Bruksanvisning Imarflex IRS-500E Strykjärn

Bruksanvisning

SPECIFICATION

Model No : IRS-500E

Input Voltage : 230 Va.c. 60Hz

Power : 2200W

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should always be followed,

including the following:

1. Read all instruction carefully.

2. Before using the unit, check if the voltage indicated corresponds with

convenience outlet (230Va.c.).

3. Do not use any appliance with a damaged cord or plug. If the cord is damaged it

should be replaced with the same type and size or bring the unit to the nearest

authorized service center.

4. Do not leave the iron unattended while it is connected to the convenience outlet.

5. Children should be supervised to ensure that they do not play with the appliance.

6. This appliance is not intended for use by persons (including children) with

reduced physical, sensory or mental capabilities, or lack of experience and

knowledge, unless they have been given supervision or instruction concerning

use of the appliances by a person responsible for their safety.

7. Do not use two-way socket with other appliance.

8. To protect against electric shock, do not immerse the iron in water.

9. Unplug the iron when filling with water; emptying the tank or after using the iron.

10. The iron should always be turned OFF before plugging or unplugging from the

outlet.

11. Do not allow cord to touch hot surface of the iron. Loop cord loosely around the

iron before storing.

12. For household use only; not intended for any business purposes

13. Save this instruction for future reference.

DESCRIPTION OF PARTS:

1. Steam Burst Button- pressing this button provides steam to eliminate stubborn

wrinkles

2. Spray Button- pressing this button provides a fine mist spray to dampen hard to

iron fabrics.

3. Variable Steam Button- slide this button to select the desired continuous water

output: “o” position indicates ironing without steam.

4. Water Inlet

5. Spray Nozzle

6. Thermostat Control Knob- to select desired fabric temperature.

For initial use:

1. Remove protective cover on the soleplate.

2. Heat up the iron to maximum temperature and iron a piece of damp cloth for

several minutes to remove any residue on the soleplate.

Note: It is normal that strange odor comes out from the unit during the Initial use.

Using as Dry Iron:

1. Plug the iron to the convenience outlet.

2. Set thermostat control knob at desired temperature setting (see table

guide).

3. Allow the iron to heat for two minutes on heel rest position before ironing.

4. The power light indicator will turn ON when the iron is switch ON, the power

light indicator will turn OFF once the temperature has been attained. The

power light indicator will remain OFF as long as the iron keeps the selected

temperature, as the temperature decreases, the thermostat will start

working; the power light indicator will turn ON again.

5. First, iron synthetic fabric at low temperature, and then as the temperature

rises, iron wool, cotton, and linen accordingly. The iron heats more quickly

than it cools.

6. Allow time for the iron to heat when changing from a low temperature to

high.

Using as Steam Iron

1. At ironing position, fill water through the water inlet. Make sure that the water

should not exceed the MAX level indicator (350ml) (see fig 1). Press down the

cover.

2. Plug into the convenience outlet and turn thermostat control knob to desired

temperature setting (see fig 2 & table guide). Position the unit on a heel rest

position.

3. Set the variable steam selector to desire steam output (see fig 3) and begin

ironing.

a. Use steam burst button for intermittent steam, or

b. Use spray button for water spray.

Fig.2
