Bruksanvisning FERM CSM1012 Cirkelsåg

Bruksanvisning

- Make sure the blade is secure.

- Use this circular saw to saw only wood, wood-

like products.

2. Do not use circular saw blades wich are deformed or

damaged.

3. Do not use HSS blades.

4. Only use blades meeting the required dimensions, as

well as data and descriptions;

Never apply any blades of which the thickness is

greater than that of the riving knife.

5. Do not stop the blade of a circular saw by pressing

the blade from the side.

6. Check that the blade guard can freely move and fully

closes.

7. Never lock-up the guard in the open position.

8. Never put sideward pressure on the blade. This may

cause the blade to break.

9. Be careful when cutting wood with knots, nails or

cracks in it and/or dirt on it, as these can cause the

blade to get stuck.

10. Never leave the circular saw unattended.

11. Use this circular saw to saw only wood or wood-like

products.

USING THE MACHINE:

1. Use clamps or a vice to hold the work.

2. Never remove wood chips and saw dust that is close

to the saw blade with your hands. If there are small

pieces of wood left between the fixed and the

movable parts, the circular saw will have to be

stopped. The plug needs to be removed from the

socket, before any left piece can be removed.

3. Check that the blade is suitable for the spindle speed

of the circular saw. Do not attempt to cut before the

circular saw has reached full speed. Make sure the

circular saw runs without load (i.e. is not in contact

with the work) when you switch it on. The circular

saw must have reached its full speed first.

4. Never cut wood that is thicker than the depth of the

saw blade.

5. When cutting in wooden walls or floors, check there

is no wiring or piping where you intend to cut.

6. Switch off the tool and wait until the blade has

stopped completely before moving the saw away

from the work or putting it down. Hearing

protection should be worn when using circular saw.

SWITCH OFF THE MACHINE IMMEDIATELY

WHEN YOU DISCOVER:

1. A defective mains plug or mains lead;

2. A defective switch.

3. Overheating of the circular saw.

4. Smoke or odeur caused by scorched insulation.

3. ASSEMBLY AND ADJUSTING

INSTRUCTIONS

Before adjusting the saw, make sure the plug is

removed from the socket.

SETTING THE SAWING ANGLE (BEVEL)

Fig. B.

- Loosen the handle (1) that sets the sawing angle.

-

Rotate the soleplate to the correct position (0° -

45°), and retighten the handle. The sawing angle

(bevel) can be read on the protractor (2).

FITTING THE RIP FENCE

Fig. B.

- Loosen the knob (3) that clamps the rip fence.

-

Slide the rip fence into the special slot(6) in the sole

plate.

- Set the correct cut width and retighten the knob (3).

SETTING THE CUT DEPTH

Fig. C.

- Loosen the handle (1) that sets the sawing depth.

- Move the soleplate (2) downwards.

- The cutting depth of the saw blade can be read off the

curved scale attached to the upper side of the sole

plate.

- Retighten the handle (1) once the correct depth is

set.

EXCHANGING OR CLEANING THE SAW BLADE

Fig. D.

- Use the shaft locking knob (C3) to prevent the shaft

from rotating.

- Next, loosen the hexagonal bolt (3) in the centre of

the saw blade, using the box spanner.

- Turn the safety guard to the rear, and hold it there

with the aid of the knob (1).

- Remove the outside flange and the saw blade, and

clean the saw blade or replace it with a new one.

- Again place the saw blade back on the shaft. Ensure

that the teeth of the saw blade are pointing in the

same direction as the riving knife (4).

- Allow the safety guard to return over the saw blade

by releasing the knob (1).

- Press the shaft locking knob (C3) back in, refit the

outside flange (5) and tighten the hexagon bolt (3)

firmly, once more.

RENEWING AND REPLACING THE CARBON

BRUSHES

Fig. E.

- Remove the rear protective cover (no. 1) from the

motor casing, after first loosening the two Phillips

screws.

- Loosen the screw of the carbon brush holder.

- Withdraw the carbon brush holder from the casing,

and remove the old carbon brush.

- Fit the new carbon brush into the holder, and return

the holder to its location in the casing.

- Re-tighten the screw in the carbon brush holder.

- Replace both carbon brushes at the same time, and

never mix old and new brushes in this tool.

- Replace the rear protective cover (no. 1) on the

motor casing, and tighten the two Phillips screws.

Frequent use will cause the carbon brushes to wear

down. Regular inspection, after every 30 hours of

use, is essential. If the brushes have worn down to

less than 4 mm, replace.

Ferm 5

Vi erklærer at under almindeligt ansvar, at dette

FKS-210

er i overenstemmelse med følgende

normer eller normative dokumenter

EN60745-1, EN60745-2-5,

EN55014-1, EN-55014-2,

EN61000-3-2, EN61000-3-3,

i henhold til bestemmelserne i direktiverne:

98/37/EC, 89/336/EEC,

2002/95/EC, 2002/96/EC, 2006/95/EC

01-08-2007

ZWOLLE NL

J.A. Bakker - van Ingen J. Lodewijk

CEO Ferm BV Quality Manager Ferm Global

Det er vores hensigt til stadighed at forbedre vores

produkter, og vi forbeholder os derfor til enhver tid

retten til at ændre produktspecifikationerne uden

forudgående varsel.

Ferm BV •

Lingenstraat 6 • 8028 PM Zwolle

Holland

CE

ı

KONFORMITETSERKLÆRING

(

DK

)

52 Ferm
