Page 5 FFS5463W / GG54SSW Upright Cooker User Manual FFS5463W / GG54SSW Upright Cooker User Manual Page 6

FIRST TIME USE OF THE APPLIANCE

Setting the time

Ifyouhavepurchasedamodelttedwitha3buttonprogrammabletimer,youmustsetthe

time of day before you can operate your appliance. Note: The clock has a 24 hour display

• After the appliance has been electrically connected “00.00” will be displayed

and the “

”willash.

• To set the time of day, press the “–” or “+” buttons. 15 seconds after the last change,

the “

”willdisappear,conrmingthetimehasbeenset.

Fitting oven shelves

• Ensure shelf orientation is correct (refer picture).

• Slide into oven at an angle until raised back of shelf is past the stop on

side runners.

• Lower front of shelf and push in until stop is reached.

NOTE: The top ledge is not a shelf position

Preparing your appliance for the rst time

• Wipe out the oven interior prior to operation with warm soapy water and polish dry with a soft clean cloth.

• Newappliancescanhaveanodourduringrstoperation.Itisrecommendedto‘runin’yourovenbeforeyoucook

forthersttime.Runtheovenat180°Cfor2-4hoursandensurethattheroomiswellventilated.

• Please install oven furniture as outlined in the “Fitting Oven Accessories and Cleaning” section.

• Ifyourapplianceisttedwithsolidhotplates,turnheatsettingtohighfor3minutestofullyhardenthecoating.

When cooled, apply a thin coating of cooking oil to seal the surface.

Using the oven

Oven safety warnings

• Always follow the instructions for putting the shelves and side racks into the oven, to avoid accidents.

• Do not line the oven with foil, it will damage the enamel.

• Do not place cookware or anything else on the bottom of conventional oven model as trapped heat will damage

the oven

• Do not touch the hot surfaces or heating elements inside the oven.

• Do not use the oven door as a shelf.

• Do not push down on the open oven door.

• Do not place shelves on top of upper most shelf runner as there are no stops for shelf withdrawal.

USING THE OVEN OF YOUR ELECTRIC COOKER

Set Oven Function

Description of oven functions (mode)

Lamp

The lamp of the oven is on. No heating elements are on.

Grill (uses upper element)

Suitable for grilling food or browning food.

Do not use lowest shelf position.

Fan Assisted Grill cooking

The upper heating element and the fan come on. Suitable for Grilling food without turning over and using two

shelves. Do not use lowest shelf position

Fan-forced Cooking

The rear circular heating element and the fan come on to make heat distribution more uniformly throughout the

oven. This mode is ideal for general purpose cooking on 3 shelves at the same time.

Defrosting Mode

Only the fan operates. It is located on the back of the oven, making the air circulate at room temperature

around the food. This is recommended for the defrosting of all types of food. By using the fan, the defrosting time is

approximately halved .

Set Thermostat knob (Temperature setting)

• Selection of cooking temperature is carried out by turning the knob clockwise to the

required temperature, between 60c to MAX .

• Oven indicator lamp will come on when the oven is heating up.

• When it goes out it means that it reached the required temperature.

• Thelampwillcycle‘on&o’regularlyduringusewhichisthennormal.

It means that oven temperature is being constantly maintained at the selected level.

Set Cooking Time

120 Minute Ringer Timer with “Oven ON/OFF”

Operating oven without Timer

• Turn knob counter clockwise to “

” symbol. The oven will operate without use of

the timer function.

Operating oven using the Timer

• To set the timer, simply turn the knob clockwise to the required number of minutes.

The timer will automatically shut down the oven after the set minutes and the timer

will ring at the same time.

NOTE:Foranytimebelowfteenminutesturntheknobpastthefteenthenturnitbacktotherequirednumberof

minutes.Whenthetimerreturnstozero,thetimergivesashortring.
