Product Overview
Unpacking
Remove all items from the packaging. Retain the packaging. If you dispose of it please do so
according to local regulations.
The following items are included:
• Main unit
• Wheel set x 2
• “U” shaped screw x 1
• Buttery nut x 4
Operation
Position the heater upright on the oor away from curtains, furniture or wall coverings before
plugging into the mains socket.
• Plug in the unit.
• Turn the Power Control to III and the Thermostat Control to Max position. The indicator
light will turn on. Wait for the heater to fully heat up.
• When the room reaches the desired temperature or if you want to lower the room
temperature, turn the Power Control to either I or II, or turn the Thermostat Control
halfway towards Min position.
• To turn o the heater, turn the Power Control to 0 (O) position. Turn the Thermostat
Control to Min position. The indicator light will turn o.
• Unplug the unit from the mains socket when it is left unattended or not in use.
Cleaning & Storage
• Your heater should be cleaned regularly to prevent dirt and dust from building up which will
aect its performance.
• Always unplug the mains cable from the mains socket and allow the heater to cool down
before cleaning.
• Wipe the unit with a soft damp (not wet) cloth.
• Coil up the mains cable onto the cord storage. Store the heater in a cool dry place.
Hints & Tips
My heater does not work when I turn it on:
• Check that your heater is plugged in and the power is turned on.
• Check if the thermostat setting is too low.
• If the heater still does not work, do not try to repair the heater yourself. Please leave all
maintenance work to qualied personnel.
If your heater’s power is automatically cut o, follow the steps
below:
1. Unplug your heater and allow it to cool down.
2. Inspect your heater.
3. Plug in the heater and switch it on again. If it cuts o again, move the heater to a better
ventilated location.
4. If there is any sign of physical damage (e.g. melting, or burning of the case), do not attempt
to use your heater. Please leave all maintenance work to qualied personnel.
Safety Protective Device
Overheat Protection
The power to the heater will automatically cut o if the temperature of the heater exceeds a
certain limit. In the event of overheating, the heater will stop operating. Switch o and unplug
the heater, and allow it to completely cool.
Built-in Tipover Protective Switch
When you use the heater in an upright position on a rm and level surface, the built-in tipover
protective switch will be on. In the event the heater is knocked over, the heater will stop
functioning automatically.
Specications
Model L15OFR18
Power Supply 220-240V~ 50Hz
Power Consumption 1500W
Number of Fins 7
Features and specications are subject to change without prior notice.
Do not plug your heater into a mains socket while you are assembling the product.
1. Turn the unit upside down.
2. Attach one of the wheel sets on the control box of the unit. Secure tightly with the buttery
nuts.
3. Wrap the “U” shaped screw in between the 6th and 7th radiator ns. Attach the other wheel
set on the “U” shaped screw. Secure tightly with the buttery nuts.
4. Stand the unit to the upright position.
5. Check that the wheels are not loose before each use.
Assembly
Model L15OFR18
Item Symbol Value Unit Item Unit
Heat output Type of heat input, for electric
storage local heaters only (select
one)
Nominal heat
output
P
nom
0.7 kW Manual heat charge control
with integrated thermostat
no
Minimum
heat output
(indicative)
P
min
0.6 kW Manual heat charge control
with room and/or outdoor
temperature feedback
no
Maximum
continuous heat
output
P
max,c
0.7 kW Electronic heat charge control
with room and/or outdoor
temperature feedback
no
Auxiliary electricity consumption Fan assisted heat output no
At nominal heat
output
el
max
N/A kW Type of heat output/room
temperature control (select one)
At minimum heat
output
el
min
N/A kW Single stage heat output and
no room temperature control
no
In standby mode el
SB
N/A kW Two or more manual stages, no
room temperature control
no
With mechanic thermostat
room temperature control
yes
With electronic room
temperature control
no
Electronic room temperature
control plus day timer
no
Electronic room temperature
control plus week timer
no
Other control options (multiple
selections possible)
Room temperature control,
with presence detection
no
Room temperature control,
with open window detection
no
With distance control option no
With adaptive start control no
With working time limitation no
With black bulb sensor no
Contact details DSG Retail Ltd. (co. no. 504877)
1 Portal Way, London, W3 6RS, UK
Product Fiche
• If items are missing or damaged, please contact Partmaster (UK only).
• Tel: 0344 800 3456 for assistance.
• It is hazardous if you turn on the heater when it is upside down.
• Before use, remember to double check that the heater is standing upright on a
rm and level surface.
• Ensure you unplug your heater from the mains socket and wait for the heater to
cool down completely before cleaning.
• Do not immerse the unit in water. Do not use any cleaning chemicals such as
detergents and abrasives.
Wheel set
Buttery nut
“U”
shaped
screw
Control box
Cord Storage
Carry Handle
Radiator Fins
Thermostat Control
Power Control
Indicator
• Do not override the tip-over protective switch as this may cause a hazard.
• Using the unit on a deep pile carpet may activate the tip-over protective switch.
L15OFR18_IB_180718_grace.indd 4-6 18/7/18 3:16 pm
