Bruksanvisning Imarflex ITS-516AF Ugn

Bruksanvisning

SPECIFICATION:

MODEL NO. : ITS-516AF

RATED VOLTAGE : 230Va.c. 60Hz

POWER CONSUMPTION : 1200W

BOX DIMENSION : 419*370*425mm

UNIT DIMENSION : 384*348*354mm

GROSS WEIGHT : 5.29kg

UNIT WEIGHT : 6.51kg

IMPORTANT SAFEGUARDS:

When using electrical appliances, basic safety precautions should always be followed,

including the following:

1. Read all instructions carefully.

2. Before using the oven toaster, check if the voltage indicated corresponds with the

convenience outlet (230Va.c.).

3. Do not use two-way socket with another appliance.

4. Do not use any appliance with a damaged cord or plug. If the cord is damaged it should

be replaced with the same type and size or bring the unit to the nearest authorized

service center.

5. Put the unit on stable surface; keep it away from the edge of counter to avoid accident.

6. Keep curtains, furniture, flammable materials, etc. away from the unit and from the

convenience outlet where the unit is plugged in.

7. Do not place the oven toaster near gas stove or electric stove.

8. The unit needs at least 10 cm clearance space on all sides and at least 30 cm

above. This is to allow adequate air circulation.

9. This appliance is not intended for use by persons (including children) with reduced

physical, sensory or mental capabilities, or lack of experience and knowledge, unless

they have been given supervision or instruction concerning use of the appliances by a

person responsible for their safety.

10. Children should be supervised to ensure that they do not play with the appliance.

11. Do not immerse the unit in water.

12. Do not use this unit other than its intended use.

13. Avoid touching the oven toaster surface while cooking is in progress or even after use.

While the oven toaster is in use avoid the glass from getting wet to avoid breakage.

14. Minor metal contraction sound may occur during operation but this is normal.

15. For household use only; not intended for any business purposes.

16. In case of malfunctions, please bring the unit to the nearest Authorized Imarflex Service

Center.

17. Save this instruction for future reference.

DESCRIPTION OF PARTS:

Cooking Tips

1. Ensure there is adequate ventilation around the oven during use.

2. Do not place the oven on untreated wooden surfaces.

3. During the first use, light smoke may be emitted, this is normal and should

disappear within 5 to 15 minutes.

4. For better cooking performance, it’s recommended to preheat the oven for 10 to

15 minutes.

5. Lightly oil the baking tray or wire rack before placing food to prevent sticking.

6. Always place a drip tray beneath the rack to catch any oil or food drippings.

7. When cooking oily foods like chicken, wrap them in two layers of aluminum foil to

reduce oil splatter.

FUNCTION & HEAT SELECTOR:

1. AF (Air Fryer)

- The Air Fryer function uses the upper + lower heating elements and convection fan to

circulate hot air at high speed. This allows food to cook evenly with a crispy, fried-like texture

using little to no oil.

- Use for cooking French fries, Chicken wings, Nuggets, Frozen snacks, Roasted vegetables

- For best results, arrange food in a single layer.

- Shake or turn food halfway through cooking if needed.

2. Upper Heater + Convection

- This function uses the upper heating element together with the convection fan, circulating

hot air from the top for fast, even cooking and enhanced crisping.

- Use for cooking Gratin dishes, Garlic bread, roasting vegetables, melting cheese toppings,

Air frying lighter foods

- Speeds up browning and crisping, promotes even heat distribution, great for open-faced or

top-layer cooking

3. Upper Heater

- Activates only the top heating element

- Best for Broiling or browning the top of dishes, melting cheese or crisping the surface

- Use for cooking Garlic bread, casseroles, gratins

4. Lower Heater

- Activates only the bottom heating element

- Best for Baking from the bottom, gentle heat for dough rising or slow cooking

- Use for cooking Bread, pizza crust, pastry bases

5. Upper + Lower Heater

- Activates both top and bottom elements, provides even, all-around heat

- Best for Roasting, baking, and general cooking

- Use for cooking Cakes, cookies, poultry, vegetables

6. Steam Boost Function

- The Steam Boost function provides an intensive burst of steam during cooking to help retain

moisture, improve texture, and enhance flavor especially for meats, bread, and baked

goods.

- Use for cooking Whole chicken or roast meats, Artisan bread (for crisp crust and soft

interior), Reheating leftovers without drying out

- Uses water from the water inlet and tray to generate high steam output for a short duration.

- Helps lock in moisture and produce juicier, more tender results.

HOW TO USE:

1. Place the oven on a flat, heat-resistant surface, then plug it in.

2. Set the temperature, time, function and heat selector.

- Preheat the oven for 10–15 minutes before inserting food.

- Note: If setting a timer under 5 minutes, first turn the timer past 10 minutes, then turn back

to the desired time.

3. Cook one tray or rack at a time to ensure even cooking.

4. Monitor cooking through the glass door. For larger or thicker foods, turn them over once

or twice during cooking.

- Open the door only when necessary, and close it promptly to maintain temperature.

5. When cooking is complete, the timer will automatically shut off with a bell ring.

- If food is done early, turn the timer knob to OFF to stop the oven.

6. Carefully remove your food, use oven mitts as parts may be hot.

Convection Function:

1. Position the oven rack in the middle or lower level, depending on the type of food being

cooked.

2. Place your food inside the oven. Select your desired cooking function, then set function to

convection to start the fan.

3. When the cooking time ends, the convection fan will turn off automatically.
