English

ACCESSORIES (Fig.1)

A Flexible crush proof hose

B Extension pipe

C Curved joint pipe

D Joint pipe

E Cloth bag

F Dusting brush (stored in tool

G Crevice nozzle storage space)

H Rug and floor tool (for CV-S880, CV-T885)

I Rug and floor tool (for CV-S890)

J Rug and floor tool (Y31)

K Rug and floor tool (D321-D)

HOW TO OPERATE

TO ASSEMBLE HOSE (Fig. 2)

The hose and joint pipe are packaged separately. To put them together,

insert the curved joint pipe and joint pipe into each end of the

hose until the claws of the stopper rings click into the holes

of the curved joint pipe and joint pipe.

TO ATTACH HOSE (Fig. 3)

Insert the joint pipe into the suction inlet of the cleaner. When you

remove the hose , pull the joint pipe while pressing the button .

TO ATTACH EXTENSION PIPES (Fig. 4)

Fit the extension pipes , and the selected suction attachment by

twisting together.

TO DETACH EXTENSION PIPES (Fig. 5)

Twist and pull the extension pipe , upward.

RUG AND FLOOR TOOL (Fig. 6) (for CV-S890)

To clean smooth surfaces, depress the switch " " to in line with

" " . To clean rugs or carpets depress the switch " " to in line

with " " .

RUG AND FLOOR TOOL (Fig. 21)

The tool is fitted with a brush at the back which can either be used in

the “withdrawn” or “projected” position. These positions are operated

by the pedal on the tool marked " " (Carpet) and " " (Floor)

For cleaning rug or carpet, keep the brush in its “withdrawn”

position, i.e., with the pedal marked " " pressed down with your

toe. If you feel the tool is heavy to slide on the carpet, please reduce

the suction power by adjusting the suction control. (Fig. 9)

ON-OFF SWITCH (Fig. 7)

Turn cleaner on or off by pushing downward on the power switch .

ELECTRONIC POWER CONTROL (for CV-S890, Fig. 8)

Suction power may be regulated electronically using the dial on the

unit . For stronger suction (thick carpets or hard floors) rotate the

dial to the right. Rotate it to the left for reduced suction (curtains,

delicate fabrics).

SUCTION CONTROL (Fig. 9)

Suction pressure is reduced by moving the adjustment ring on the

curved joint pipe to expose a hole.

The more hole area exposed the lower the suction.

Low suction pressure is recommended for cleaning curtains, blinds,

delicate fabrics etc,.

BAG FULL INDICATOR (Fig. 10)

When the orange sign appears in the large window continuously,

change the cloth bag.

Check the bag full indicator (with the highest power of electronic power

control for CV-S890) by lifting cleaning head from the surface being

cleaned or removing the crevice nozzle when it has been used.

NOTE: If the cleaner is used in such a condition as the orange sign

appears in the large window, air to the motor will be reduced

and the motor will eventually burn out.

AUTOMATIC CORD REWIND (Fig. 11)

The power cord is stored neatly inside the cleaner using an automatic

cord rewind.

When cleaning is completed unplug from the mains and depress the

rewind pedal , the cord will automatically rewind.

NOTE: Should the cord not fully rewind, pull out a short length and

press the pedal again.

For smooth rewinding, turn the cord inlet toward the same direction

as the cord pulled out.

TOOL STORAGE SPACE (Fig. 12)

The crevice and brush tools snap into the rear storage rack for

safekeeping and easy access.

TO USE ATTACHMENTS (Fig. 13,14)

TO STORE ACCESSORIES (Fig. 15)

Hose, extension pipe and rug and floor tool can be attached in

assembled condition to the cleaner by using the nozzle hook of

the rug and floor tool.

This combination allows you a space storage.

1. Place the cleaner upright.

2. Slide the nozzle hook of the rug and floor tool into the hook

supporter at the rear of the cleaner as shown in Fig. 15.

3. Turn the hose around pipes to make it compact and stable.

NOTE:

Do not hold the hose and the joint pipe to transport the cleaner.

TO DISCONNECT CURVED JOINT PIPE (Fig. 16)

Blockages may be cleared by separating the curved joint pipe

from the hose. To separate the curved joint pipe depress the two

claws which are located in the holes on both sides of curved joint

pipe and pull apart.

When needed, the hose collar can be removed from the hose end

by turning it (left-handed screw).

To re-connect push hose back into curved joint pipe and twist until

two claws locate with holes .

Likewise you can disconnect the hose joint on the other end of the hose.

HOW TO REMOVE DUST

TAKING OUT DUST BAG (Fig. 17)

1. Remove the plug from the electrical outlet. Open the bag

compartment lid by pulling up the clamp .

2. Pull out the dust bag gently.

3. Slide off the bag clip from the dust bag and dispose of dust in the

dust bag.

SETTING DUST BAG (Fig. 18)

1. Before setting the dust bag, be sure to slide back the bag clip.

2. Place the dust bag by opening its inner lid .

3. Position the top edges of the collar to the inner lid concave, and

fit the hole at the lower edge to the guide pins of the case.

NOTE

To avoid using the cleaner without the cloth bag, the clamp system of

your cleaner prevents the bag compartment lid from being clamped

when the cloth bag has not been replaced, or has not been set properly

in place.

CARE OF AIR FILTERS

MOTOR PROTECTION AIR FILTER (Fig. 19)

Once or twice a year, or when it becomes visibly soiled, the motor

protection filter located behind the cloth bag may need cleaning.

1. Take out the cloth bag, then remove the filter from the cleaner as

shown in Fig. 19 and wash in warm water.

2. After washing the filter, dry thoroughly away from direct sunlight

and fit back into the cleaner.

5

1

J1861_CV-S880(E) 15/07/2004, 4:07 PM2
