WASH CYCLES
Follow the instructions on the symbols of the garment’s wash
care label. The value indicated in the symbol is the maximum
recommended temperature for washing the garment.
Anti-Stain Turbo
this programme is ideal for washing the most dicult daily stains in 1
hour. It is ideal for mixed fabrics and coloured garments, caring for your
clothes as it washes. .
Anti-Stain 40°
the programme is suitable to heavily-soiled garments with resistant
colours. It ensures a washing class that is higher than the standard class (A
class).
When running the programme, do not mix garments of dierent colours.
We recommend the use of powder detergent. Pre-treatment with special
additives is recommended if there are obstinate stains.
Cotton
Suitable for washing towels, underwear, table cloths, etc. made of
resistant linen and cotton that are moderately to heavily soiled.
Synthetics
Specic for synthetic items. If the dirt is dicult to remove, the
temperature can be increased up to 60° and powder detergent can be
used too.
Rapid 30’
For washing lightly soiled garments in a short time. Not suitable for wool,
silk and garments to be washed by hand.
Mix Wash & Dry
use programme 6 to wash and dry mixed garments (cotton and
synthetics). This cycle may be used to wash and dry loads of up to 3.5 kg;
we recommend the use of liquid detergent.
The use of the steam in this programme is optimised to reduce the
formation of creases on garments, making them easier to iron.
Shirts Wash & Dry
Use programme 7 to wash and dry shirts and T-shirts in dierent fabrics
and colours to ensure maximum care. This cycle may be used to wash and
dry loads of up to 2 kg. To achieve optimum results, use liquid detergent
and pre-treat cus, collars and stains. The use of the steam in this
programme is optimised to reduce the formation of creases on garments,
making them easier to iron.
Wool - Woolmark Apparel Care - Green:
the wool wash cycle of this machine has been approved
by The Woolmark Company for the washing of wool
garments labelled as “hand wash” provided that the
products are washed according to the instructions on the
garment label and those issued by the manufacturer of
this washer-dryer. (M1318)
Eco 40-60
For washing normally soiled cotton garments declared to be washable at
40 °C or 60 °C, together in the same cycle. This is the standard cotton
programme and the most ecient in terms of water and energy
consumption.
20°C
For washing lightly soiled cotton garments, at a temperature of 20 °C.
White
For heavily soiled whites and resistant colours.
Anti Allergy
Suitable for removing major allergens such as pollen, mites and cat or dog hair.
Steam Refresh
For refreshing garments, neutralised unpleasant odours and relaxing the
bres by delivering steam into the drum. The garments will be damp at
the end of the cycle.
Ultradelicates
For washing very delicate garments. It is advisable to turn the garments
inside out before washing them. For best results, use liquid detergent on
delicate garments.
We recommend turning the garments inside out before washing and
placing small items into the special bag for washing delicates. Use liquid
detergent on delicate garments for best results.
When selecting an exclusively time-based drying function, a drying cycle
is performed at the end of the wash cycle that is particularly delicate,
thanks to light handling and appropriate temperature control of the
water jet.
The recommended durations are:
1 kg of synthetic garments --> 150 min
1 kg of synthetic and cotton garments --> 180 min
1 kg of cotton garments --> 180 min
The degree of dryness depends on the load and fabric composition.
Rinse&Spin
Designed for rinsing and spinning.
Spin&Drain
Designed for spinning and draining the water.
Eco Cotton
For washing normally soiled cotton garments at 60°C.
DISPLAY
The display is useful when programming the washer-dryer and provides
plenty of information.
Section A displays the duration of the various available wash cycles and,
once the cycle starts, the time remaining to the latter’s end (the display will
show the maximum duration of the selected cycle which may decrease
after a few minutes, as the actual duration varies in relation to the laundry
load and the chosen settings); if the Delay option was set, the display will
show the time remaining to the start of the selected wash cycle.
Moreover, pressing the relative button allows for visualising the maximum
values for the temperature, spin speed or type of drying relative to the
selected programme or the most recently selected ones, if compatible
with the selected programme.
The “washing phases” relative to the selected cycle and the “washing
phase” of the running cycle appear in section B:
Main Wash
Rinse
Spin/Pump out
Drying
Section C displays – starting from the left – the icons corresponding to
“temperature”, “spin” and “drying”.
The “temperature” bars indicate the maximum temperature level
that can be selected for the chosen cycle.
The “spin” bars indicate the maximum spin speed that can be
selected for the chosen cycle.
The symbol lights up while the drying settings are being adjusted.
LOCKED DOOR INDICATOR
When lit, the symbol indicates that the door is locked. To prevent any
damage, wait until the symbol turns o before opening the door.
To open the door while a cycle is in progress, press the START/PAUSE
button ; if the symbol is o, the door can be opened.
FIRSTTIME USE
Once the appliance has been installed, and before it is used for the rst
time, run a wash cycle with detergent and no laundry, by setting the
“Auto-Clean” cycle.
DAILY USE
Prepare the laundry by following the suggestions appearing under the
“TIPS AND SUGGESTIONS” section.
- Press the ON/OFF button ; the indicator light relative to START/PAUSE
will ash slowly green.
- Open the door. Load the laundry while making sure not to exceed the
maximum load quantity indicated in the wash cycle table.
- Pull out the detergent dispenser drawer and pour the detergent into the
relevant compartments, as described in the “DETERGENT DISPENSER
DRAWER” section.
- Close the door.
- The machine automatically displays the maximum temperature and spin
speed values for the selected cycle, or the most recently used settings if
they are compatible with the selected cycle. Pressing the button
gradually reduces the temperature down to the cold wash “OFF” setting.
Pressing the button gradually reduces the spin speed until it is
completely excluded (“OFF” setting). Pressing the buttons further restores
the maximum allowed values for the selected cycle.
- Select the desired wash cycle.
- Select the desired options.
- Press the START/PAUSE button to start the wash cycle; the relative
indicator light will light up steady green and the door will lock ( symbol on).
PAUSING A CYCLE
To pause the wash cycle, press the START/PAUSE button again; the
indicator light will ash amber. To start the wash cycle from the point at
which it was interrupted, press the START/PAUSE button again.
OPENING THE DOOR, IF NECESSARY
Once a cycle starts, the symbol turns on to signal that the door cannot
be opened. While a wash cycle is running, the door remains locked. To
open the door while a cycle is under way, for example, to add or remove
garments, press the START/PAUSE button to pause the cycle; the
indicator light will ash amber. If the symbol is not lit, the door may be
opened. Press the START/PAUSE button again to continue the cycle.
CHANGING A RUNNING WASH CYCLE
To change a wash cycle while it is in progress, pause the washer-dryer using
the START/PAUSE button (the relative indicator light will ash amber),
B
C
A
