Bruksanvisning Matsui M15ORW09 Värmefläkt

Bruksanvisning

1. Position the radiator upright on the oor away from curtains, furniture or

wallcoverings before plugging into the mains socket.

2. Turn the Power Switches to the “ ” or “ ” position.

The radiator has 2 built-in heating elements. You can select turning on one or

both heating elements simultaneously.

3. Turn the Thermostat Control to a desired position. It is recommended to

select the highest setting to get the heater to pre-heat. It will take 5-10

minutes for the heater to fully heat up.

4. When the surrounding room temperature reaches to the desired tempera-

ture, turn the Thermostat Control slowly anti-clockwise until the indicator

goes o with a “click” sound. The heater will temporarily go o.

5. If the surrounding room temperature falls below the desired temperature,

the heater and indicator will turn on again until the room temperature

reach the desired temperature.

GB - 4

Your Radiator - Product Overview

Control Panel

Assembly

It is hazardous if you turn on the radiator when it is upside down. Before

use, remember to double check that the radiator is standing upright on a

rm and level surface.

Do not immerse the radiator in water. Do not use any cleaning chemicals

such as detergents and abrasives.

GB - 3GB - 2

Using your Radiator

Do not plug your radiator into a mains socket, while you are assembling

the product.

1. Install the 4 wheels onto the 2 supporting plates by using a spanner.

2. Turn the unit upside down.

3. Wrap the “U” shaped screw in between the 1

st

and 2

nd

radiator ns.

4. Hook the wheels and supporting plate into the screws.

5. Insert the buttery nut and screw it tightly on.

6. Repeat step 3-5 in between the 6

th

and 7

th

radiator ns.

7. Check the wheels have not become loose before each use.

1. Always remove the mains plug from the

mains socket and allow the radiator to

cool down before cleaning the radiator.

2. Wipe radiator with a soft damp (not wet)

cloth.

3. Coil up the mains cable and place it in

the mains cable holder. Store the radiator

in a clean dry place.

Cleaning

Supporting plate

“U” shaped screw

Buttery nut

Wheels

Safety Protective Devices

1. Overheat Protection System

The power to the radiator will automatically cut o if the temperature of the

radiator exceeds a certain limit. In the event of overheating, the radiator will

stop operating. Switch the radiator o and allow to cool. The radiator will then

operate again as normal.

2. Tip-over Protective Switch

When you use the radiator in an upright position on a rm and level surface,

the tip-over protect switch will be on. In the event the radiator is knocked over,

the radiator will stop functioning automatically.

Power Switches /

(with indicators)

Display Window

My radiator does not work when I turn it on

1. Check that your radiator is plugged in and the power is turned on at the

socket.

2. Set the temperature to the highest setting.

3. Check if the thermostat setting is too low.

4. Try replacing the BSI or ASTS approved 13 Amp BS1362 fuse in the plug.

5. If the radiator still doesn’t work, do not try to repair the radiator yourself, it

may result in a re hazard or electric shock. Please leave all maintenance work

to qualied personnel.

If your radiator’s power is automatically cut o follow the steps below:

1. Unplug your radiator and allow it to cool down.

2. Inspect your radiator.

3. Plug-in the radiator and switch it on again. If it cuts o again, move the

radiator to a better ventilated location.

4. If there is any sign of physical damage (e.g. melting, or burning of the case), do

not attempt to use your radiator. Contact your authorised service agent.

Hints and Tips

D

C

E

F

B

A

H

G

I

J

Thermostat Control

ON

OFF

A. Carry Handle

B. Power Switches (with indicator)

C. Display Window

D. Thermostat Control

E. Mains Cable Holder

F. Mains Cable

G. Vent

H. Radiator Fins

I. Rear Wheel

J. Front Wheel

ON

OFF

1

4

2 3

In between the 1

st

&

2

nd

radiator ns

In between the 6

th

&

7

th

radiator ns
