Bruksanvisning Logik L200IR12 Strykjärn

Bruksanvisning

OPERATION

• Ensure the mains socket is switched off and the

Steam Control is at the OFF position.

• Fill the iron with water as described above.

• Place the iron on its heel on the ironing board rest

and connect the mains cable to the mains socket.

• The Temperature Indicator will illuminate.

• Select the correct temperature by turning the

Temperature Dial.

Turn clockwise to increase and anticlockwise to

reduce temperature.

Mains Cable

Temperature

Indicator

Spray

Shot of Steam

Steam Control

Water Filler & Cap

Spray Nozzle

Water Tank

Temperature Dial

Self Clean

Soleplate

Filler Cup

UNPACKING

Remove all packaging from the unit. Retain the packaging. If you dispose of it

please do so according to any local regulations. The following items are included:

• Steam Iron

• Filler Cup

• Instruction Manual

If items are missing or damaged, please contact Partmaster (UK only).

Tel: 0344 800 3456 for assistance.

IRONING TEMPERATURES

Check the ironing instructions attached to the article (they are on a label showing a

symbol of an iron). Always follow these ironing instructions. The indications on the

iron’s Temperature Dial and the table below will help you.

FIRST TIME USE

Inspect the iron carefully.

Check that the voltage marked on the rating matches your mains voltage.

Remove any protective film from the soleplate. Polish the soleplate lightly with a

clean soft cloth to remove any residues.

Place the iron on the ironing board or a at rigid surface.

PRODUCT OVERVIEW

min

max

INCREASEDECREASE

200ml

150ml

100ml

50ml

FILLING THE IRON

Make sure the iron is unplugged from the mains

socket and the Steam Control is at the OFF

position.

Open the Water Door, tip the iron up slightly and

fill it carefully with fresh water using the supplied

filler cup.

If you live in a hard water area, it is advisable to use

distilled or de-mineralised water. Avoid using water

containing softeners, perfumes or additives.

Do not fill the iron above the max mark

indicated on the side of the iron.

Do not iron garments that are dirty or stained. The iron’s heat may set the stain.

• Some parts have been lightly greased and the iron might smoke slightly

when switched on for the first time. After a short while, this will cease. We

recommend passing the iron over a clean cotton cloth before using it for the

first time. The Temperature Indicator will go off when the indicated setting

reaches the correct temperature. The iron is now ready for use. During use

the indicator will cycle on and o as the thermostat maintains the iron at the

correct temperature setting.

• In between operations and when lling the iron always stand the iron on its

heel. NEVER leave the iron face down.

The iron gives o steam continuously only if you hold the iron horizontally.

You can stop the continuous steam by placing the iron in a vertical position or

by moving the steam selector to the OFF position.

SWITCHING OFF THE IRON

To prevent water leakage, set to the far

side of the Steam Control to prevent

water leakage from the soleplate.

Set to the

OFF position

STEAM IRONING

Steam ironing should be carried out at the highest settings on

the Temperature Dial. Steam ironing at lower temperatures

may cause water to leak from the soleplate.

The quantity of steam is regulated by the Steam

Control. Move the steam selector to a suitable

position depending on the quantity of steam

required and the ironing temperature.

Maintaining the finish of the iron’s soleplate is essential. Keep the soleplate

smooth: do not scratch it on metal objects (e.g. the edge of the ironing board,

buttons, zippers, etc.) as these may impair performance.

If there are no ironing instructions but you know the fabric, then use the table

above. The table is valid only for the actual materials and does not take into account

any finish applied to the fabric. Textiles to which a finish has been applied (wrinkle

relief, printed T shirts etc.) should be ironed at a lower temperature.

If the fabric contains mixed fibres, select the lowest ironing temperature of the

composition, e.g. iron a 60% polyester /40% cotton mix at the temperature

indicated for polyester.

The iron heats up quicker than it cools down. Sort fabrics to be ironed into groups

according to temperature: wool with wool, cotton with cotton, etc. Start by ironing

articles requiring low temperature settings and progress to higher ones.

Pure (100%) wool fabrics may be pressed with the iron set to a steam position and

the garment protected by a dry cloth.

GB-1 GB-2 GB-3

GARMENT LABEL

Synthetic

Silk-wool

Cotton-linen

Medium temperature

Low temperature

High temperature

FABRIC TYPE THERMOSTAT REGULATION

Fabric not to be ironed

MAX Steam MIN Steam Dry Ironing

(OFF)

SAFETY FIRST!

Please follow all the safety precautions listed below for safety and to reduce the risk

of injury or electrical shock.

• Read all the instructions before operating the appliance and keep them for future

reference. If you pass the product on to a third party, include these instructions.

• Unplug the iron from the mains socket when not in use, and before emptying,

lling, or cleaning.

• Do not touch the soleplate of the iron if it is hot.

• Always hold the appliance by the handle.

• Keep the appliance well away from surfaces and objects that can be damaged by

heat.

• Ensure there is adequate room to operate the iron.

• Ensure that the iron cannot fall into water.

• Do not immerse the mains cable in any liquid.

• Do not let the mains cable overhang the edge of the work surface or allow it to

touch hot surfaces or sources of heat or ame.

• If any part of this appliance is damaged or malfunctions in any way, or the mains

cable or mains plug is broken, do not continue to use it. Seek expert assistant.

• The iron must not be used if dropped, if there are visible signs of damage or if it is

leaking.

• This appliance can be used by children aged from 8 years and above and persons

with reduced physical, sensory or mental capabilities or lack of experience and

knowledge if they have been given supervision or instruction concerning use of the

appliance in a safe way and understand the hazards involved. Children shall not

play with the appliance. Cleaning and user maintenance shall not be made by

children without supervision.

• Keep the appliance and its cord out of reach of children less than 8 years old.

• Children should be supervised to ensure that they do not play with the appliance.

• Parents must warn children not to touch hot appliance parts. Close supervision is

necessary when an appliance is used near children.

• When not ironing never leave the iron face down. Stand it upright on its heel, on a

level heatproof surface.

• The iron must be used and rested on a stable surface.

• When standing the iron in an upright position ensure that the surface is at and

stable.

• Do not use outdoors or in damp or wet conditions.

• Do not use this iron for professional laundry services.

• Do not use this appliance for any purpose not covered by the instructions.

• Do not turn the iron upside down, there may be hot water in the water tank.

• Use this iron only with a purpose-built ironing board.

• Observe all ironing instructions and ironing temperature dot settings given by the

garment manufacturer. These are normally on a label or labels inside the garment.

• If the mains cable is damaged it must be replaced by the manufacturer, its service

agent, or similarly qualied persons in order to avoid a hazard.

• The iron must not be left unattended while it is connected to the mains socket.

• Always ensure the water lling does not exceed the max mark.

• Always unplug the iron when relling the water reservoir.

• The plug must be removed from the socket-outlet before the water reservoir is

lled withwater.

L200IR12_IB_RC_160226_grace.pdf 2 26/2/16 2:26 pm
