The simple instructions below are designed to help with the programming of the unit. All the following

instructions require the front flap to be lowered. Please replace the flap when

normal operation is required.

Electronic equipment can in some circumstances be affected by electrical interference. If the

programmer’s display becomes frozen or scrambled; or if you wish to revert back to the default time

settings please use the following procedure.

FRONT COVER

SETTING TIME OF DAY

SETTING THE ON AND OFF TIMES

Should you encounter any problems, please refer to the

Question and Answer section located on page 4

The normal working position for the SET switch is in the PROG.RUN position. In order to remind the user

of this, the flap is unable to be closed with the switch in any other position.

RESETTING THE PROGRAMMER

The SET slide switch must be in the PROG.RUN position for the following instructions.

Press SELECT once.

Programme goes from

AUTO to ALL DAY

Press SELECT again.

Programme goes from

ALL DAY to ON

Press SELECT again.

Programme goes from

ON to OFF

Press SELECT again.

Programme goes from

OFFto AUTO

Unit will operate from

first ON until last OFF

period

Unit will be

continuously ON

Unit will be

continuously OFF

Programmer will return

to normal ON and OFF

times

BOOST FUNCTION- 1 or 2 hour temporary override

Press BOOST button once:

Your System will be Boosted

for 1 hour

Press BOOST button twice:

Your System will be Boosted

for 2 hours

At any time during a BOOST

period press BOOST again to

return to normal program-

ming

ADVANCE FUNCTION

-

Brings forward next on or off operation

Press ADVANCE button once

to move to the next

ON/OFF time

To cancel the advance press the ADVANCE

button again. This will return the unit to

its normal programme

HOLIDAY FUNCTION

-

Allows system to be programmed for up to 32 days

Move SET switch to the

HOLIDAY position

Use the PLUS button to enter the

required number of nights

(MAX OF32NIGHTS)

Return SET switch to the

PROG.RUN position

Whilst the HOLIDAY FUNCTION is in operation the system will remain OFF, the display will show the

number of nights remaining. The HOLIDAY setting is an instant function and cannot be set in advance.

The HOLIDAY FUNCTION can be cancelled at any time by pressing any of the SELECT buttons.Normal

programme functions will resume at the first ON period after the pre-set number of nights has expired.

INFORMATION AND ADVICE

Programming ON/OFF times

If a period is not required it can be cancelled by setting the ON and OFF settings to the same

time. Example ON 10:00am OFF 10:00am

Your programmer will prevent you from accidentally overlapping ON and OFF times.

Example: If the 2nd ON time is set at 12:00pm and then you try and set the 1st OFF at 12:30 pm the

OFF setting will ‘bounce’ by a 10 minute period until the 2nd ON time has been adjusted.

08

SETTING

AUTO

ON UNTIL

11:30

AM

AUTO

ON UNTIL

10:30

AM

ALL DAY

ON UNTIL

8:30

PM

ON

OFF

ADVANCE

SELECT

Lower the front flap of the unit. Press the ADVANCE and SELECT

buttons together then release the buttons and the programmer will

return to the preset factory settings.

Page 2

BOOST

SPECIAL FEATURES

Page 3

10:00AM

Move the SET

switch to the CLOCK

position.

Use PLUS and

MINUS buttons to

adjust time

Return SET switch to

PROG.RUN position

12:OOPM

SETTING

1:45PM

SET

Move SET switch

to the

ON/OFF TIMES

position.

Use the PLUS and

MINUS buttons to

adjust the 1st ON

time.

Use the PLUS and

MINUS buttons to

adjust the 1st OFF

time.

Repeat this

process for 2nd and

3rd setting.

Return SET

switch to PROG.RUN

position.

Press

ENTER

Press

ENTER

SETTING1ST

ON OFF

6:30AM 8:30AM

10:00AM

10:00AM 10:00AM

10:00AM

BOOST

1st ON 1st OFF2nd ON 2nd OFF 3rd ON 3rd OFF

6:30

AM 8:30 AM 12:00 PM 12:00 PM 4:30 PM 10:30 PM

DEFAULT TIME SETTINGS

The default factory settings are shown above, however if you wish to change these proceed as

instructed below.
