Bruksanvisning

GREAT BRITAIN - CUSTOMER SERVICE contact number: 020 8247 9300 e-mail: customerservice@clasohlson.co.uk internet: www.clasohlson.co.uk

English

Ver. 20141027

Remote control with

keyboard and gyro mouse

Art.nr 18-8417 Modell ZW-51025

38-6633 ZW-51025

Please read theentire instruction manual before using theproduct

and then save it for future reference. Wereserve theright for

any errors in text or images and any necessary changes made

to technicaldata. Intheevent of technical problems or other

queries, please contact our Customer Services.

Safety

• When thebattery is charged, remove thechargercable.

• Never attempt to dismantle or modify theproduct.

• Do not expose theproduct to moisture anddamp.

• Thebattery will discharge if theproduct is not used for

alongtime.

• Only use thecharger supplied.

• Overcharging shortens thelife of thebattery.

• Only use thesupplied charger cable and accessories.

Product description

Combined remote control with keyboard and gyromouse.

IRremote function with nine buttons which can be

programmed using your TV remote, and awireless QWERTY

keyboard to easily type in internet addresses, YouTube

searches,etc. Thebuilt-in gyro mouse allows you to accurately

control themouse pointer on thescreen with simple hand

movements, just like aregularmouse. Nomouse pad or flat

desk space is needed. Built-in rechargeable battery.

Care and maintenance

Clean theproduct by wiping it with asoft, dampcloth.

Neveruse solvents or abrasive cleaning agents.

Disposal

This product should be disposed of in accordance with local

regulations. Ifyou are unsure how to proceed, contact your

local council.

Buttons and functions

Remote control

Theorange buttons belong to theremote control.

Programming

Operating instructions

The keyboard

Thewhite keys belong to thekeyboard and

gyro mouse.

1. Plug theUSB receiver into thecomputer.

Thekeyboard can also be used for some

newer TV models. Referto theinstruction

manual for your TV to find out if it supports

thekeyboard.

2. Start thekeyboard by moving theslider to ON.

3. Thekeyboard pairs with thedevice automatically so you

can start using it straightaway.

4. Switch thekeyboard off by moving theslider to OFF.

NB. Youcan recharge thekeyboard’s built-in battery via

theUSB socket. TheLED lights up red while charging and

goes out when fully charged. Theproduct can be used while

charging. Whenthebattery is almost empty, theLED willflash.

Gyro mouse

Theproduct can be used as amouse pointer.

1. Point thetop of theproduct towards thescreen to control

thepointer.

2. Use thewhite buttons to perform what you want todo.

NB. Youcan use thelock button [

] at any time to enable

and disable thegyromouse.

Automatic shut off

Thekeyboard shuts off automatically after 3 minutes of

inactivity. AllLEDs turnoff. Activate thekeyboard again by

pressing any button.

1. Press and hold [ SET ] for about 4 seconds. TheLED blinks

once and then stayssolid.

2. Point theIR sensor on theremote control towards theIR

sensor of theoriginal remote control. Thedistance

between them must not be more than 7cm.

3. Then press any button on theremote control, theLED will

flash twice and then stay solid, which means that it is in

programmingmode.

4. Press any button on theoriginal remote control that you

want to programme, theLED will flash three times on

theremote control and then stay solid, which means that

programming is complete.

5. Repeat steps 2–4 until all thebuttons are programmed.

6. Press and hold [ SET ] for about 10 seconds toend.

Troubleshooting guide

If themouse pointer begins to wander on thescreen or does

not follow your movements, theproduct can be calibrated.

1. Place thekeyboard on aflat surface.

2. Press and hold theleft [

] and right [ ] mouse buttons

for about 3 seconds and then release.

Specifications

Range Upto 10m

Compatible with Windows 8, 7 (32/64-bit),

Vista (32/64-bit) and XP

Supplied with USB charging cable and 2.4 GHz

nano receiver

Size 156×49.5×10 mm
