example “0°F CAL” or “00.”

2. Press the TEMP/TIME “+” or “-” arrow pads to increase or to

decrease the temperature in 10°F (5°C) amounts. The

adjustment can be set between 30°F (17°C) and -30°F (-17°C).

3. Press START.

Aluminum Foil

IMPORTANT: To avoid permanent damage to the oven bottom

finish, do not line the oven bottom with any type of foil or liner.

For best cooking results, do not cover entire oven rack with foil

because air must be able to move freely.

Positioning Racks and Bakeware

IMPORTANT: To avoid permanent damage to the porcelain finish,

do not place food or bakeware directly on the oven door or bottom.

Bakeware

To cook food evenly, hot air must be able to circulate. Allow

2" (5 cm) of space around bakeware and oven walls. Make sure

that no bakeware piece is directly over another.

Racks

■ Position racks before turning on the oven.

■ Do not move racks with bakeware on them.

■ Make sure racks are level.

To move a rack, pull it out to the stop position, raise the front edge,

and then lift out. Use the following illustration and charts as a

guide.

Rack Positions

Rack 4: Use for broiling and 2-rack baking.

Rack 3: Most baked goods on a cookie sheet or jelly roll pan, layer

cakes, frozen convenience foods. Broiling chicken pieces.

1

2

3

4
