Bruksanvisning Indesit IDVL 75 BRS.9 UK Torktumlare

Bruksanvisning

2

GB

Installation

10

m

m

15 mm

15 mm

15 mm

15 mm

B

A

Where to install the tumble dryer

If the dryer is installed below a worktop,

ensure there are 10 mm

between the upper panel

of the dryer and any

objects above it, and 15

mm between the sides

of the machine and the

walls or furniture units

adjacent to it. This en-

sures adequate air cir-

culation. Make sure the

air inlets on the rear panel are not blocked or

obstructed.

Ventilation

This appliance gently dries laundry by taking in cold, clean

and relatively dry air, heating it and passing it through the

fabric. To facilitate the drying process, damp air is expelled at

the rear, through a ventilation hose. When the dryer is in use,

there has to be adequate ventilation to avoid a back flow

of gases into the room from appliances burning other fuels,

including open fires.

Mobile ventilation system

When using the tumble dryer with the mobile ventilation

system, a ventilation hose must be connected. The hose

should be securely fastened to the ventilation hole at the

rear of the appliance (see “Description of the tumble dryer”).

We recommend the hose is connected to an outlet near

the tumble dryer, if possible. If it cannot be installed in a

permanent spot, the tumble dryer will still function perfectly

well if the ventilation hose is passed through a partially-

opened window.

Make sure you do not point the ventilation hose towards the

air inlet, which is located on the rear of the appliance.

The ventilation hose should not exceed a maximum length

of 2.4 metres; it should also be shaken frequently to remove

any fluff, dust or water deposits inside it. Make sure you do

not crush the hose.

Fixed ventilation system

We recommend the ventilation hose is connected to a

ventilation system for windows or doors, available from the

retailer which originally sold you the appliance or from your

local spare parts stockist.

Wall ventilation hole

1. Leave an opening in the wall to the left of the tumble dryer

installation site.

2. Make the hose as short and straight as possible, in order

to prevent any moisture from condensing and leaking back

into the appliance.

3. The hole in the wall must also be straight and pointing

downwards, so that the flow of air coming out is not

impeded.

Areas A and B should be checked frequently, to prevent

the accumulation of fluff or debris, particularly if the tumble

dryer is used very often. The hose adaptor must be fitted

correctly, in order to prevent damp air from coming back into

the room.

Window ventilation hole

The ventilation hole should be

directly behind the dryer in order

to keep the hose as short as

possible.

Make sure you do not push the

tumble dryer too far backwards,

as this could lead to the

ventilation hose being crushed,

bent or even disconnected.

There should be no cuts, kinks or “U”-shaped bends

in the hose, as these could impede ventilation or trap

condensation.

The end of the hose must be facing downwards, in order to

prevent the hot, damp air from forming condensation in the

room or the tumble dryer.

Make sure that the tumble dryer is adequately ventilated,

and that the end of the ventilation hose is not pointing

towards the air inlet pipe on the

rear of the appliance.

The ventilation hose must

always be fitted to ensure

optimum performance.

Make sure that the ventilation

hose and the air inlet vents are

not obstructed or blocked.

Do not let the tumble dryer

recirculate exhaust air.

Improper use of the tumble dryer may result in fire hazards.

Ventilation through an open window

The air emitted by the tumble dryer must not be expelled in

the same duct as used for the fumes produced by different

appliances which burn gas or

other fuels.

Do not discharge the exhaust

air into an extraction system

or any duct with an extractor

fan. This will affect the way the

thermal controls operate and

can result in a fire hazard.

Make sure that the

room in which the tumble dryer is installed

is not damp, and that it is adequately

ventilated.

We do not recommend that the dryer is

installed in a cupboard but the dryer must

never be installed behind a lockable door, a

sliding door or a door with a hinge on the

opposite side to that of the dryer door.

The appliance must be installed with the
