G).2.4-,4'$(-3&&4-).4-<0=&.4>2?.2

• Install the dryer far from gas

ranges, stoves, radiators or

hobs, as flames may damage it.

If the dryer is installed below a

worktop, ensure there are 10

mm between the upper panel of

the dryer and any objects

above it, and 15 mm between

the sides of the machine and

the walls or furniture units

adjacent to it. This ensures

adequate air circulation.

a.$-'&3-',$

• The room must be adequately ventilated while the dryer is

running. Make sure that the dryer is installed in a room free of

humidity and with adequate air circulation. The flow of air

around the dryer is essential to allow water to condense

during drying; the dryer will not function properly if it is placed

in an enclosed space or inside a cabinet.

! Some condensation may form if the dryer is used in a small

or cold room.

! We do not recommend that the dryer is installed in a

cupboard but the dryer must never be installed behind a

lockable door, a sliding door or a door with a hinge on the

opposite side to that of the dryer door.

G3-.24>23'$

If your dryer is installed next to a drain the water can be

plumbed into this drain. This does away with the need to

empty the water container. If the dryer is stacked onto or

installed next to a washing machine it can share the same

drain. The height of the drain must be less than 3' (1 m)

from the bottom of the dryer.

Remove existing hose from position shown in picture !

and fit a suitable length of hose and connect as shown

in picture ".

! #$%&'()*&'+,$+'+,&',-(&'.(' /-+'(0)$(,&1'-*'%./%&1

2,&/'+,&'1*3&*'.('./'.+('4./$5'5-6$+.-/7

1

0

m

m

15 mm

15 mm

15 mm

15 mm

1

2

2

1

Less than 1m

Picture ! Picture "

/$(-3&&3-',$

!&.;-2';3&4;,$$.;-',$(

Before plugging the appliance into the socket, check the

following:

• Make sure your hands are dry.

• The socket must have an earth connection.

• The socket must be able to withstand the machine’s

maximum power output as indicated on the data plate (see

Description of the tumble dryer).

• The power supply voltage must fall within the values

indicated on the data plate (see Description of the tumble

dryer).

• The socket must be compatible with the machine’s plug. If

not, either the socket or the plug must be replaced.

! Do not use extension cords.

! The tumble dryer must not be installed in outdoor spaces,

even if sheltered. It may be very dangerous to expose this

appliance to rain and thunderstorms.

! Once dryer installation is complete, the electric cord and

plug must be at hand.

! The electric cord must not be bent or crushed.

! If the plug to be replaced is of the moulded-on type, it

must be disposed of in a safe way. DO NOT leave it where it

can be plugged into a socket and cause electric shocks.{}

! The electric cord must be regularly checked and replaced

with a cord specifically designed for this dryer; it must then

be installed by an authorised technician only (see

Assistance). New or longer electric cords are supplied by

authorised dealers at a supplementary cost.

!'8,&'9$/)4$6+)*&*'1&65./&('$55'*&(:-/(.;.5.+3'4-*'4$.5)*&

+-'-;(&*<&'+,&(&'./(+*)6+.-/(7

!'=,&/'./'1-);+'$;-)+'+,&'$;-<&'./1.6$+.-/(>'6-/+$6+'$

0)$5.4.&1'&5&6+*.6.$/7

V2.&'0'$32?4'$5,203-',$

Once the tumble dryer is installed, clean the inside of the

drum before operating it and remove any dirt accumulated

during transportation.
