Bruksanvisning Imarflex IRS-501C Strykjärn

Bruksanvisning

SPECIFICATION:

Model No : IRS-501C

Input Voltage : 230 Va.c. 60Hz

Power : 2200W

Box Dimension : 30*12.6*16.3cm

Unit Dimension : 28.9*12.3*14.4cm

Gross Weight : 1.20kg

Unit Weight : 1.05kg

IMPORTANT SAFEGUARDS:

When using electrical appliances, basic safety precautions should always be

followed, including the following:

1. Read all instruction carefully.

2. Before using the unit, check if the voltage indicated corresponds with

convenience outlet (230Va.c.).

3. Do not use any appliance with a damaged cord or plug. If the cord is

damaged it should be replaced with the same type and size or bring the

unit to the nearest authorized service center.

4. Do not leave the iron unattended while it is connected to the

convenience outlet.

5. Children should be supervised to ensure that they do not play with the

appliance.

6. This appliance is not intended for use by persons (including children)

with reduced physical, sensory or mental capabilities, or lack of

experience and knowledge, unless they have been given supervision or

instruction concerning use of the appliances by a person responsible for

their safety.

7. Do not use two-way socket with another appliance.

8. To protect against electric shock, do not immerse the iron in water.

9. Unplug the iron when filling with water; emptying the tank or after using

the iron.

10. The iron should always be turned OFF before plugging or unplugging

from the outlet.

11. Do not allow cord to touch hot surface of the iron. Loop cord loosely

around the iron before storing.

12. For household use only; not intended for any business purposes

13. Save this instruction for future reference.

DESCRIPTION OF PARTS:

1. Steam Burst Control – Switch to steam burst control to provide steam

that eliminates stubborn wrinkles

2. Spray Button- pressing this button provides a fine mist spray to dampen

hard to iron fabrics.

3. Variable Steam Button- slide this button to select the desired

continuous water output: “o” position indicates ironing without steam.

4. Water Inlet

5. Spray Nozzle

6. Thermostat Control Knob- to select desired fabric temperature.

For initial use:

1. Remove protective cover on the soleplate.

2. Heat up the iron to maximum temperature and iron a piece of damp

cloth for several minutes to remove any residue on the soleplate.

Note: It is normal that strange odor comes out from the unit during the

Initial use.

Using as Dry Iron:

1. Plug the iron to the convenience outlet.

2. Set thermostat control knob at desired temperature setting (see table

guide).

3. Allow the iron to heat for two minutes on heel rest position before

ironing.

4. The power light indicator will turn ON when the iron is switch ON, the

power light indicator will turn OFF once the temperature has been

attained. The power light indicator will remain OFF as long as the iron

keeps the selected temperature, as the temperature decreases, the

thermostat will start working; the power light indicator will turn ON again.

5. First, iron synthetic fabric at low temperature, and then as the

temperature rises, iron wool, cotton, and linen accordingly. The iron

heats more quickly than it cool.

6. Allow time for the iron to heat when changing from a low temperature to

high.

Using as Steam Iron

1. At ironing position, fill water through the water inlet. Make sure that the

water should not exceed the MAX level indicator (380ml). Press down

the cover.
