GB - 1 GB - 2 GB - 3

OPERATING INSTRUCTIONS

Switching on your Fridge

1. The internal temperature of your fridge is controlled by a

thermostat. There are seven settings, of which position 7 is

the coldest and position 0 turns the fridge o.

2.

Adjust the thermostat control dial to the desired position,

bear in mind that the higher the number, the lower the

temperature. Position 4 is the recommended setting for

the fridge when operating at normal room temperature

(between 16

º

C and 32

º

C).

3. The fridge may not operate at the correct temperature if it

is in a particularly hot or a particularly cold room, or if you

open the fridge door often.

4. If you are concerned that your fridge is not being kept cold

enough and wish to check the temperature you will need a

special fridge thermometer. These are available from most

supermarkets and hardware shops.

Place the thermometer in the fridge, where it can be read easily. Leave overnight, the temperature

in the fridge should be between 0

º

C and 5

º

C.

Adjusting the Temperature

The internal temperature of your fridge is controlled by a thermostat. The recommended position is

between 1 to 4 for colder working environments (i.e. during winter) and between 5 to 6 for hotter

environments. Please adjusted according to the environment.

Noises inside the Fridge!

If you have not owned a fridge before, you may notice that it makes some rather unusual noises. Most

of these are perfectly normal, but you should be aware of them!

These noises are caused by the circulation of the refrigerant liquid in the cooling system. It has

become more pronounced since the introduction of CFC free gases. This is not a fault and will not

aect the performance of your fridge.

This is the compressor motor working, as it pumps the refrigerant around the system.

Shopping for Chilled Foods

• Take a quick look at the chilled food package and make sure it is in perfect condition.

• Try to keep chilled food together whilst shopping and on the journey home as this will help to keep

the food cold.

• Don’t buy chilled food unless you can chill it straight away. Specially insulated bags can be bought

from most supermarkets and hardware shops. These bags can keep chilled food cold for longer

while transporting.

• Food that has been left in a car or at room temperature for a prolonged period of time could raise the

food temperature to a dangerous level, which allows harmful bacteria to grow.

• Always unpack and place chilled food in the fridge before storing dry food.

Tips for Keeping Food Perfect In the Fridge

• Cooked meats/ shes should always be stored on a shelf above raw meats/shes to avoid bacterial

transfer. Keep raw meats/shes in a container which is large enough to collect juices and cover it

properly. Place the container on the lowest shelf at the bottom of the fridge.

• Leave space around your food, to allow air to circulate inside the fridge. Ensure all parts of the fridge

are kept cool.

• To prevent transfer of avours and drying out, pack or cover the food separately. Fruit and vegetables

do not need to be wrapped.

• Always let pre-cooked food cool down before you put in the fridge. This will help to maintain the

internal temperature of the fridge.

• To prevent cold air escaping from the fridge, try to limit the number of times you open the door. We

recommend that you only open the door when you need to put food in or take food out.

Shopping for Frozen Foods

• Your freezer compartment is 4-star.

When you are buying frozen food, check the storage guidelines on the packaging. You will be able to

store each item of frozen food for the period shown against the 4-star rating. This is usually the

period stated as “Best before” on the front of the packaging. The maximum freezing capacity of this

fridge is 2.5kg in 24 hours. Do not place fresh food into the freezer compartment exceeding this

weight.

• Check the temperature of the frozen food cabinet in the shop where you buy your frozen foods. It

should show a temperature lower than -18

º

C.

• Take a quick look at the frozen food package and make sure it is in perfect condition.

• Always buy frozen products last on your shopping trip or visit to the supermarket. Try to keep frozen

food together whilst shopping and on the journey home as this will help to keep the food cold.

• Don’t buy frozen food unless you can freeze it straight away. Specially insulated bags can be bought

from most supermarkets and hardware shops. These bags can keep frozen food frozen longer.

Preparations for Freezing

• Leave cooked food to cool completely. Chill food in a fridge before freezing if possible.

• Label your frozen foods as they will look the same when in frozen state. Use special freezer tapes, labels

and pens with different colours as this allows you to easily organise and to effectively use the freezer.

Write the contents and date; otherwise the frozen food might exceed the storage time and this could

cause food poisoning. Please refer to your food packaging for the recommended storage time.

• You may also add the weight and cooking notes, e.g. “defrost rst”, “cook from frozen” and keep a

separate log-lock of what is in each drawer. This will save opening the door and searching around

unnecessarily.

Defrosting Frozen Food

1. Take the frozen food out from the freezer compartment and uncover

the frozen food. Let it defrost at room temperature. Don’t forget

that defrosting in a warm area encourages the growth of bacteria

and low temperature cooking may not destroy dangerous bacteria.

2. Drain off and throw away any liquid lost during defrosting.

3. Always make sure there are no ice-crystals in the food before

cooking, particularly with meat. These crystals indicate that the food

has not fully defrosted.

4. Cook food as soon as possible after defrosting.

5. Many microwaves and ovens have a defrost setting. To avoid

bacterial build up, only use these if you intend to cook the food

immediately afterwards.

a

b

4

Remove the bottom hinge adaptors from both doors. On the opposite side, insert the replacement

hinge adaptors. Ensure they are securely located.

Underside view of the freezer door Underside view of the fridge door

RemoveInsert RemoveInsert

Levelling the Fridge

To do this use the two levelling feet at the front of the fridge.

If the fridge is not level, the door and magnetic seal alignments will not

be covered properly.

Cleaning Before Use

Wipe the inside of the fridge with a weak solution of bicarbonate soda.

Then rinse with warm water using a ‘wrung-out’ sponge or cloth. Wipe

completely dry before replacing the shelves and salad bin. Clean the

exterior of the fridge with a damp cloth.

If you require more information refer to the CLEANING section.

Before Plugging in YOU MUST

Check that you have a socket which is compatible with the plug supplied with the fridge.

Before Turning On!

Do not turn on until two hours after moving the fridge. The coolant uid needs time to settle.

Before Using your Fridge

Before placing any food in your fridge, turn it on and wait for 24 hours, to make sure it is working

properly and to allow the fridge to fall to the correct temperature.

Your fridge should not be overlled.

THERMOSTAT CONTROL

DIAL

INTERNAL

LIGHT

Note:

Never refreeze anything that

has been defrosted out unless

you cook it again, to kill o

harmful bacteria. Never

re-freeze defrosted shellsh.

Re-seal packs properly after

removing items. This prevents

drying or freezer-burn and a

build up of frost on any

remaining food.

Put the top cover back and tighten it with the screws. Then,

replace the screw covers.

Reverse steps 1a to 1c for details.

Double check that the door is aligned correctly and all

the seals are closed on all sides. If necessary, re-adjust

the levelling feet.

Use a spanner to tighten it if necessary.

Ensure the doors are aligned

horizontally and vertically so that the

seals are closed on all sides before

nally tightening the hinge.

Remove the screw cover on the side you want to install

the door. Place the fridge door rst and screw it onto the

middle hinge.

Ensure the doors are aligned horizontally and

vertically, so that the seals are closed on all sides

before nally tightening the hinge.

6

a

b

Middle hinge

7

8

Position the freezer door and screw it to the

the top hinge.

5

Remove the screws, bottom hinge and the adjustable feet. Then remove the pin with a

spanner and tighten it onto the opposite side. Screw it into place and reattach the door and

adjustable feet.

unscrew

unscrew screw

screw

180˚

UNPACKING

Remove all packaging from the fridge. Retain the packaging. If you dispose of it please do so

according to any local regulations.

The following items are included:

• One Main Unit/ • One Adjustable Shelf / • One Glass Shelf / • Two Doors / • One Salad Bin /

• One Wire Shelf / • Two Egg trays / • One Ice Tray

If items are missing or damaged, please contact Partmaster (UK only).

Tel: 0870 6001 338 for assistance.

INSTALLATION

Note:

All parts removed must be saved to do the reinstallation of the door. You should rest the fridge on

something solid so that it will not slip during the door change process. Do not lay the fridge at as

this may damage the coolant system. Ensure the fridge is unplugged and empty. We recommend

that 2 people handle the fridge during assembly.

Location

When selecting a position for your fridge you should make sure the oor is at and rm, and the

room is well ventilated with an average room temperature of between 16

º

C and 32

º

C. Avoid

locating your fridge near a heat source, eg. cooker, boiler or radiator. Also avoid direct sunlight as it

may affect the acrylic coating and increase the electrical consumption. Extreme cold ambient

temperatures may also cause the appliance not to perform properly. This fridge is not designed for

use in a garage or outdoor installation. Do not drape the fridge with any covering. When installing,

ensure that 2cm (3/4”) of free space is left at the sides. The fridge door can open to the right or the

left, depending on what better suits the location. IF YOU WANT TO HAVE THE DOOR SWING

REVERSED, WE RECOMMEND THAT YOU CONTACT A QUALIFIED TECHNICIAN. YOU SHOULD ONLY

TRY TO REVERSE THE DOOR YOURSELF IF YOU BELIEVE THAT YOU ARE QUALIFIED TO DO SO.

Reversing the door swing

To change the opening direction yourself, please follow these instructions:

Tools required : Philips style screwdriver / Flat bladed screwdriver / Hexagonal Spanner

a

1

Remove the 2 screw covers rst, then undo

the screws underneath.

Remove the 2 screws on the back.

Lift the top cover away from the fridge. Swap over the hinge cover on the top cover.

b

c

d

2

Undo the screws and remove the hinge

bracket.

Remove the pin with a spanner and tighten

it on the side you want to install. Lift the

freezer door up and move it away from the

fridge.

unscrew

screw

180˚

180˚

3

Remove the screws from the middle hinge. Lift the fridge

door up and move it away from the fridge.

unscrew
