Bruksanvisning Imarflex IMX-300P Elvisp

Bruksanvisning

SPECIFICATION

MODEL NO. : IMX-300P

RATED VOLTAGE : 230Va.c. 60Hz

POWER CONSUMPTION : 300 Watts

BOX DIMENSION : 330x222x250mm

UNIT DIMENSION : 309x219x351mm

GROSS WEIGHT : 2.74kg

UNIT WEIGHT : 2.17kg

IMPORTANT SAFEGUARDS:

When using electrical appliances, basic safety precautions should always be

followed, including the following:

1. Read all instructions thoroughly.

2. Before using the unit, check if the voltage indicated corresponds with the

convenience outlet (230Va.c.).

3. Do not use the two-way socket with another appliance.

4. Do not use any appliance with a damaged cord or plug. If the cord is damaged it

should be replaced with the same type and size or bring the unit to the nearest

Imarflex Authorized Service Center.

5. Do not place the unit near a gas stove, an electric burner or in a heated oven.

6. Place the unit on stable surface; keep it away from the edge of counter to avoid

accident.

7. Children should be supervised to ensure that they do not play with the appliance.

8. This appliance is not intended for use by persons (including children) with reduced

physical, sensory or mental capabilities, or lack of experience and knowledge,

unless they have been given supervision or instruction concerning use of the

appliances by a person responsible for their safety.

9. Unplug mixer from the outlet when not in use, before inserting or removing parts,

and before cleaning.

10. Refrain from using the accessories with different function (one beater and one

dough hook) at the same time.

11. Keep curtains, furniture, flammable materials, etc. away from the unit and from the

convenience outlet where the unit is plugged in.

12. Avoid contacting moving parts. Keep hands, hair, clothing, as well as spatulas and

other utensils away from beater during operation to prevent injury, and/or damage

to the mixer.

13. The maximum continuous operating time of the mixer is five minutes only. Do not

exceed with the maximum operating time. It may cause damage to the unit.

14. Do not let cord hang over edge of table or counter, or touch hot surfaces.

15. To protect against electric shock, do not immerse the unit in water or any other

liquid.

16. This appliance is not intended for outdoor use.

17. Never place the mixer near hot surfaces.

18. In case of malfunctions, please bring the mixer to the nearest authorized Imarflex

Service Center.

19. Avoid water spillage into the socket, connector, cord and alike.

20. Do not use this unit other than its intended use.

21. For household use only; not intended for any business purposes

22. Save this instruction manual for future reference.

23. CAUTION: In order to avoid a hazard due to inadvertent resetting of the thermal

cutout, this appliance must not be supplied through an external switching device,

such as a timer, or connected to a circuit that is regularly switched on and off by

the utility.

CAUTION: This unit has an overload protection device. The unit will

automatically turn OFF to prevent overheating and will automatically

turn ON once it cools down. THEREFORE, the unit should be TURNED

OFF and UNPLUGGED as soon as the unit shuts down automatically

DESCRIPTION OF PARTS:

HOW TO USE:

For initial use, wash the beaters and dough hooks with soap

and water then rinse thoroughly and let it dry.

1. INSERTING THE BEATERS

a. Be sure that the Speed Control is in “OFF’ position.

b. Insert the edge of the Beaters and align the flange on slot

one by one and push until it fits (a click sound will be

heard). The beater with gear must be inserted into the

right slot. (See fig. 1)

2. INSERTING THE DOUGH HOOKS

a. Insert the edge of the Dough Hooks and align the flange on

slot one by one and push until it fits (a click sound will be

heard). The dough hook with gear must be inserted into the

right slot. (See fig. 2)

3. PLACING MIXER ON STAND

a. Align the bottom part of the mixer on the slot and press it

down. (See fig. 3)

4. MIXING

a. Lift up the movable support with the mixer by pressing the

Neck Release Button. (See fig. 4)

b. Place the mixing bowl on the rotating plate (See fig.5)

Press the neck release button again and push down the

Movable support with mixer. (See fig. 6)

c. Start blending or mixing at a low speed, add more speed

as you follow recipe instruction (ingredients can slowly

be added during mixing). Speed is from 1 to 5 with Turbo

Button.

d. Turn OFF after use.
