DRY VACUUM CLEANER EURO390

OPERATIG INSTRUCTIONS

These opereting instruction provide you with all information necessary for

correct , safe and prescribed usage and maintenance of the series DRY and

WET & DRY VACUUM CLEANER (ALL THE MODELS). They must be

kept where they are accessible to the user at all times.

PRESCRIBED USAGE

This machine is designed for the professional cleaning according to these

operating instructions.

Any other usage, in particular, for the removal of types of dust whch may be

dangerous to health, is prohibited.

GENERAL SAFETY INSTRUCTIONS

This machine is designed and constructed according to che present state of the

art and recognised technical safety standards. It is fitted with protective devices,

following safety European standard rules. Dangers can occur in spite of this, in

particular in the case of maloperation or non-compliance with the

specifications and information in the operating instructions.

All our equipements are coverde by international assurances against risks.

1) Sources of danger

- Electrical voltage / Electric current

- Warning: Danger

Contact with voltage or current carrying parts carries the risk of electric shock

which can result in serious injury or even death. Never touch damaged cables.

Always switch off and disconnect the power supply before carrying out any

work on the machine. Replace faulty cables immediately.

2) Improper usage

Any usage of the machine for a purpose not covered under the “Prescribed

usage” or contractually agreed purpose is not permissible. The use of the

machine in an unserviceable condiction or not in compliance with the

following prescription is prohibited:

- Protective devices must not be removed or bypassed.

- Conversions and modification to the machine are not permitted.

- Defective supply cables are only to be replaced by original FIORENTINI

cables.

- Coupling elements between mains supply or detachable extension cables

must be at least splashproof.

- The machine is to be fitted with a type H circuit breaker for rated current of

10 A for the vacuum with 1 or 2 motors and 15 A for 3 motors.

3) Organisational points

It is the responsibility of the operator to ensure that:

- The machine is used only by personnel who have been instructed in its

handling and authorised to use it.

- The recognised occupational safety regulations are observed.

- Any further national or internal company regulations are abserved.

- All users are acquainted with the safety regulations and trained in the use of

the specific machine.

- All users have read and understood the operatin instructions.

- Responsabilities for the operation, maintenance and repair of the machine are

clearly assingned and abserved.

- Faults and damage are immediately notified to the Service Agent of

FIORENTINI.

4) In the case of an emergency

- Pull out the mains connector plug.

- Immediately apply recognised first-aid measures.

After incidents, do not resume operation with the machine until it has been

inspected by FIORENTINI autorized technical.

5) Opetating for the first time

Delivery, instruction on safety rules, handling and maintenance as well as

operation for the first time must be carried following the specification of this

instruction book. The operator is responsible for instructing the users.

FUTHER SAFETY INSTRUCTIONS CONCERNING OPERATING AND

MAINTENANCE ARE DETAILED IN THE RELEVANT SECTIONS

AND MUST BE COMPLIED WITH!

IMPORTANT NOTES

BEFORE STARTING TO USE THE CLEANER PLEASE OBSERVE THE

FOLLOWING POINTS:

- If you should discover any damage when unpacking the cleaner please inform

your sale agency.

- Certain parts are packed in the tank to protect them from damage. These

should be removed before the cleaner is put into use.

- The supply voltage must be the same as that shown on the nameplate.

ELECTRICAL CONNECTION AND SUPPLY

WARNING: - This appliance must be earthed!

- Check that the supply voltage details given on the rating plate are in

accordance with your electricity supply.

CAUTION!

- The cleaner should never be used for picking up hot ashes, explosive fluids or

undiluted acids or solvents. These include petrol, paint thinner and heating oil,

all of which can generate explosive mixtures or vapours when swirled together

with the suction air. Acetone, undiluited under acids and solvents would attack

the materials from which the machine is made.

WARNING NOTE

- For cleaning or servicing the cleaner or when replacing parts, the motor

should be switched off and the connecting plug be withdrawn from the socket.

- Care should be taken to ensure that the connecting calble is not damage by

being driven over, crusced, strained, etc.

- The connecting cable should be regularly checked for any signs of damage or

ageing.

- The machine must not be used if the conneting cable is not in a proper

condition.

- For suction of dry dust, check that the filter are in the vaccum cleaner, also

for draw up liquids care to take out the filter from the vaccum cleaner.

- Do not use foaming chemical.

- Do not clean the vaccum with a water pipe to avoid that water get trought the

vaccum head.

UTILIZATION

1) First operation before use

- Introduce the flex hoses in the hole of the machine until the click insert. Look

that the seal ring is on right position.

- Put the accessory that you need on the hoses.

2) Transport

- To avoid damage during the transport by car or by truck, the vaccum cleaner

must be put inside his original package.

MAINTENANCE AND CLEANING ATTENTION

Take out the plug before any maintenance operation on the head of the

machine.

NORMAL OPERATION OF MAINTENANCE:

- Clean the vaccum cleaner inside and outside.

- Clean the rubber which is in the cover of the head.

- Check the hoses and the electric cable.

IF LOOSE POWER

- Check the filter.

IMPORTANT: IF YOU CLEAN THE FILTER MICROWEB WITH

WATER, WAIT THAT IT IS DRY BEFORE TO INSERT IN THE

VACCUM AGAIN.

TROUBLE SHOOTIN

FAULT

CAUSE

REMEDY

Motor (suction

turbine) does not start

No electrical power

Check fuse,cable,plug

and socket

Suction slowly

decreases

Filter,nozze,suction hose or

extensios tube blocked

Check and clean

Suction suddenly

decreases

The paper filtre bag or the

tank is full

Switch off the cleaner

and empty

Dust ascapes when

cleaning

Filter incorrectly or

defective

Check filter sealing.

Replace filter

-In case of defective electric or electronic goods,

Please return them separately from other materials,

In order to help us in dividing dangerous wastegoods

And recycle the (RAEE) as DER 2002/96/CEE LOW.
