Bruksanvisning

Watch Setting Guide

Features

1.Time display with Hour, Minute and Second Hands.

2. One hour Stopwatch (Chronograph) with Seconds and Minutes

Hand display

3. 24-Hour Hand.

BEFORE USING THIS WATCH

STOPWATCH HAND ADJUSTMENT

1. Refer to diagram on left. Notice the small dial on the bottom and

the small dial on the left side. These are the stopwatch hands.The

bottom dial shows elapsed seconds (0-60) and the dial on the left

shows elapsed minutes (0-60).These hands are synchronized with

each other.They must be programmed to start at the “zero” or 12

o’clock position before the stopwatch can be used.

2. Pull the crown to the “out” position. Push and hold buttons “A” and

“B” simultaneously for two seconds, then release.The stopwatch

second hand (bottom small dial) will move backwards for one half

turn and then forward for one half turn.This will electronically reset

the stopwatch mechanism.

3.With the crown still in the “out” position, push either button A or B

to position the stopwatch second hand. Button “A” will move the

hand backwards (counter-clockwise). button “B” will move the hand

forward (clockwise). Each push of the buttons will move the hand

one step – if the button is held “in” the hand will move rapidly.

4. Remember

, the stopwatch second and minute hands are synchro-

nized

with each other. For each revolution of the second hand, the

minute hand will move one minute. Both hands m

ust be positioned

at the zer

o or 12 o’clock position.

SETTING THE TIME

With the crown still in the “out” position, turn the crown to set the

hands to the desired time.We suggest moving the hands to approxi-

mately 5 minutes past the correct time – then backwards to the

correct time.The 24 hour hand is permanently synchronized with the

hour/minute hands.When setting the hands, check the 24 hour dial

(on the right side of the watch – see diagram). AM time is 0-12 Hours

on this dial, PM time is 13-24 hours on this dial (24:00 hours is mid-

night).After the time is set, push the crown back to the “IN” position.

USING THE STOPWATCH/ SPLIT TIME

1. Insure that the stopwatch hands have been properly adjusted

(see section “BEFORE USING THIS WATCH”, above).

2. Push the “A” button to start the stopwatch. Push “A” button

again to stop.

3. Push the “B” button and the stopwatch hands will automatically

return to the “0” or starting position.

4. For “SPLIT” time measurement – With the stopwatch running, push

button “B”.The hands w

ill stop moving, but the watch will keep the

stopwatch time internally. Push “B” again and the hands will catch up

to the actual elapsed time.

ELECTRONIC RESET FOR STOPWATCH

If for any reason, the stopwatch behaves erratically, it can be electroni-

cally reset as follows:

1. Pull the crown to the “OUT” position.

2. Push buttons “A” and “B” simultaneously for two seconds,

then release.

3.The stopwatch second hand will move backwards for 1/2 revolution

then forward 1/2 revolution.

4. Reset the hands to “0” following the above instruction:

“Stopwatch Hand Adjustment”, steps #2 through #4.

5. Push the crown back in.

Te c h nical

Letter

BOOK NO. 537 STOPWATCH VD54B

11/2002

MINUTE HAND

PUSH BUTTON “A”

HOUR HAND

Crown

STOP WATCH
