5

COOKTOP USE

Cooktop Controls

Electric igniters automatically light the surface burners when

control knobs are turned to HI and will automatically reignite if

the flame is extinguished.

NOTE: All igniters will spark when lighting; however, only the

selected burner will ignite.

If a cross draft is present, the flame may be affected and some

sparking may occur. This is normal.

Before setting a control knob, place filled cookware on the

grate. Do not operate a burner using empty cookware or without

cookware on the grate.

Lighting the Burners

IMPORTANT: All burners will click/spark when a knob is pushed

in. A burner will light only if the knob is pushed in and then turned

counterclockwise to IGNITE.

To light the burners:

1. Push in the knob.

2. Turn the knob counterclockwise to IGNITE. Wait until you see

a flame.

3. Turn the knob to anywhere between HI and LO to the desired

setting.

Setting Recommended Use

HI

■ Start food cooking.

■ Bring liquid to a boil.

■ Hold a rapid boil.

■ Quickly brown or sear food.

■ Fry chicken.

Medium between

HI and LO

■ Maintain a slow boil.

■ Fry or sauté foods.

■ Cook soups, sauces, and gravies.

■ Stew or steam food.

LO

■ Simmer.

■ Keep food warm.

Power failure

In case of prolonged power failure, the surface burners can

be lit manually. Hold a lit match near a burner and turn knob

counterclockwise to HI. After burner lights, turn knob to setting.

The vent fan will not work.

NOTE: The downdraft vent will not operate during a power failure.

Flame-Sensing™ Reignition

Your cooktop has sealed gas burners with Flame-Sensing™

Reignition. If any burner flame should go out, the system will

automatically spark to reignite the burner (all igniters will spark

when any flame is extinguished; however, only the selected

burner will reignite). If intermittent sparking occurs, increase flame

(rotate knob clockwise) until clicking (spark) sound ceases.

Smart Port Burner System

This cooktop is equipped with a Smart Port Burner System. The

Smart Port Burner System produces a small flame directly under

each grate finger and a larger flame between each grate finger. The

visual difference between the ports will be noticeable when the

burner is used or when adjustments are made to the flame length.

Sealed Surface Burners

IMPORTANT: Do not obstruct the flow of combustion and

ventilation air around the burner grate edges.

Burner cap: Always keep the burner cap in place when using a

surface burner. A clean burner cap will help avoid poor ignition

and uneven flames. Always clean the burner cap after a spillover

and routinely remove and clean the caps according to the

“General Cleaning” section. Each round burner base is marked

with letters indicating the burner size.

Alignment: Be sure to align the gas tube opening in the burner

base with the orifice holder on the cooktop and the igniter

electrode with the notch in the burner base.

Gas tube opening: Gas must flow freely throughout the gas

tube opening for the burner to light properly. Keep this area free

of soil and do not allow spills, food, cleaning agents, or any other

material to enter the gas tube opening. Keep spillovers out of the

gas tube by always using a burner cap.

Burner ports: Check burner flames occasionally for proper size and

shape as shown in the previous illustration. A good flame is blue in

color, not yellow. Keep this area free of soil and do not allow spills,

food, cleaning agents, or any other material to enter the burner ports.

WARNING

Fire Hazard

Do not let the burner flame extend beyond the edge of

the pan.

Turn off all controls when not cooking.

Failure to follow these instructions can result in death

or fire.

REMEMBER: When cooktop is in use, the entire cooktop

area may become hot.

A

B

C

A. Cap

B. Spreader

C. Electrode

A

B

A. Low flame

B. High flame
