Bruksanvisning Matsui MUR1248GS Kylskåp

Bruksanvisning

UNDERCOUNTER

FRIDGE

INSTRUCTION MANUAL

MUR1248GW-GS

MUR1248GWE-GSE

Congratulations on the purchase of your new Matsui Undercounter Fridge.

We recommend that you spent some time to read this Instruction Manual in

order to fully understand how to install and operate it.

PRODUCT OVERVIEW

INTERNAL LIGHT AND

THERMOSTAT CONTROL DIAL

ADJUSTABLE

SHELVES

LEVELLING FEET

BOTTLE

STORAGE

Safety First!

For your continued safety and to reduce the risk of injury or electric shock, please

follow all the safety precautions listed below.

• Read all instructions carefully before using the Fridge and keep them for future reference.

• Retain the manual. If you pass the Fridge onto a third party, make sure to include this

manual.

• Keep ventilation openings, in the appliance enclosure, clear of obstruction.

• Do not use mechanical devices or other means to accelerate the defrosting process, other

than those recommended by the manufacturer.

• If the mains cable is damaged, it must be replaced by the manufacturer of its service

agent or a qualied technician in order to avoid a hazard.

• Choose a location for your Fridge away from heat sources such as radiators or res as

refrigerant and vesicant are burnable.

• Do not discard old Fridge at will in order to avoid environment pollution. Thank you for

your cooperation.

• Young children should be supervised to ensure that they do not play with the Fridge.

• Do not damage the refrigerant circuit (applicable only for appliances with refrigeration

circuits which are accessible to the user).

• The Fridge must be maneuvered by a minimum of 2 persons.

• This appliance is not intended for user by persons (including children) with reduced

sensory or mental capabilities, or lack of experience and knowledge unless they have

been given supervision or instructions concerning he use of the appliance by a person

responsible for their safety.

• If your Fridge is tted with a lock to prevent children being trapped inside, keep the key

out of reach and not in the vicinity of the appliance.

WARNING

IT IS HAZARDOUS FOR ANYONE OTHER THAN AUTHORISED SERVICE PERSONNEL

TO CARRY OUT SERVICING OF REPAIRS WHICH INVOLVE THE REMOVAL OF

COVERS.

TO AVOID THE RISK OF AN ELECTRICAL SHOCK DO NOT ATTEMPT REPAIRS

YOURSELF.

MAINTENANCE

Moving your Undercounter Fridge

Care when handling

Hold the Fridge around its sides or base when moving it. Under no circumstances should it

be lifted by holding the edges of the top surface.

Location

Do not locate your Fridge near a heat source, eg. cooker boiler or radiator. Also avoid direct

sunlight in outbuildings or sun lounges.

Leveling the Undercounter Fridge

Make sure that the Fridge is level. Use the adjustable levelling feet at the front. If the Fridge

is not level, the doors and magnetic seal alignments will be affected.

Do not turn on the Undercounter Fridge for 2 Hours

After the Fridge is in place, it needs to be left for 2 hours. The coolant uid needs time to

settle.

Installation

Don’t cover or block the vents or grilles of your Fridge.

Servicing

This product should be serviced by an authorised engineer and only genuine spare parts

should be used.

Under no circumstances should you attempt to repair the appliance yourself. Repairs

carried out by inexperienced persons may cause injury or serious malfunction. Contact a

qualied technician.

When the Fridge is not in use for a long period of time, disconnect it from the mains supply,

empty all food and clean the Fridge, leaving the door ajar to prevent unpleasant smells.

GB - 1 GB - 5

DSG Retail Ltd. Maylands Avenue Hemel Hempstead

Hertfordshire HP2 7TG England

DISPOSAL

Old appliances still have some residual value. An environmentally friendly method of

disposal will ensure that valuable raw materials can be recovered and used again. The

refrigerant used in your appliance and insulation materials require special disposal

procedures. Ensure that none of the pipes on the back of the appliance are damaged prior

to disposal. Up to date information concerning options of disposing of your old appliance

and packaging from the new one can be obtained from your local council oce.

If disposing of an old Fridge break off any old locks or latches as a safeguard.

SPECIFICATIONS

Rated voltage (V): 230

Rated frequency (Hz): 50

Input Current (A): 0.7

Input Power (W): 75

Fridge Volume

Net Capacity (liters): 117

4.1 (cubic feet)

Weight (kg): 28.5

Product Dimension h/w/d: 845 x 545 x 570

(mm)

Refrigerant (weight): 24g

Features and Specication are subject to change without prior notice.

GLASS SHELF

SALAD BIN

FREEZER

COMPARTMENT

ICE TRAY

Visit Partmaster.co.uk today for the easiest way to buy electrical spares and accessories.

With over 1 million spares and accessories available we can deliver direct to your door

the very next day. Visit www.partmaster.co.uk Or call 0844 800 3456 (UK customers

only) Calls charged at National Rate.

This symbol on the product or in the instructions means that your electrical and electronic

equipment should be disposed at the end of its life separately from your household waste.

There are separate collection systems for recycling in the EU.

For more information, please contact the local authority or your retailer where you purchased

the product.

CLEANING

Defrosting

Frost will build up in the Freezer Compartment after the unit has been used for a period of

time. Scrape away the frost using a plastic scraper.

Note: Do not use a metal or sharp instrument to scrap away the frost, nor should you use any

electrical appliances to aid defrosting.

When the frost layer exceeds 5cm (2”), defrosting should be carried out. Choose a time when

the stock of frozen food is low and proceed the following:-

1. Take out the chilled food, turn the fridge off at the mains supply and leave the door open.

Ideally, the frozen good should be put into another freezer compartment or refrigerator. If

this is not possible, wrap the food in several sheets of newspaper or large towels and then

a thick rug or blanket to keep it cool.

2. Place a shallow bowl or pan below the Freezer Compartment. Scrap

away the frost using the plastic scraper. Thawing of the remainder

can be speeded up by placing a bowl of hot water inside the Freezer

Compartment cabinet and closing the door. As the solid frost loosens,

scrap it away with the plastic scraper and remove.

3. When defrosting is complete, clean your fridge’s interior and exterior.

Cleaning the interior and the exterior of the Undercounter Fridge

• Wipe the inside of the Fridge with a weak solution of bicarbonate soda. Then rinse with

warm water using a ‘wrung-out’ sponge or cloth. Wipe completely dry before replacing the

shelves and baskets.

• Use a damp cloth to clean the Fridge exterior, then use the standard furniture polish to

clean. Make sure that the door is closed to avoid the polish getting on the magnetic door

seal or inside.

• The grille of the condenser at the back of the fridge and the adjacent components can be

vacuumed using a soft brush attachment.

Cleaning tips

• Condensation may appear on the outside of the Fridge. This maybe due to a change in the

room temperature. Wipe off any residue of moisture. If the problem continues call the

Customer Service Department.

Matsui MUR1248GS-GW-GSE-GWE_IB_101229.pdf 1 12/29/10 2:46 PM
