Bruksanvisning EasyHome GT-TBs-01uk Eltandborste

Bruksanvisning

1

2

3

4

5

6

9

8 7

Safety instructions

Description of parts /

scope of delivery

1 Charging station

2 Brush handle

3 On/off function button

Function 1 (red)

= Normal (30,000

movements/min.)

Function 2 (yellow) = Soft (40,000

movements/min.)

Function 3 (green) = Massage (30,000

movements/min. with short intervals)

Function 4 = OFF

4 LED function display (charging control

LED and operating mode display)

5 Toothbrush attachment (blue)

Replacement toothbrush attachments

(red and green) in the scope of

delivery.

6 Lid for accessory compartment

7 Tooth gap brush

8 Dental fl oss holder

9 Tongue brush

- Operating Instructions/Guarantee Card

2

7

3

8

45

106 9

OPERATING INSTRUCTIONS

Sonic Toothbrush

BATHROOM

GB

AFTER SALES SUPPORT

[email protected]

0800 / 328 6020

IRE

00800 / 4467 5888

MODEL: GT-TBs-01uk, 01/2015, 91866, E47207

YEAR WARRANTY

3

Table of Contents

Safety Instructions ........................................3

Description of parts / scope of delivery ....7

Prior to initial use ..........................................9

Use ...............................................................11

Replacement toothbrush attachments ....14

Faults and rectifi cation ..............................14

Technical data ...........................................15

Conformity Declaration .............................16

Environmental information ........................16

Warranty .......................................................18

Warranty card

Symbols

Hazard!

Injuries can occur if not observed.

Caution!

Property damage can occur if not observed.

Info

In front of information and explanations.

WEEE symbol

The appliance must not be disposed of with general waste.

Battery return

Batteries must not be disposed of with household waste.

Read and follow these

instructions for use completely

prior to using the appliance and keep

these in case you need to refer to

them later. If you pass the product on

to someone else, please also include

these instructions.

Designated use

The purpose of the appliance is for brushing teeth and is

only suitable for private households. It is not suitable for

commercial use.

The appliance may only be used with the included accessories

and matching toothbrush attachments.

Hazard for children and a wider group

of persons

This appliance can be used by children from the age of 8, as

well as by persons with limited physical, sensory or mental

abilities or lacking experience and/or knowledge, if they are

under supervision or after receiving instruction on safe use

of the appliance and have understood the resulting hazards.

Children must not play with the appliance. Cleaning and user

maintenance must not be carried out by children, unless they

are supervised and more than 8 years old.

Children under the age of 8 should be kept away from the

appliance.

Keep children away from packaging material. Su ocation

hazard if swallowed. Ensure that packaging bag is not put

over the head.

Children must be supervised in order to ensure that they do not

play with the appliance.

Hazard from electricity

Electric shock hazard! The appliance

operates with hazardous voltage.

Handling liquids in relation to electrical appliances requires utmost

attention!

A frequent cause of household accidents is a lack of attention

during routine activities. Ensure that your hands are always dry

when connecting/disconnecting the mains plug.

The appliance must not be exposed to dripping or spray water.

The charging station must not be immersed in water or other

liquids. Electric shock hazard! Therefore, also do not use the

charging station in the vicinity of moisture sources, e.g. a sink,

bathtub or shower.

Do not operate the appliance outdoors and do not expose it to

weather in uences, such as rain, snow or frost.

Only connect the charging station to a properly installed socket,

with voltage corresponding to the “technical data”.

When using an adapter plug or extension cord, these must comply

with the valid safety regulations. The speci ed maximum voltage

must not be exceeded.

Ensure that th socket is well-accessible, so that you can remove the

mains plug quickly, if necessary.

Do not use the appliance:

– if the appliance is damaged,

– if the power cable or mains plug are damaged.

– if the device has fallen.

Unwind the power cable completely prior to each use.

In doing so, ensure that the power cable is not trapped,

squeezed or damaged by sharp edges or hot items.

Disconnect the mains cable from the socket:

– if you are not using the charging station,

– after the charging process,

– before cleaning or putting the appliance away,

– if an obvious fault occurs during operation,

– in a thunder storm.

Always pull on the mains plug, not on the power cable.

Do not carry out any modi cations to the appliance or its

mains cable.

Only allow repairs to be carried out on appliances by a

professional workshop. Please also note the guarantee

conditions.

The power cable of the charging station cannot be replaced. If

damaged, the appliance must be disposed of.

The brush handle may only be used with the supplied

charging station.

The appliance must not be connected to a time switch or

other separate remove activation system, such as a dimmer

switch or a remote-control socket.

Injury hazards from other causes

Lay the power cable to that it does not become a trip hazard.

Replace worn or damages brush attachments immediately in

order to prevent injuries in the area of the mouth and teeth.

Caution – property damage

Place the device on a sturdy, even and heatproof surface.

When doing so, ensure a su ciently large distance to strong

heat sources, e.g. heating plates, heating pipes, et al.

Avoid a heat accumulation and position the appliance so that

heat can escape all around the housing during use.

Do not place any items, e.g. cloths or magazines on the

charging station. Fire hazard!

A rubberised stand surface is situated on the underside of the

appliance. As the furniture/ oor surfaces are made of diverse

materials and are treated with diverse care products, it cannot

be entirely ruled out that some of these materials contain

components, which could attack and soften the appliance stand

surface. If necessary, place a non-slip base under the appliance.

Do not use any aggressive chemical detergents, abrasives,

hard sponges, or similar, for cleaning.

Instructions on the charging procedure/

battery

After initial use, the full battery

performance is only reached

after charging and discharging the

battery several times.

Overcharging of the battery is excluded. If the battery charged,

remove the brush handle from the charging station and

remove the mains plug of the charging station from the socket.

If the movements of the brush attachment reduce noticeably

or if a depleted battery is displayed on the brush handle, the

battery requires recharging.

Yo u wi ll c on tr ib ut e to t he c are of t h e bat te r y i f you on ly

charge it when it is depleted.

Continuous charging reduces the life of the battery.

Prior to disposal of the appliance, the battery must be

removed from the appliance, please refer to Environmental

information.

Prior to removing the battery,

disconnect the charging

station from the power supply and

completely discharge the brush

handle.

Prior to initial use

Unpacking

Remove the appliance and accessories from the packaging.

With the order card, you can

reorder toothbrush attachments,

as required. Keep these with the

operating instructions.

Carefully remove all packaging material and completely

unroll the power cable.

Before using the appliance for the  rst time, check whether

the voltage speci cation on the rating place corresponds to

that of your household. The rating plate is on the underside

of the charging station.

Clean the appliance with a slightly dampened cloth prior

to initial use, in order to remove possible packaging and

production residues.

Rinse the toothbrush attachments (5, 7, 8 and 9) under

running water and wipe all parts dry.

Place the charging station (1) on a sturdy, level surface.

First-time charging and additional

charging processes

Connect the charging station (1) an to a properly installed

socket and place the brush handle (2) onto the charging

station as shown.

Leave the brush handle (2) on

the charging station (1) for

approx. 24 hours when charging for

the fi rst time.

For each subsequent full charging

process, 16 hours are suffi cient.

The LED function display (4) fl ashes

green during the charging process.

When the charging process is

completed, the function display (4)

will continuously illuminate in green.

After the fi rst charging process,

around 16 hours are suffi cient for

each additional charging process.

The brush handle (2) can only be

switched on after approx. 2 seconds

after being removed from the

charging station.

A red fl ashing LED function display

(4) in operation or approx. 30

seconds after switching off indicates

a depleted battery. Depending on

the remaining capacity, several

brushing cycles can still be carried

out. Charge the brush handle (2) for

approx. 16 hours.

It is normal for the brush handle to

heat up during charging.

The charging process takes place

using induction and can be

impaired by metallic items that

are in the vicinity of the charging

station. Maintain a minimum

distance of 10 cm between metallic

items and the charging station.

Disconnect the charging station

from the power supply as soon as

the charging process has ended.
