ELK301J
USER MANUAL
ELECTRIC CITRUS JUICER
IMPORTANT SAFETY INSTRUCTIONS
Read all instructions carefully before use
1. Make sure that your outlet voltage is correspondent to the coffee machine “220-240V”
2. Place the electric juicer on a flat surface or on a table.
3. NEVER put appliance and cable in water or any other liquid to avoid electric shock.
4. DO NOT USE the electric juicer if the cord or any other part is damaged in order to reduce
the risk of electric shock. If you encounter any faults, please contact nearest KB ELEMENTS point
of sales.
5. Do not put weights on the cord, and keep it away from hanging over edges or touching hot
surfaces to avoid damage.
6. Do not place the electric juicer on or near objects that produce high temperatures such as
ovens, heaters, refrigerators, or stovetops.
7. Do not use attachments not recommended by KB ELEMENTS.
8. Always unplug the electric juicer when not in use or before cleaning, and always store it
in a dry place.
9. Ensure the motor has come to a complete stop before removing the press cone or filter sieve.
Never touch any moving parts during or immediately after operation.
10. Use only for juicing citrus fruits; do not use with hard or non-citrus fruits.
11. This appliance is intended for household use only. Commercial use is not permitted
And it is NOT intended for outdoor use.
12. Keep the appliance out of reach of children.
13. For optimal performance and to extend the appliance’s lifespan do not operate it continuously
for more than 2 minutes. Allow it to cool between uses.
14. Always clean the electric juicer after use.
TECHNICAL SPECIFICATIONS
Power Supply: AC 220-240V ~ 50/60Hz
Power: 300W
Juicing Capacity: Approx. 700ml
Motor Type: Copper Core
PRODUCT FEATURES
300W Powerful Motor – Efficient juice extraction
Interchangeable Press Cones – Accommodates small and large citrus fruits
Removable Stainless Steel Filter – For pulp-free or pulp-rich juice
Easy Pour Spout – Mess-free pouring
One-Touch Operation – Simple press-down activation
Compact and Easy to Clean – Perfect for everyday use
PRODUCT OVERVIEW
HOW TO ASSEMBLE AND USE
• Secure the Juice Cup Base: Align and firmly lock the juice cup base onto the front side
of the motor base.
• Install the Cap on the Press Lever: Insert the cap onto the press lever and tighten it securely.
• Assemble the Juicing Components: Insert the driving shaft, then place the juice collector and filter
sieve onto the motor base in sequence.
• Select and Attach the Appropriate Cone: Choose the suitable cone based on fruit size
(small or large). To juice larger citrus fruits, place the large cone over the small cone.
• Prepare the Fruit: Cut the citrus fruit in half. Place one half onto the cone with the cut side
facing downward.
• Position a Cup: Place a cup under the juice spout. Push the anti-drip spout downward
to allow juice flow.
• Start Juicing: Plug in the appliance. Press the lever downward, holding the citrus half firmly
onto the cone using the cap. Juicing will begin automatically.
• After Use: Lift the press lever and raise the juice spout to prevent dripping. Unplug the appliance
and remove the cone, filter sieve, juice collector, and driving shaft for cleaning.
1. Press Lever
2. Motor Base
3. Cap
4. Big Cone
5. Small Cone
6. Filter Sieve
7. Juice Collector
8. Juice Spout
9. Driving Shaft
10. Cup Base
BEFORE FIRST USE – QUICK START GUIDE
• Unpack the juicer and remove all packaging. Keep materials away from children to
prevent suffocation.
• Inspect all parts for damage and ensure everything is complete and in good condition.
• Clean all removable parts (cones, filter sieve, juice collector) with warm soapy water;
wipe the motor base with a damp cloth. Air dry thoroughly before use.
• Place the appliance on a flat, stable surface for safe operation.
• Select the Appropriate Cone:
-Small cone – for lemons, limes
-Large cone – for oranges, grapefruits (attach over the small cone)
-To separate cones, lift the large cone off.
• Juice Collection Options:
-Close spout (upward) to collect juice in the juice collector
-Open spout (downward) to allow juice to flow directly into a cup
• Use Gentle Pressure:
Excessive force on the cone may stall the motor.
• Automatic Operation:
The juicer activates when fruit is pressed onto the cone and stops when pressure is released.
Juice passes through the filter sieve, which separates seeds and pulp.
• Tip for Maximum Juice:
Press the fruit onto the cone multiple times to extract the most juice.
CLEANING AND MAINTENANCE
Always unplug the appliance before cleaning.
Remove the juice bowl, filter, and cone.
Wash all removable parts in warm, soapy water. Rinse and dry thoroughly.
Wipe the motor base with a damp cloth.
Note: Avoid using abrasive cleaners or scouring pads.
Do not immerse the motor base in water.
STORAGE & DISPOSAL
Before Storage: Ensure the appliance is unplugged and has fully stopped. Air dry and wipe all detachable
parts, then reassemble following the instructions in the Assembly & Use section. Store the appliance in a
clean, dry, and flat location.
Disposal: Do not dispose of the appliance with household waste. Recycle it responsibly through designated
collection facilities to protect the environment and promote the reuse of materials.
To know more about this product, please visit our youtube channel
www.kbelements.de
Please read this manual carefully and retain for future references.
