7

■ The Cooling ON/OFF touch pad on the control panel shuts

down refrigerator functions such as cooling, lighting, fans and

compressors. To turn the power off completely, use the power

ON/OFF switch located behind the top grille. See “Power

On/ Off Switch.”

Viewing the Celsius Temperatures

■ Press the F/C touch pad. To redisplay degrees Fahrenheit,

press F/C again.

NOTE: If the freezer temperature is below zero, the negative sign

next to the freezer display will light up. This is normal.

Adjusting Controls

NOTE: Wait at least 24 hours between adjustments. Recheck the

temperatures before other adjustments are made.

To Adjust Set Point Temperatures:

■ Press the refrigerator or freezer PLUS (+) or MINUS (-) touch

pad until the desired temperature is reached.

■ Press the Set To Recommended touch pad to reset the set

points to the factory recommended temperatures.

NOTE: The set point range for the freezer is -5°F to 3°F

(-21°C to -16°C). The set point range for the refrigerator is

34°F to 42°F (1°C to 6°C).

CONDITION /REASON:: TEMPERATURE

ADJUSTMENT:

REFRIGERATOR too cold

Not set correctly for conditions

REFRIGERATOR Control 1°

higher

REFRIGERATOR too warm

High use or room very warm

REFRIGERATOR Control 1°

lower

FREEZER too cold

Not set correctly for conditions

FREEZER Control1° higher

FREEZER too warm/too little

ice

High use or heavy ice use

FREEZER Control 1° lower

Water Filter Indicator and Reset

See “Water Filter Indicator” section.

Max Cool

The Max Cool feature assists with periods of heavy ice usage, full

grocery loads, or temporarily warm room temperatures.

■ Press MAX COOL to turn on the Max Cool feature. The Max

Cool indicator light will remain on for 24 hours unless

manually turned off.

NOTE: The temperature display will remain at 34°F (1°C) and

-5°F (-21°C) for the refrigerator and freezer compartments,

respectively, while the Max Cool feature is enabled. After 24

hours, the refrigerator returns to the previous temperature set

points.

Alarm Functions

Master Alarm Reset

Pressing Alarm Reset once will turn off the audio alarm and

indicator light. The audio alarm will not sound again for the

current condition that caused the alarm until a new condition

occurs or until a Master Alarm Reset is performed.

A Master Alarm Reset can be performed by pressing Cooling

(ON/ OFF) twice or by turning the power to the refrigerator off and

on again. See “Power On/Off Switch.” After performing a Master

Alarm Reset, the indicator light will reactivate if the condition that

caused the alarm is still present. See “Over Temperature,” “Call

Service,” or “Door Open.”

Door Open

The Door Open indicator light will ash, an alarm will sound

and the interior lights will turn off when a door has been open

for longer than 10 minutes. When the door is closed, the audio

alarm will reset and turn off, but the Door Open indicator light

will continue to ash until the temperature is equal to or below

45°F (7°C) and 15°F (-9°C) for the refrigerator and freezer

compartments, respectively.

NOTE: To deactivate the audio alarm and indicator light, see

“Master Alarm Reset.”

Over Temperature

IMPORTANT: If the Over Temperature Alarm activates, your food

may spoil. See the “Power Interruptions.” Minimize door openings

until temperatures return to normal.

The Over Temperature feature is designed to let you know when

either the refrigerator temperature rises above 48°F (9°C) or

the freezer temperature rises above 15°F (-9°C) for longer than

1½ hours. The audio alarm will shut off automatically when the

temperature returns to normal, but the indicator light will continue

to ash until the Alarm is pressed to let you know that an over

temperature condition has occurred.

If the over temperature condition is still present when an Over

Temperature Reset is performed, the indicator light will continue

to reactivate every 1½ hours until refrigerator and freezer

temperatures are below 48°F (9°C) and 15°F (-9°C), respectively.

NOTE: The audio alarm will be disabled for subsequent

occurrences of over temperature alarm condition. To enable the

audio alarm, see “Master Alarm Reset.”

Sabbath Mode

The Sabbath Mode feature is designed for the traveler or for

those whose religious observances require turning off the lights

and ice maker. By selecting this feature, the temperature set

points and Deli Pan settings remain unchanged, the ice maker will

be disabled and the interior lights will turn off. For most efcient

refrigerator operation, it is recommended to exit the Sabbath

Mode when it is no longer required.

To fully activate Sabbath Mode, you must follow the instructions

below for both the control panel and dispenser panel (on some

models).
